400L Glassware Washing Machine 380V Pharmaceutical Glass Washer
400L Glassware Washing Machine 380V Pharmaceutical Glass Washer
Specifications
Brand Name :
Senova
Model Number :
HG-400S
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
Available upon request
Payment Terms :
T/T
Supply Ability :
200 units
Delivery Time :
5-20 working days
Packaging Details :
plywood case
Product name :
Pharmaceutical Glassware Washer
Capacity :
400L
Tank Internal Temprature :
RT - 93℃
Door Structure :
Single
Door Opening :
Electric
Control System :
PLC with 7" touch screen
Dimensions :
1500mm x 800mm x 1800mm
Power Supply :
380V/50Hz, 3 phase
Description
400L Heavy Duty Glassware Washer (with single door) HG-400S
Main features
Cleaning System

Two rotating spray arms at the top and bottom, paired with multi-layer racks featuring parallel water intake to guarantee uniform pressure on each tier.

Two water inlets (a third is optional) for simultaneous tap and pure water connection.

Cleaning aid is dosed with precision by a peristaltic pump, while a circulating pump, regulated by a flow meter, optimizes pressure and flow.

Control System

S-i-e-m-e-n-s PLC and a 7’’ LCD touch screen

40 standard and 200 user-defined programs, which can be custom-named

Self-diagnostic function for components, a sealed panel to resist dust and moisture, and a crucial power-off memory function that resumes interrupted cycles

Safety Protection

An emergency stop switch and real-time water leakage monitoring.

The lift door has an automatic induction device that stops motion upon detecting obstructions

A door interlock prevents opening during operation, and separate, lockable strong and weak current distribution boxes isolate electrical systems.

Comprehensive alarms cover overheating, heating failures, low detergent, and water issues.

Audit Trail System

Three-level password management (super user, administrator, operator).

Over 20,000 cleaning and 20,000 alarm records, searchable on-screen.

Data can be exported via USB in PDF format or printed.

Each cleaning log details equipment ID, program, operator, timestamps, and cycle parameters.

Automatically records all operational actions and parameter changes for full traceability.

Specifications
Model HG-400S
Exterior Dimension(W*D*H,mm) 1110*900*2165
Capacity(L) 400
Control System PLC/S-i-e-m-e-n-s or equivalent
Display 7" touch screen
Door Structure Single door
Door Opening Method Electric door(manual door optional)
Circulating pump flowA(L/min) 1000
Circulating pump flowB(L/min) /
Tank Internal Temperature(C) Rt-93
Water Heater Power(kW) 15
Drying temperature(C) Rt-120
Dry Power(kW) 3.6
Voltage(V/Hz) 380/50
Introduction about laboratory glassware washer

The Evolution to Precision Cleaning
From humble origins akin to household appliances, modern laboratory glassware washers have evolved into essential, high-precision instruments. They provide automated and thorough cleaning and disinfection for critical labware like beakers and pipettes, eliminating contaminants that could compromise experimental results. Contemporary models are defined by sophisticated programmable controls, integration with pure water systems, and advanced features like HEPA-filtered drying. This evolution directly enhances lab safety by minimizing manual contact with hazardous residues and boosts efficiency by conserving time and resources. As exemplified by manufacturers like Senova, today's washers offer customizable, gentle cycles that guarantee reproducible cleanliness, making them a vital, long-term asset for data integrity and research excellence.
