Specifications
Td(off) :
35ns
Pd - Power Dissipation :
267W
Td(on) :
18ns
Collector-Emitter Breakdown Voltage (Vces) :
650V
Input Capacitance(Cies) :
1.52nF@30V
IGBT Type :
FS (Field Stop)
Gate-Emitter Threshold Voltage (Vge(th)@Ic) :
4V@40mA
Gate Charge(Qg) :
36nC@40A,15V
Operating Temperature :
-55℃~+175℃
Reverse Recovery Time(trr) :
206ns
Switching Energy(Eoff) :
280uJ
Turn-On Energy (Eon) :
970uJ
Description :
IGBT FS (Field Stop) 650V 267W Surface Mount D2PAK-3
Mfr. Part # :
FGB40T65SPD-F085
Model Number :
FGB40T65SPD-F085
Package :
D2PAK-3
Description

Product Overview

The FGB40T65SPD-F085 is a 650 V, 40 A IGBT utilizing novel field stop 3rd generation technology. It offers optimized performance with low conduction and switching losses for high efficiency, along with enhanced blocking voltage and rugged high current switching reliability. This device is also advantageous for parallel operation. It is copacked with a soft, fast recovery diode and is AEC-Q101 qualified.

Product Attributes

  • Brand: onsemi
  • Origin: Semiconductor Components Industries, LLC
  • Certifications: AEC-Q101 Qualified, RoHS Compliant
  • Material: Pb-Free

Technical Specifications

ModelDescriptionVCES (V)IC @ TC=25C (A)IC @ TC=100C (A)VCE(sat) (Typ.) @ IC=40A (V)TJ (C)Package
FGB40T65SPD-F085Field Stop, Trench IGBT65080402.0-55 to +175D2PAK-3 (TO-263, 3-LEAD)
