KTHP100 Series High-Precision Multifunctional Differential Pressure Transmitter with IP65/NEMA4 Rating
KTHP100 Series High-Precision Multifunctional Differential Pressure Transmitter with IP65/NEMA4 Rating
KTHP100 Series High-Precision Multifunctional Differential Pressure Transmitter with IP65/NEMA4 Rating
KTHP100 Series High-Precision Multifunctional Differential Pressure Transmitter with IP65/NEMA4 Rating
KTHP100 Series High-Precision Multifunctional Differential Pressure Transmitter with IP65/NEMA4 Rating
KTHP100 Series High-Precision Multifunctional Differential Pressure Transmitter with IP65/NEMA4 Rating
Specifications
Model Number :
KTHP100
Type :
Differential Pressure & Temperature/Humidity
Max air velocity / flow rate :
30 m/s
Temperature Range :
–35 ... +80 °C
Certification :
CE
Cable gland :
M16 × 1.5 / M20 × 1.5
Packaging Details :
Carton
Powersupply :
16–30 VDC (2-wire 4–20 mA) / 16–30 VAC or VDC (0–5 V / 0–10 V / RS485)
Humidity Range :
0 ... 100% RH
Delivery Time :
15 work days
Protection rating :
IP65 / NEMA4
Payment Terms :
T/T
Pressure Range :
±100Pa~±1000Pa
Pressure Accuracy :
< ±1% FS @ –5 to +65 °C
MOQ :
5
Shell Material :
PC+ABS
Response time :
0.5 s
Brand Name :
Keramcontrols
Output Signal :
4–20 mA / 0–5 V / 0–10 V / RS485
Description
KTHP100 Series Differential Pressure & Temperature & Humidity
The KTHP100 Series Differential Pressure & Temperature/Humidity Transmitter is a multifunctional, high-precision measuring instrument that integrates three core parameters.
Product Overview
Measurement Media Air, neutral gases, dry gases, and other gases
Range -35 ... +80 °C
0 ... 100% RH
Output Signal 4-20 mA / 0-5 V / 0-10 V / RS485
Power Supply 16-30 VDC (2-wire 4-20 mA)
16-30 VAC or VDC (0-5 V / 0-10 V / RS485)
Accuracy ±0.3 °C @ +20-60 °C
±2% RH(20-80% @ 25 °C)
±3%RH (0-20% & 80-100% @ 25 °C)
Protection Rating IP65/NEMA4
Cable Connector M16 * 1.5 / M20 * 1.5
Display LCD with backlight (no backlight for 2-wire 4-20 mA)
Applications
  • Building Energy Management Systems (BEMS)
  • HVAC systems
  • Cleanroom and laboratory environmental monitoring
  • Pharmaceutical and medical equipment integration
  • Data center environmental control
  • Industrial manufacturing facility environmental monitoring
  • Ventilation duct differential pressure and airflow measurement
  • Agricultural greenhouse climate control
  • Food storage and cold chain logistics
  • Museum and archive temperature/humidity control
