PIR motion sensor Panasonic EKMB1374112K with low current consumption and high signal to noise ratio
PIR motion sensor Panasonic EKMB1374112K with low current consumption and high signal to noise ratio
PIR motion sensor Panasonic EKMB1374112K with low current consumption and high signal to noise ratio
PIR motion sensor Panasonic EKMB1374112K with low current consumption and high signal to noise ratio
PIR motion sensor Panasonic EKMB1374112K with low current consumption and high signal to noise ratio
PIR motion sensor Panasonic EKMB1374112K with low current consumption and high signal to noise ratio
Specifications
Description :
Optical Motion Sensors RoHS
Mfr. Part # :
EKMB1374112K
Model Number :
EKMB1374112K
Description

Panasonic PIR Motion Sensors (PaPIRs)

Panasonic's PaPIRs are highly sensitive and reliable PIR motion sensors designed for easy integration and environmentally friendly operation. They offer advanced features like high signal-to-noise ratio, reduced false alarms, and low current consumption, making them ideal for a wide range of applications from smart home devices to industrial equipment.

Product Attributes

  • Brand: Panasonic
  • Product Series: PaPIRs
  • Available Series: EKMB(WL), EKMC(VZ), AMN(NaPiOn)
  • Pyroelectric Element Material: Ferroelectric LiTaO3 single lead-free crystal (Panasonic), Ceramic base material (Conventional)
  • Lens Colors: White, Black, Pearl white
  • Output Types: Digital, Analog

Technical Specifications

SeriesModel No.Current Consumption (Standby)Lens TypeOutput TypeDetection DistanceDetection Area (Horizontal)Detection Area (Vertical)Detection Zones
EKMB(WL)EKMB11011111AStandard detectionDigital5m948264
EKMB(WL)EKMB11011121AStandard detectionDigital5m948264
EKMB(WL)EKMB11011131AStandard detectionDigital5m948264
EKMB(WL)EKMB12011112AStandard detectionDigital5m948264
EKMB(WL)EKMB12011122AStandard detectionDigital5m948264
EKMB(WL)EKMB12011132AStandard detectionDigital5m948264
EKMB(WL)EKMB1301111K6AStandard detectionDigital5m948264
EKMB(WL)EKMB1301112K6AStandard detectionDigital5m948264
EKMB(WL)EKMB1301113K6AStandard detectionDigital5m948264
EKMB(WL)EKMB11031111ALong distanceDigital12m1029292
EKMB(WL)EKMB11031121ALong distanceDigital12m1029292
EKMB(WL)EKMB11031131ALong distanceDigital12m1029292
EKMB(WL)EKMB12031112ALong distanceDigital12m1029292
EKMB(WL)EKMB12031122ALong distanceDigital12m1029292
EKMB(WL)EKMB12031132ALong distanceDigital12m1029292
EKMB(WL)EKMB1303111K6ALong distanceDigital12m1029292
EKMB(WL)EKMB1303112K6ALong distanceDigital12m1029292
EKMB(WL)EKMB1303113K6ALong distanceDigital12m1029292
EKMB(WL)EKMB11041111AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMB(WL)EKMB11041121AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMB(WL)EKMB11041131AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMB(WL)EKMB12041112AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMB(WL)EKMB12041122AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMB(WL)EKMB12041132AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMB(WL)EKMB1304111K6AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMB(WL)EKMB1304112K6AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMB(WL)EKMB1304113K6AWall installationDigital12m (1st step), 6m (2nd step), 3m (3rd step)1054068
EKMC(VZ)EKMC1601111170AStandard detectionDigital5m10092-
EKMC(VZ)EKMC1601112170AStandard detectionDigital5m10092-
EKMC(VZ)EKMC1601113170AStandard detectionDigital5m10092-
EKMC(VZ)EKMC1603111170ALong distanceDigital11.3m10092-
EKMC(VZ)EKMC1603112170ALong distanceDigital11.3m10092-
EKMC(VZ)EKMC1603113170ALong distanceDigital11.3m10092-
EKMC(VZ)EKMC1604111170AWall installationDigital5m92--
EKMC(VZ)EKMC1604112170AWall installationDigital5m92--
EKMC(VZ)EKMC1604113170AWall installationDigital5m92--
AMN(NaPiOn)AMN31112-Standard detectionDigital5m82--
AMN(NaPiOn)AMN31111-Standard detectionAnalog5m82--
AMN(NaPiOn)AMN21112-Standard detectionDigital5m82--
AMN(NaPiOn)AMN21111-Standard detectionAnalog5m82--
AMN(NaPiOn)AMN32112-Long distanceDigital14.8m82--
AMN(NaPiOn)AMN32111-Long distanceAnalog14.8m82--
AMN(NaPiOn)AMN22112-Long distanceDigital14.8m82--
AMN(NaPiOn)AMN22111-Long distanceAnalog14.8m82--
AMN(NaPiOn)AMN33112-Wall installationDigital5m100--
AMN(NaPiOn)AMN33111-Wall installationAnalog5m100--
AMN(NaPiOn)AMN23112-Wall installationDigital5m100--
AMN(NaPiOn)AMN23111-Wall installationAnalog5m100--
AMN(NaPiOn)AMN34112-Slight motion detectionDigital10m24.6m110-
AMN(NaPiOn)AMN34111-Slight motion detectionAnalog10m24.6m110-
AMN(NaPiOn)AMN24112-Slight motion detectionDigital10m24.6m110-
AMN(NaPiOn)AMN24111-Slight motion detectionAnalog10m24.6m110-
EKMB(WL) (Lensless)EKMB11001001ALenslessDigital----
EKMB(WL) (Lensless)EKMB12001002ALenslessDigital----
EKMB(WL) (Lensless)EKMB1300100K6ALenslessDigital----
EKMC(VZ) (Lensless)EKMC1600100170ALenslessDigital----

Application Scenarios

  • Digital signage
  • Vending machines
  • Lighting systems, lighting control, lighting equipment
  • OA (office automation) for MFP (multi-function printers), Display panels for meeting rooms, PCs
  • Home appliances (Air conditioners, air purifiers, automatic toilets)
  • Thermostats, HVAC (heater, ventilator or air conditioner)
  • Security equipment (IP cameras, intrusion alarms)
  • IoT, smart home, HEMS (home energy management systems) by battery-operated wireless PIR Motion sensor modules
