1.Product Overview​

The ​Murr Elektronik 55091 MurrCase Metal Profile Set​ is an industrial-grade mounting system for modular control cabinet components, designed to optimize space and streamline installations in automation enclosures. Constructed from robust, anodized aluminum alloy (AIMgSi0.5), these profiles support tool-less DIN-rail assembly for PLCs, relays, and terminal blocks. Compatible with Murr's modular component ecosystem, it features pre-drilled M6 mounting slots and standardized 35mm clip-in rails that withstand vibrations up to ​15g (IEC 60068-2-6)​. Ideal for high-density control panels requiring flexible reconfiguration.

​2.Key Technical Specifications​

​Core mechanical parameters:

• ​Material: Aluminum EN AW-6060 T66 (100% recyclable)
• ​Dimensions: 7.5mm × 1.5mm profile height/depth; customizable lengths (50–2000mm)
• ​Load Capacity: 80kg/m distributed load (per DIN 28791)
• ​Mounting: Tool-less DIN rail EN 60715 snap lock (retention force >40N)
• ​Corrosion Resistance: Class 2 salt spray (ISO 9227 NSS 480hr)
• ​Temperature Range: -50°C to +105°C (ambient operation)
• ​Electrical Continuity: <10mΩ impedance for EMI grounding (EN 61000-4-4)
• ​Compatibility: Supports all Murrcase accessory clips (e.g., cable ducts, fan trays)
• ​Flammability Rating: UL 94 V-0
• ​Standards: EN 60439-1, UL 508A

3.​Primary Applications​

​Control cabinet optimization:

• ​Automotive Assembly: Flexible PLC/Safety controller mounting in welding line cabinets
• ​Renewable Energy: High-density I/O module organization in wind turbine nacelles
• ​Packaging Lines: Vibration-resistant mounting for servo drives in bottling machines
• ​Railway Signaling: Compact relay groupings in trackside control boxes
• ​Semiconductor Fabs: Static-safe component mounting in cleanroom electrical panels
• ​AGV Charging Stations: Modular power contactor arrangement
  Eliminates drilling/welding – reduces cabinet build time by 50%.

​4.Competitive Advantages​

​Unique engineering benefits:

• ​Tool-Less Installation: Spring-loaded DIN rail locks deploy in <2 seconds
• ​Zero Grounding Kits: Integrated 360° conductive coating replaces grounding wires
• ​Thermal Management: 8W/mK heat dissipation (vs. 0.8W/mK steel)
• ​Hybrid Material Inserts: Compatible with plastic vibration dampers (optional)
• ​Legacy Integration: Adapters for legacy DIN-rail EN 60715 G32 components
• ​Customization: Laser etching for component labeling (1200 dpi resolution)
• ​Weight Savings: 60% lighter than steel profiles with equal strength

5.​Functional Capabilities​

​Advanced mounting features:

• ​Dynamic Reconfiguration: Rail segments snap/reposition without disassembly
• ​EMI Shielding: Continuous conductive surface blocks RF interference >30dB
• ​Cable Routing: Integrated clips for 25/40/60mm cable ducts (no tools)
• ​Seismic Resilience: Lateral shock absorption via tuned damper slots
• ​Access Ports: Removable sections for connector pass-throughs
• ​Static Load Testing: Pre-certified for forklift impact loads (ISO 15870)
• ​Corrosion Monitoring: Anodization wear indicators (visual blue/green fade)
  Includes ​self-aligning end caps​ for IP20 dust protection.

​
