The main machine lift, with ambidextrous design, allows for precise positioning of the glassware. Digital displays of rotation speed and heating bath temperature allow optimal control of all distilling processes. New clamp mechanism simplifies changing of evaporation flasks. This package comes with a heating bath and one set of glassware (vertical).
| Model | NoVap-AL6 |
| Voltage | 220V/50Hz 110V’60Hz |
| Machine Power | 1560W |
| Rotating Motor | 40W |
| Lift motor Power | 20W |
| Heating Power | 1500W |
| Vacuum | 0.098Mpa |
| Boiling Flask | 6L flask /Φ50 flange |
| Collect Flask | 3L flask Φ195mm,35#Ball milling mouth |
| Stirring Speed | 0-200rpm/min |
| Temp. Control Range | Ambient to 99℃ |
| Temperature Accuracy | ±1℃ |
| Main Motor Lift Stroke | 90mm |
| Main Condenser | Φ100x530H(mm) |
| Condensing Area | 0.26㎡ |
| Feeding Valve | 19#Standard plug valve |
| Vacuum Suction Nozzle | Outer diameter of pagoda joint10mm |
| Condensing Pipe Inlet and Outlet Circulation Nozzle | Outer diameter of pagoda joint 12mm |
| Heating Pot | Φ275x160H(mm), around 9.5L |
| Dimensions(mm) | 690x 440x(825-9150) |
| Net Weight | 32Kg |
| Gross weight | 50Kg |
One of the most celebrated attributes of rotary evaporation is its capacity for gentle processing. Many organic, biological, and pharmaceutical compounds are thermally labile, meaning they degrade, isomerize, or decompose when exposed to high temperatures. Traditional distillation or open-air evaporation often subjects these materials to damaging heat. The rotovap circumvents this by combining vacuum (to lower boiling points) with minimal, controlled heating. This synergy allows solvents to be removed quickly at temperatures far below their atmospheric boiling points, often at room temperature or slightly above. This gentle approach preserves the integrity and bioactivity of sensitive products like natural products, enzymes, or complex pharmaceutical intermediates.
