Ultraminiature SMD Photointerrupter ROHM RPI-0128 Ideal for Digital Still Cameras and Video Devices
Ultraminiature SMD Photointerrupter ROHM RPI-0128 Ideal for Digital Still Cameras and Video Devices
Specifications
Slot Width :
1.2mm
Voltage - Forward(Vf) :
1.35V
Rise Time :
10us
Output Current :
30mA
Fall Time :
10us
Description :
1.2mm 1.35V SMD Photointerrupters - Slot Type - Transistor Output RoHS
Mfr. Part # :
RPI-0128
Model Number :
RPI-0128
Package :
SMD
Description

RPI-0128 Photointerrupter

The RPI-0128 is an ultraminiature SMD type photointerrupter designed for compact electronic devices. It features a gap of 1.2mm and is suitable for applications in digital still cameras (DSC), digital video cameras (DVC), and digital handy phones.

Product Attributes

  • Brand: ROHM
  • Type: Ultraminiature SMD
  • Gap: 1.2mm

Technical Specifications

Parameter Symbol Conditions Min. Typ. Max. Unit
Absolute Maximum Ratings
Collector-emitter voltage VCEO (Ta=25C) - - -30 V
Emitter-collector voltage VECO (Ta=25C) - - 5 V
Collector current IC (Ta=25C) - - 80 mA
Collector power dissipation PC (Ta=25C) - - 80 mW
Forward current IF (Ta=25C) - - 30 mA
Power dissipation PD (Ta=25C) - - 30 mW
Operating temperature Topr - -25 - +85 C
Storage temperature Tstg - -25 - +85 C
Electrical and Optical Characteristics
Forward voltage VF IF=5mA - 1.35 1.5 V
Reverse current IR VR=5V - - 10 A
Dark current ICEO VCE=5V, IF=5mA - - 0.1 A
Peak sensitivity wavelength P IF=5mA - 800 - nm
Collector current IC1 VCE=5V, IF=5mA - 1.0 - mA
Collector current IC2 VCE=5V, IF=20mA - - 5 mA
Collector-emitter saturation voltage VCE(sat) IF=20mA, IC=0.1mA - 0.4 - V
Cut-off frequency fC VCC=5V, IF=20mA, RL=100 - - 850 kHz
Rise time tr VCC=5V, IF=20mA, RL=100 - - 1 s
Fall time tf VCC=5V, IF=20mA, RL=100 - - 1 s
Response time tr VCC=5V, IC=1mA, RL=100 - - 10 s
Response time tf VCC=5V, IC=1mA, RL=100 - - 10 s

2412232010_ROHM-RPI-0128_C5280867.pdf
