Supermicro Ultra SuperServer SYS-220U-MTNR 2U Rackmount Server with Dual Socket P+ 3rd Gen Intel Xeon Scalable Processors and Up to 4 GPUs
Supermicro Ultra SuperServer SYS-220U-MTNR 2U Rackmount Server with Dual Socket P+ 3rd Gen Intel Xeon Scalable Processors and Up to 4 GPUs
Supermicro Ultra SuperServer SYS-220U-MTNR 2U Rackmount Server with Dual Socket P+ 3rd Gen Intel Xeon Scalable Processors and Up to 4 GPUs
Supermicro Ultra SuperServer SYS-220U-MTNR 2U Rackmount Server with Dual Socket P+ 3rd Gen Intel Xeon Scalable Processors and Up to 4 GPUs
Supermicro Ultra SuperServer SYS-220U-MTNR 2U Rackmount Server with Dual Socket P+ 3rd Gen Intel Xeon Scalable Processors and Up to 4 GPUs
Supermicro Ultra SuperServer SYS-220U-MTNR 2U Rackmount Server with Dual Socket P+ 3rd Gen Intel Xeon Scalable Processors and Up to 4 GPUs
Supermicro Ultra SuperServer SYS-220U-MTNR 2U Rackmount Server with Dual Socket P+ 3rd Gen Intel Xeon Scalable Processors and Up to 4 GPUs
Supermicro Ultra SuperServer SYS-220U-MTNR 2U Rackmount Server with Dual Socket P+ 3rd Gen Intel Xeon Scalable Processors and Up to 4 GPUs
Specifications
Brand Name :
Supermicro
Model Number :
SYS-220U-MTNR
Place of Origin :
China
MOQ :
1/set
Payment Terms :
T/T
Supply Ability :
50pcs per week
Delivery Time :
2-3 work days
Form Factor :
2U Rackmount
Processor :
Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors Up to 40C/80T; Up to 60MB Cache per CPU
Max GPU Count :
Up to 4 double-width or 6 single-width GPUs
Supported GPU :
NVIDIA PCIe: T4, RTX A6000, RTX A5000, A40, A30, A16, A2, A100, A10
Slot Count :
32 DIMM slots
Gross Weight :
66 lbs (30 kg)
Net Weight :
40 lbs (18.2 kg)
Available Color :
Black Front & Silver Body
Power Supply :
2x 1200W Redundant Titanium Level (96%) Hot-plug power supplies
Description

Key Applications

Virtualization, HPC, Cloud Computing, High End Enterprise Server, Software

Defined Storage, Application Tier Service Provider, 5G/Telco,

Key Features

Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors;

Intel® C621A Chipset;

32 DIMM Slots; Up to 8TB DRAM; Up to 8TB Intel® Optane™ Persistent

Memory (up to 12TB with DRAM); 3200/2933/2666 ECC DDR4

LRDIMM;RDIMM; Intel® Optane™ Persistent Memory 200 series;

1 PCIe 4.0 x16 (LP)

1 PCIe 4.0 x16 (FH, 10.5"L)

5 PCIe 4.0 x8 (FH, 10.5"L)

1 internal PCIe 4.0 x8 (in x16 slot, LP);

Flexible networking options;

6x 2.5" hot-swap hybrid NVMe/SATA/SAS drive bays;

6 heavy duty fans with optimal fan speed control;

1600W redundant Titanium level power supplies;

Form Factor

2U Rackmount

Enclosure: 437 x 89 x 574mm (17.2" x 3.5" x 22.6")

Package: 625 x 253 x 1154mm (24.6" x 9.96" x 45.43")

Processor

Dual Socket P+ (LGA-4189)

3rd Gen Intel® Xeon® Scalable processors

Up to 40C/80T; Up to 60MB Cache per CPU

GPU

Max GPU Count: Up to 4 double-width or 6 single-width GPUs

Supported GPU: NVIDIA PCIe: T4, RTX A6000, RTX A5000, A40, A30, A16, A2, A100, A10

System Memory

Slot Count: 32 DIMM slots

Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM

Supports Intel® Optane™ persistent memory 200 series

Drive Bays Configuration

Default: Total 6 bays

6 front hot-swap 2.5" NVMe/SAS*/SATA drive bays

(*SAS support may require additional storage controller and/or cables)

Expansion Slots

Default

1 PCIe 4.0 x16 FH/10.5"L slot

5 PCIe 4.0 x8 FH/10.5"L slots

1 PCIe 4.0 x8 LP slot

1 PCIe 4.0 x16 LP slot

On-Board Devices

SATA: SATA (6Gbps) ; RAID 0/1/5/10 support

NVMe: NVMe; RAID 0/1/5/10 support

Chipset: Intel® C621A

Network Connectivity: 2 RJ45 10GBASE-T with Intel® X710-AT2 (optional)

2 RJ45 10GBASE-T with Intel® X710-TM4 (optional)

2 SFP+ 10GbE with Intel® X710-TM4 (optional)

No NIC option supported

Power Supply

1x 1600W Redundant Titanium Level (96%) Hot-plug power supply

Dimensions and Weight

Weight: Gross Weight: 66 lbs (30 kg)

Net Weight: 40 lbs (18.2 kg)

Available Color: Black Front & Silver Body
