Logic Level Gate Drive N Channel IGBT onsemi FGD3040G2 F085 for Automotive Coil On Plug Applications
Logic Level Gate Drive N Channel IGBT onsemi FGD3040G2 F085 for Automotive Coil On Plug Applications
Specifications
Td(off) :
4.8us
Pd - Power Dissipation :
150W
Td(on) :
900ns
Collector-Emitter Breakdown Voltage (Vces) :
400V
Input Capacitance(Cies) :
-
IGBT Type :
-
Gate-Emitter Threshold Voltage (Vge(th)@Ic) :
1.3V@1mA
Gate Charge(Qg) :
21nC
Operating Temperature :
-55℃~+175℃@(Tj)
Turn-On Energy (Eon) :
-
Description :
IGBT 400V 41A 150W Surface Mount TO-252AA
Mfr. Part # :
FGD3040G2-F085
Model Number :
FGD3040G2-F085
Package :
TO-252AA
Description

Product Overview

The FGB3040G2-F085 / FGD3040G2-F085 / FGP3040G2-F085 / FGI3040G2-F085 are N-Channel Ignition IGBTs from the EcoSPARK2 series. These devices offer a high Self Clamping Inductive Switching (SCIS) energy capability of 300mJ at 25C and feature a logic-level gate drive. They are qualified to AEC Q101 standards, RoHS compliant, and suitable for automotive ignition coil driver circuits and coil-on-plug applications.

Product Attributes

  • Brand: ON Semiconductor
  • Product Series: EcoSPARK2
  • Certifications: AEC Q101, RoHS Compliant
  • Application Focus: Automotive Ignition Coil Driver Circuits, Coil On Plug Applications

Technical Specifications

Part NumberBVCER (V)BVECS (V)ESCIS25 (mJ)IC25 (A)IC110 (A)PD (W)TJ (C)RJC (C/W)VCE(SAT) @ ICE=6A, VGE=4V, TJ=25C (V)VGE(TH) @ ICE=1mA, VCE=VGE, TJ=25C (V)QG(ON) @ ICE=10A, VCE=12V, VGE=5V (nC)
FGB3040G2-F085400283004125.6150-55 to +17511.15 - 1.251.3 - 2.221
FGD3040G2-F085400283004125.6150-55 to +17511.15 - 1.251.3 - 2.221
FGP3040G2-F085400283004125.6150-55 to +17511.15 - 1.251.3 - 2.221
FGI3040G2-F085400283004125.6150-55 to +17511.15 - 1.251.3 - 2.221

2410121851_onsemi-FGD3040G2-F085_C606124.pdf
