Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Specifications
Brand Name :
Light-Bo
Model Number :
LB4522IRJF1S
Certification :
ISO9001&RoHS
Place of Origin :
Shenzhen, China
MOQ :
1000
Price :
Negotiate
Payment Terms :
T/T, WU
Supply Ability :
20000 PCS/Day
Delivery Time :
10-15 days
Packaging Details :
EPE+CARTON
Min. Order :
1000 Piece/Pieces
Trade Term :
EXW
Origin :
Guangdong, China (Mainland)
Means of Transport :
Ocean, Air, Land
Production Capacity :
100,000 pcs/week
Packing :
EPE+Carton
Delivery Date :
10-15 days
Type :
Standard
Character height :
16mm(0.63inch)
Package dimensions :
45.2*21.5*7.5 mm
Polarity :
Common Anode
Emitting Color :
Red/green/orange
Description
Customized Multicolor Triple Digit 7 Segment LED Display Module
Light-Bo's customized triple-digit 7-segment LED display delivers vibrant performance and clarity for home electronic appliances. With 0.63-inch (16mm) character height and compact dimensions (45.2×21.5×7.5mm), it features striking yellow segments on a black surface with durable protective film. The display supports multi-color emission including red, yellow green, and orange. Designed with common anode configuration, it balances high luminous intensity (40-90mcd) with low power consumption (1.8-2.3V/LED), making it ideal for air conditioner controls, refrigerator indicators, and heating/cooling systems.
Product Images
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Technical Specifications
SpecificationDetails
Brand NameLight-Bo
TypeStandard
Digit CountTriple-digit (3 digits)
Character Height16mm (0.63 inch)
Package Dimensions45.2×21.5×7.5mm
PolarityCommon anode
Emitting ColorsRed (625-635nm), yellow green (569-573nm), orange (600-605nm); multi-color options available
Luminous IntensityRed: 70-90mcd; Yellow green: 40-50mcd; Orange: 60-70mcd
Forward Voltage1.8-2.3V/LED
Forward Current12-15mA/LED
Surface DesignYellow segments on black surface (with protective film)
ComplianceRoHS
Order & Logistics
Minimum Order1000 pieces
Trade TermEXW
Payment TermsT/T, WU
OriginGuangdong, China (Mainland)
Transport OptionsOcean, Air, Land
Production Capacity100,000 pcs/week
PackingEPE + Carton (secure protection for transit)
Delivery Time10-15 days
Absolute Maximum Ratings (Ta=25°C)
ParameterSymbolRatingsUnit
Forward Current (per dice)Ipm20mA
Reverse Voltage (per dice)Vr5V
Power Dissipation (per dice)Pm80mW
Operating Temperature RangeTopr-40~+85°C
Storage Temperature RangeTstg-40~+85°C
Solder Temperature (≤3 seconds)Th260°C
Electrical Characteristics by Color Code
Yellow Green - J
ParameterSymbolConditionMinTypMaxUnit
Forward VoltageVfIf=10mA1.82.4V
Reverse VoltageVrIr=10uA5V
Luminous IntensityIvIf=10mA3040mcd
Spectrum Width Of Half Value△λIf=10mA20nm
WavelengthDλIf=10mA569574nm
Amber/Yellow - Y
ParameterSymbolConditionMinTypMaxUnit
Forward VoltageVfIf=10mA1.82.5V
Reverse VoltageVrIr=10uA5V
Luminous IntensityIvIf=10mA6080mcd
Spectrum Width Of Half Value△λIf=10mA20nm
WavelengthDλIf=10mA585595nm
Orange - F
ParameterSymbolConditionMinTypMaxUnit
Forward VoltageVfIf=10mA1.82.4V
Reverse VoltageVrIr=10uA5V
Luminous IntensityIvIf=10mA6080mcd
Spectrum Width Of Half Value△λIf=10mA20nm
WavelengthDλIf=10mA600605nm
Super Bright Red - R
ParameterSymbolConditionMinTypMaxUnit
Forward VoltageVfIf=10mA1.82.2V
Reverse VoltageVrIr=10uA5V
Luminous IntensityIvIf=10mA5060mcd
Spectrum Width Of Half Value△λIf=10mA20nm
WavelengthDλIf=10mA630635nm
Ultra Bright Red - UR
ParameterSymbolConditionMinTypMaxUnit
Forward VoltageVfIf=10mA1.82.2V
Reverse VoltageVrIr=10uA5V
Luminous IntensityIvIf=10mA80100mcd
Spectrum Width Of Half Value△λIf=10mA20nm
WavelengthDλIf=10mA625635nm
Pure Green - G
ParameterSymbolConditionMinTypMaxUnit
Forward VoltageVfIf=10mA2.63.2V
Reverse VoltageVrIr=10uA5V
Luminous IntensityIvIf=10mA120180mcd
Spectrum Width Of Half Value△λIf=10mA20nm
WavelengthDλIf=10mA515525nm
Ultra Bright Blue - BH
ParameterSymbolConditionMinTypMaxUnit
Forward VoltageVfIf=10mA2.83.2V
Reverse VoltageVrIr=10uA5V
