RF coaxial adapter cable BAT WIRELESS BWNJ-TNCK-RG58L1000 with N Male to TNC Female connectors
RF coaxial adapter cable BAT WIRELESS BWNJ-TNCK-RG58L1000 with N Male to TNC Female connectors
Specifications
Operating Temperature :
-45℃~+85℃
Line Length :
1m
Description :
1m Gas Sensor RoHS
Mfr. Part # :
BWNJ-TNCK-RG58L1000
Model Number :
BWNJ-TNCK-RG58L1000
Description

Product Overview

The Bat Wireless BWNJ-TNCK-RG58L1000 is a high-performance RF coaxial adapter cable designed for reliable signal transmission in wireless communication applications. Operating from 0 to 6000 MHz, this cable features an N Male to TNC Female connector configuration and utilizes RG58 coaxial cable. It is engineered to minimize signal attenuation and insertion loss, making it suitable for connecting devices with N and TNC interfaces. Applications include wireless communication modules (GPS/Beidou, 4G/5G, Wi-Fi/Bluetooth), test and measurement equipment, and IoT terminals, ensuring compatibility and stable signal integrity.

Product Attributes

  • Brand: BAT WIRELESS
  • Model Number: BWNJ-TNCK-RG58L1000
  • Cable Type: RG58
  • Connector Type 1: N Male (N-J)
  • Connector Type 2: TNC Female (TNC-K)
  • Cable Length: 1000mm (1 meter)
  • Certifications: RoHS & REACH Complaint
  • Inner Conductor Material: Copper
  • Insulation Material: FEP
  • Outer Conductor Material: Copper
  • Jacket Material: FEP
  • Mount Way: Screw-on

Technical Specifications

Parameter Value Unit Notes
Product Type Adapter Cable -- MH
Frequency Range 0-6000 MHz --
Input Impedance 50 --
Contact Resistance < 1 OC IC
Contact Resistance < 0.2 OC OC
Insulation Resistance >5000 M --
DC Voltage 1500 V --
Insert Loss 0.5 dB(6GHz) Typ.
RF leakage -- -- --
Durability 500 Times ID of Plug / OD of Jack
Cable Length 1000 mm --
Operating Temperature -45~ +85 --
Storage Temperature -45~ +85 --
Capacitance 10010 Pf/m --
Max Attenuation (400 MHz) 0.187 dB/m --
Max Attenuation (800 MHz) 0.378 dB/m --
Max Attenuation (1000 MHz) 0.58 dB/m --
Max Attenuation (1800 MHz) 0.617 dB/m --
Max Attenuation (2000 MHz) 1.76 dB/m --
Max Attenuation (2690 MHz) 2.69 dB/m --

2512181047_BAT-WIRELESS-BWNJ-TNCK-RG58L1000_C49563184.pdf
