Xfusion FusionServer 2258 V7 2U Rack Server with 4th Gen AMD EPYC™ 9004 Series Processors, OCP 3.0 NIC, and TPM 2.0 Security
Xfusion FusionServer 2258 V7 2U Rack Server with 4th Gen AMD EPYC™ 9004 Series Processors, OCP 3.0 NIC, and TPM 2.0 Security
Xfusion FusionServer 2258 V7 2U Rack Server with 4th Gen AMD EPYC™ 9004 Series Processors, OCP 3.0 NIC, and TPM 2.0 Security
Xfusion FusionServer 2258 V7 2U Rack Server with 4th Gen AMD EPYC™ 9004 Series Processors, OCP 3.0 NIC, and TPM 2.0 Security
Xfusion FusionServer 2258 V7 2U Rack Server with 4th Gen AMD EPYC™ 9004 Series Processors, OCP 3.0 NIC, and TPM 2.0 Security
Xfusion FusionServer 2258 V7 2U Rack Server with 4th Gen AMD EPYC™ 9004 Series Processors, OCP 3.0 NIC, and TPM 2.0 Security
Specifications
Brand Name :
Xfusion
Model Number :
2258 V7
Place of Origin :
China
MOQ :
1/set
Payment Terms :
T/T
Supply Ability :
50pcs per week
Delivery Time :
2-3 work days
Form Factor :
2U Rack Server
Processors :
1 or 2 x 4th Gen AMD EPYC™ 9004 Series processors (Genoa) with up to 400 W TDP per processor
Network :
1 x OCP 3.0 NIC, which can be configured as required and supports hot swap and PCle 5.0
PCle Expansion :
1 x FlexlO expansion slot dedicated for an OCP 3.0 NIC; 8 x FH standard PCle expansion slots, including 4xPCle 5.0 slots
Security :
Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot,and chassis cover opening detection
Dimensions(H x W x D) :
86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.)
Description

FusionServer 2258 V7 (2258 V7) is a new-generation 2U 2-socket rack server designed for SDS, VDI, CDN, virtualization, big data, DB, cloud scenarios, AI inference, small enterprises, OA, and web applications, meeting requirements of enterprise or telecom service applications and other complex workloads. The 2258 V7 features robust performance, solid scalability and reliability, easy deployment, and simplified management.


technical specification

Form Factor

2U rack server

Processors

1 or 2 x 4th Gen AMD EPYC™ 9004 Series processors (Genoa) with up to 400 W TDP per processor

Memory

12 or 24 x DDR5 DlMM slots, delivering up to 4800 MT/s

Local Memory

Hot-swappable and flexible drive configurations:

·8x2.5"SAS/SATA drives

·12 to 16 x3.5"SAS/SATA drives

·24 xNVMe SSDs

·12 x2.5" drives (including 8 x NVMe drives)

Flash storage:

·2 xM.2 SSDs(SATA/NVMe)

RAID

RAlD 0,1,10,5, 50, 6, and 60: supercapacitors for cache data protection against power failures;

RAlD level migration, drive roaming, self-diagnosis, and remote web-based configuration

Network

1 x OCP 3.0 NIC, which can be configured as required and supports hot swap and PCle 5.0

PCle Expansion

1 x FlexlO expansion slot dedicated for an OCP 3.0 NIC; 8 x FH standard PCle expansion slots, including

4xPCle 5.0 slots

Security

Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel,

secure boot,and chassis cover opening detection

Dimensions(H x W x D)

86.1 mm x 447 mm x798 mm(3.39 in. x 17.60 in. x 31.42 in.)


Xfusion FusionServer 2258 V7 2U Rack Server with 4th Gen AMD EPYC™ 9004 Series Processors, OCP 3.0 NIC, and TPM 2.0 Security


Xfusion FusionServer 2258 V7 2U Rack Server with 4th Gen AMD EPYC™ 9004 Series Processors, OCP 3.0 NIC, and TPM 2.0 Security