Luminous IntensityIvIf=10mA120140mcd
Spectrum Width Of Half Value△λIf=10mA20nm
WavelengthDλIf=10mA460465nm
Ultra Bright White - WH
ParameterSymbolConditionMinTypMaxUnit
Forward VoltageVfIf=10mA2.83.2V
Reverse VoltageVrIr=10uA5V
Luminous IntensityIvIf=10mA120140mcd
LED Color TemperatureKIf=10mA5500206800K
Chromaticity CoordinatesX/YIf=10mA0.29,0.320.30,0.33nm
About Light-Bo
SHENZHEN GUANGZHIBAO TECHNOLOGY CO., LTD. (BRAND: LIGHT-BO) - Established in 2006, we are a company that integrates R&D, manufacturing and sales of optoelectronics LED Displays. We are ISO 9001:2015 Quality Management Systems certified with more than 15 years OEM and ODM experience.
LIGHT-BO has been committed to provide high quality and low cost customized solutions to help customers reduce cost and enhance competitiveness.
Product Applications
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
7 Segment LED Display, Customized LED Display, Numeric LED Display, Dot matrix LED Display, widely used for home appliances, temperature indicators, humidity indicators, refrigerator controller, thermostats indicator, heating and cooling control and more.
Certifications
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Office and Factory Overview
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Company Exhibitions
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Shipping Services
Customized multicolour Triple Digit 7 Segment LED Display Module for Refrigerator Control Panel
Frequently Asked Questions
Q1: Are you trading company or manufacturer?
A: We are original manufacturer with more than 20 years experience in optoelectronic LED displays.
Q2: What is your main products?
A: Our main products include 7 Segment LED display, SMD LED Display, Dot matrix LED Display, Arrow LED display, Custom Design LED Display, LED light bar, Through hole led, SMD LEDs, LED Backlights, and more.
Q3: What is your MOQ?
A: Our MOQ is 1000 pcs. We can also accept sample orders and small orders with quantity less than our MOQ.
Q4: Before placing order, Can I get some samples for test?
A: Yes. We can provide 5-10 free samples for your testing, but the freight cost will be borne by the customer.
Q5: How long is your delivery time?
A: Delivery time: About 10-20 days; According to order quantity and raw materials. If you have urgent order and we have raw materials in stock, we can adjust our production plan to make it ready within 7-10 days.
Q6: What is your terms of payment?
A: We accept bank transfer, T/T, Western Union and Paypal with small amount. Details of payment methods can be negotiable.
Q7: Can you quote me FOB prices?
A: Yes. We can quote you prices based on incoterms EXW, FOB, CIF, DDP.
Q8: How can I get your catalogue and price list?
A: Yes. Please let us know your email address or contact us from website directly for our catalogue and price list.
Q9: Can I negotiate the prices?
A: Yes, we may consider discounts for bulk orders.
Q10: How much will the shipping charges be?
A: It depends on the size of your shipment and the method of shipping. We will offer the charge to you as you requested.
Q11: Can you do custom design products?
A: Yes, OEM & ODM service are available. We can customize the sizes, LED color and functional icons according to your requirements.
Q12: If I send my design, can you make it for myself only, and will not show it to anyone else?
A: Yes, we will not show it or sell to others without your authorization.
Q13: What will be the samples lead time for customized products?
A: Samples lead time will be about 20-25 working days after receiving mold cost and mold drawing approval from customers.
Q14: What is the shipping methods?
A: We usually ship the goods by DHL, FEDEX, UPS, EMS, BY AIR, BY SEA etc. You can also choose other methods that work best for you.
Q15: How do you ensure the quality of your products?
A: We are ISO 9001 QMS certified manufacturers with more than 20 years experience. We conduct twice 100% testing for all our products before shipment.
