Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Triple Digit 0.28inch White 7 Segment LED Display Common Cathode
Specifications
Brand Name :
LIGHT-BO
Model Number :
LB30281DWH3A-D
Certification :
ISO9001&RoHS
Place of Origin :
Shenzhen, China
MOQ :
1000
Payment Terms :
T/T,Western Union
Supply Ability :
50000 PCS/Day
Price :
Negotiate
Delivery Time :
15-20 days
Packaging Details :
EPE+cartons
Emitting color :
red, blue, green, white, amber, orange and yellow
Shipping :
By DHL, TNT, UPS, EMS, etc.
Application :
Coffee Machine
Outer dimensions :
22.5 x 10 x 6.1mm
Character height :
0.28inch
Face Colour :
Yellow Segment Black Face
Description

Triple Digit 0.28inch White 7 Segment LED Display Common Cathode

Absolute Maximum Ratings(Ta=25ºC)

Parameter Symbol Ratings Unit
Forward Current(per dice) Ipm 20 mA
Reverse Voltage(per dice) Vr 5 V
Power Dissipation(per dice) Pm 80 mW
Operating Temperature Range Topr -40~+85 ºC
Storage Temperature Range Tstg -40~+85 ºC
Solder Temperature(3 sec) Th 260 ºC

Code:R-Ultra bright white

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage(Per dice) Vf If=10mA 2.8 3.2 V
Reverse Voltage(Per dice) Vr Ir=10uA 5 V
Luminous Intensty(Per dice) Iv If=10mA 100 140 mcd
Spectrum With Of Half Value λ If=10mA 20 nm
Color Temperature If=10mA 6000 6500 K
LED working lifetime 100,000hrs Absolute Maximum Rating at Ta=25ºC

Product Feature:

Forward voltage (high luminous intensity output)

Low power consumption

Extremely low current

Operating temperature: -45-80Cº

Luminous evenly distributed on each segment

Industrial standard size

Provides excellent reliability in bright ambient light

Stable performance

Long lifetime

Meet RoHS/REACH compliant

Applications:

Audio equipments or instrument panels

Home electronic appliances

Numeric displays

Multimedia products

General use for digital indicators,temperature indiators, humidity indicators,process indicators,and so on
