12A TRIAC KY BT138-800E 800V Peak Voltage Suitable for Solid State Relays and Motor Controls
12A TRIAC KY BT138-800E 800V Peak Voltage Suitable for Solid State Relays and Motor Controls
Specifications
Holding Current (Ih) :
25mA
Voltage - On State(Vtm) :
1.55V
Average Gate Power Dissipation (PG(AV)) :
1W
Current - On State(It(RMS)) :
12A
Peak off - state voltage(Vdrm) :
800V
SCR Type :
1 TRIAC
Operating Temperature :
-40℃~+125℃
Gate Trigger Voltage (Vgt) :
1.5V
Description :
TRIAC 800V 12A Through Hole TO-220
Mfr. Part # :
BT138-800E
Model Number :
BT138-800E
Package :
TO-220
Description

ShenZhenHanKingyuan Electronic BT138 Series 12A TRIACs

The BT138 Series TRIACs from ShenZhenHanKingyuan Electronic are 12A, 4-quadrant TRIACs designed for various AC power control applications. They offer features like low gate trigger voltage (VGT: 1.5V) and are available in voltage ratings of 600V and 800V (VDRM/VRRM). These TRIACs are suitable for use in washing machines, vacuum cleaners, massagers, solid-state relays, and AC motor speed regulation.

Product Attributes

  • Brand: ShenZhenHanKingyuan Electronic
  • Series: BT138 Series
  • Product Type: TRIACs
  • Country of Origin: Shenzhen, China

Technical Specifications

Parameter Conditions BT138-600 BT138-800 Unit
Repetitive Peak Off-State Voltage (VDRM/VRRM) 600 800 V
R.M.S On-State Current (IT(RMS)) Tc=110C 12 12 A
Surge On-State Current (ITSM) 115/120 115/120 A
It for fusing Tp=10ms 70 70 As
Average Gate Power Dissipation (PG(AV)) Tj=125C 1 1 W
Peak Gate Current (IGM) tp=20us, Tj=125C 4 4 A
Operating Junction Temperature (Tj) -40~125 -40~125 C
Storage Temperature (TSTG) -40~150 -40~150 C
Parameter Test Conditions Value (Max) Unit
Repetitive Peak Off-State Current (IDRM) Tj=25C 5 uA
Repetitive Peak Off-State Current (IDRM) Tj=125C 1 mA
Repetitive Peak Reverse Current (IRRM) Tj=25C 5 uA
Repetitive Peak Reverse Current (IRRM) Tj=125C 1 mA
Forward "on" voltage (VTM) IT=35A, tp=380us 1.55 V
Gate trigger voltage (VGT) VD=12V, RL=30 1.5 V
Critical-rate of rise of commutation current (di/dt) I,II,III, Tj=125C, IG=2XIGT, tr 100ns, F=100Hz 50 A /us
Critical-rate of rise of commutation current (di/dt) IV, Tj=125C, IG=2XIGT, tr 100ns, F=100Hz 10 A /us
Gate trigger current (IGT) I,II,III, VD=12V RL=30 5, 10, 25, 50 mA
Gate trigger current (IGT) IV, VD=12V RL=30 10, 25, 70, 100 mA
Holding current (IH) IT=0.2A 10, 25, 30, 60 mA
Gate non-trigger voltage (VGD) ALL, VD=VDRM TJ=125C, RL=3.3K 0.2 V
Critical-rate of rise of commutation voltage (dv/dt) TJ=125C, VD=2/3VDRM Gate, tp=10ms 5, 10, 50, 200 V/us
Critical-rate of rise of commutation voltage (dv/dt) TJ=125C, VD=2/3VDRM Gate, tp=16.7ms 5, 10, 50, 200 V/us

2410121251_KY-BT138-800E_C2831695.pdf
