Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors
Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors
Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors
Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors
Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors
Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors
Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors
Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors
Specifications
Brand Name :
Supermicro
Model Number :
AS-4124GS-TNR
Place of Origin :
China
MOQ :
1/set
Payment Terms :
T/T
Supply Ability :
50pcs per week
Delivery Time :
2-3 work days
Form Factor :
4U Rackmount
Processor :
Dual AMD EPYC™ 7003/7002 Series Processors
GPU :
8 Double-Width/Single-Width PCI-E 3.0/4.0 x16 Card (Full Height Full Length)
System Memory :
32 DIMM slots* Up to 8TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
Expansion Slots :
9 PCI-E 4.0 x16 (FHFL) slots or 10 PCI-E 4.0 x16 (FHFL) slots without NVMe devices
Drive Bays :
Up to 24x 2.5" SAS/SATA drive bays 2x 2.5" SATA supported natively* 4x 2.5" NVMe (Gen3 only) supported natively RAID controller option available for 24 HDDs
Power Supply :
2000W Redundant Power Supplies with PMBus
Dimension (W x H x L) :
73.5 x 40 x 203 mm
Description

Key Applications- AI / Deep Learning
- High Performance Computing (HPC)
- Cloud Gaming
- Molecular Dynamics Simulation
Key Features
1.Supports up to 8 double-width GPUs
Direct connect for maximum performance
2.Dual AMD EPYC™ 7003/7002 Series Processors
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
3.8TB Registered ECC DDR4 3200MHz SDRAM in 32 DIMMs
4.9 PCI-E 4.0 x16
(Option: 10 PCI-E 4.0 x16 slots without NVMe devices)
5.Up to 24 Hot-swap 2.5" drive bays.
With included hardware:
• 2x 2.5" SATA in RAID 1 via onboard
Marvell 9230
• 4x 2.5" NVMe (Gen3 only; depends on PCI-E quantity
based on #4)
RAID controller option available for 24 HDDs
6.2 GbE LAN ports (rear)
7.8 Hot-swap 11.5K RPM cooling fans
8.2000W (2+2) Redundant Power Supplies
Titanium Level (96%+)
(full redundancy based on configuration and application load)


Form Supermicro AS-4124GS-TNR 4U GPU Server
Processors
  • Dual AMD EPYC™ 7003/7002 Series Processors
    (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)*
  • Socket SP3
  • Up to 128 Cores (64 per CPU)
GPU

  • Supported GPUs

    8 Double-Width/Single-Width PCI-E 3.0/4.0 x16 Card (Full Height Full Length)
    NVIDIA A100, V100, A40, T4, Quadro RTX, AMD Instinct
    Supports both active and passive cooled GPUs

    CPU-GPU Interconnect

    PCI-E Gen 4 x16 Direct Connect CPU-GPU Dual-Root

    GPU-GPU Interconnect

    NVIDIA® NVLink™ Bridge (Optional), AMD Infinity Fabric (optional)
System Memory

Memory Capacity

32 DIMM slots*
Up to 8TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM

Memory Type

3200MHz ECC DDR4 RDIMM/LRDIMM
Drive Bays Configuration

Hot-swap

Up to 24x 2.5" SAS/SATA drive bays
2x 2.5" SATA supported natively*
4x 2.5" NVMe (Gen3 only) supported natively
RAID controller option available for 24 HDDs
Expansion slots

9 PCI-E 4.0 x16 (FHFL) slots
or 10 PCI-E 4.0 x16 (FHFL) slots without NVMe devices
Power Supply 2000W Redundant Power Supplies with PMBus
Dimensions

(W x H x L)
  • 73.5 x 40 x 203 mm
