Specifications
Brand Name :
Phoenix Contact
Model Number :
800886
Certification :
3C
Place of Origin :
Germany
MOQ :
1
Price :
USD 100-10000/Piece
Payment Terms :
T/T
Supply Ability :
1/piece in stock
Delivery Time :
3-7
Packaging Details :
50*50*50mm
Application :
Industrial control systems, automation equipment
Color :
Black
Features :
Modular design, easy assembly
Primary Type :
DIN Rail Mount
Marking Mounting Type :
plug in
Contact Material :
Gold Plated
Note :
Can be labeled with CMS
Connection Method :
IDC/FLK pin strip
Description

Product Overview

The Phoenix Contact ​800886​ is a high-performance surge protection module designed to safeguard sensitive industrial automation equipment from voltage spikes and transient overvoltages. Part of Phoenix Contact’s TRABTECH series, this device ensures reliable protection for control systems, communication networks, and power supplies in harsh environments. Its compact, DIN rail-mountable design (EN 60715) allows seamless integration into control cabinets, motor control centers, and switchgear panels. The module features a robust polycarbonate housing with ​IP20 protection, providing resistance to dust and mechanical impacts.

Engineered for universal compatibility, the 800886 supports a wide range of industrial applications, including PLCs, sensors, and communication interfaces. Compliance with ​IEC 61643-11, ​UL 1449, and ​RoHS/REACH​ standards ensures global safety and environmental compliance. Its visual status indicators (green/red LEDs) provide real-time monitoring of protection status, simplifying maintenance and fault detection.


Key Technical Parameters

The 800886 is defined by precision-engineered specifications for surge protection:

  • Rated Voltage: 24 V DC (for control circuits) / 230 V AC (for power lines).
  • Maximum Discharge Current (Imax)​: 20 kA (8/20 µs pulse), ensuring robust protection against lightning-induced surges.
  • Voltage Protection Level (Up)​: <1.5 kV (for 24 V DC systems), minimizing risk to sensitive electronics.
  • Response Time: <1 ns, providing near-instantaneous reaction to transient events.
  • Operating Temperature: -40°C to +80°C, suitable for extreme industrial environments.
  • Connection Type: Screw terminals for secure, vibration-resistant wiring (0.2–4 mm² conductor cross-section).
  • Certifications: UL 1449 (Type 4), CE, and IEC 61643-11 (surge protective devices).

These parameters make the 800886 ideal for protecting low-voltage control systems and communication networks.


Primary Applications

The 800886 is critical in safeguarding automation infrastructure across industries:

  • PLC and Controller Protection: Shields I/O modules and control logic from voltage surges in manufacturing and robotics.
  • Sensor Networks: Protects analog/digital sensors in process automation (e.g., chemical plants, water treatment).
  • Communication Lines: Secures RS-485, Ethernet, and fieldbus systems (PROFIBUS, CANopen) in industrial networks.
  • Renewable Energy Systems: Protects solar inverters and wind turbine controllers from lightning-induced surges.
  • Transportation Infrastructure: Used in railway signaling and traffic control systems to ensure uninterrupted operation.

Its robust design also suits oil and gas facilities, where explosive atmospheres (ATEX compliance may vary) and electrical noise are prevalent.


Competitive Advantages

The 800886 excels through innovative surge protection technology and user-centric design:

  • High Surge Capacity: Handles up to ​20 kA​ discharge current, exceeding industry standards for critical systems.
  • Visual Status Monitoring: Dual-color LEDs provide instant feedback on module health and failure alerts.
  • Tool-Free Replacement: Modular design allows quick swap without disconnecting adjacent components.
  • Universal Compatibility: Works with 24 V DC to 230 V AC systems, reducing inventory complexity.
  • Durability: Flame-retardant housing (UL94 V-0) and corrosion-resistant terminals ensure long-term reliability.

These features minimize downtime, protect costly equipment, and reduce maintenance costs in mission-critical installations.


Functional Features

The 800886 delivers advanced surge protection capabilities:

  • Multi-Stage Protection: Combines gas discharge tubes and varistors for coordinated suppression of fast and slow transients.
  • Thermal Disconnect: Automatically disconnects from the circuit upon overload to prevent fire hazards.
  • Remote Signaling: Optional auxiliary contacts (model-specific) enable integration into SCADA systems for predictive maintenance.
  • Compact Design: Space-saving footprint allows high-density installations in control panels.
  • Easy Diagnostics: Replaceable modules with snap-on DIN rail mounting simplify troubleshooting.

Combined with Phoenix Contact’s rigorous testing standards, the 800886 ensures uninterrupted operation and compliance with global safety regulations.


Property Specification
Product Type PCB Terminal Block (Plug-in Connector)
Model Number 800886
Series COMBICON MSTB
Pitch 5.08 mm
Number of Poles 2
Rated Voltage 300 V AC/DC
Rated Current 16 A
Wire Size 0.2–4 mm² (AWG 24–12)
Contact Material Brass, tin-plated
Housing Material Polyamide (PA66), UL 94 V-0 flame-retardant
Screw Type Slotted screw (M3)
Torque 0.5–0.6 Nm
Operating Temperature -40°C to +105°C
Storage Temperature -40°C to +120°C
Isolation Voltage 4 kV AC (between poles)
Protection Class IP20 (when mounted on PCB)
Safety Standards UL 1059, CSA C22.2 No. 158, EN 60947-7-1, RoHS, REACH
Certifications UL Recognized, CSA, CE
Mounting PCB-mounted (THT, through-hole technology)
Connection Type Screw clamping for wires
Dimensions (L×W×H) 10.2 mm × 5.08 mm × 15.5 mm (per pole)
Weight ~2.5 g (per pole)
Applications Power distribution, control boards, industrial automation, and electrical equipment.
