switching IGBT JIAENSEMI JNG75T65HMU2 suitable for boost converters UPS and portable power stations
switching IGBT JIAENSEMI JNG75T65HMU2 suitable for boost converters UPS and portable power stations
Specifications
Pd - Power Dissipation :
395W
Td(off) :
187ns
Td(on) :
32ns
Collector-Emitter Breakdown Voltage (Vces) :
650V
Reverse Transfer Capacitance (Cres) :
154pF
Input Capacitance(Cies) :
5.66nF
Gate-Emitter Threshold Voltage (Vge(th)@Ic) :
4.3V@1mA
Operating Temperature :
-55℃~+175℃
Pulsed Current- Forward(Ifm) :
160A
Output Capacitance(Coes) :
260pF
Reverse Recovery Time(trr) :
73ns
Switching Energy(Eoff) :
2.33mJ
Turn-On Energy (Eon) :
3.04mJ
Description :
395W 650V TO-247 Single IGBTs RoHS
Mfr. Part # :
JNG75T65HMU2
Model Number :
JNG75T65HMU2
Package :
TO-247
Description

Product Overview

JIAEN Trench IGBTs are designed to reduce conduction loss, improve switching performance, and enhance avalanche energy. They are suitable for applications such as motor drives, UPS, Boost converters, portable power stations, and other soft switching scenarios.

Product Attributes

  • Brand: JIAEN
  • Origin: www.jiaensemi.com

Technical Specifications

ParameterSymbolTest ConditionsMin.Typ.Max.Units
IGBT CharacteristicsVCES650V
VCE(sat)VGE=15V, IC=75A1.62.0V
BVCESVGE=0V, IC=250uA650V
Diode CharacteristicsIFTC=10040A
VFIF=40A1.852.15V
trrVCE=400V, IF=40A, dif/dt=200A/ns73ns
Maximum RatingsICTC=25150A
ICM(Note 1)300A
PDTC=25395W
Thermal CharacteristicsRth j-c (IGBT)0.38/W
Rth j-a40/W

2509021810_JIAENSEMI-JNG75T65HMU2_C51484262.pdf
