White/Green Customized 7 Segment LED Display for Electric Scooter
White/Green Customized 7 Segment LED Display for Electric Scooter
White/Green Customized 7 Segment LED Display for Electric Scooter
White/Green Customized 7 Segment LED Display for Electric Scooter
White/Green Customized 7 Segment LED Display for Electric Scooter
White/Green Customized 7 Segment LED Display for Electric Scooter
Specifications
Warranty :
Three years
Compatibility :
Universal for electric scooters
Application :
Electric Scooter
Screen Size :
3.5 inches
Usage :
Indoor/Outdoor
Outer Dimension :
37*30*6mm
Diameter :
35mm
Display Type :
LED
Operating Temperature :
-10°C to 50°C
Trade Term :
ShenZhenEXW
Resolution :
320x240 pixels
Brand Name :
LIGHT-BO
Model Number :
LB6031AWRG3S-T2-D-JT
Certification :
ISO9001&RoHS
Place of Origin :
SHENZHEN，CHINA
MOQ :
1000
Price :
Negotiate
Payment Terms :
T/T,Western Union
Supply Ability :
20000pcs/days
Delivery Time :
15-20days
Packaging Details :
EPE+Carton
Display function :
Video,Graphics,Animation,Picture,Image
Material :
ABS Plastic
Connectivity :
Wired connection
Color :
White & Green
Forward Current :
20mA
Model :
custom model for optional
Weight :
150 grams
Description
White/Green Customized 7 Segment LED Display for Electric Scooter
Product Specifications
Product Name White/Green Customized 7-Segment LED Display for Electric Scooter Other color and configuration options available
Part Number LB6031AWRG3S-T2-D-JT Custom part number printing supported
Standard Color White & Green Also available in white, blue, pure green, yellow-green, orange, etc.
Polarity Common Anode Common Cathode option available
Lifespan 80,000 hours -
Free Samples Available -
Sample Lead Time 5-7 working days (standard samples)
15-20 working days (tooling samples)		 -
Production Lead Time 15-20 working days May vary depending on order quantity
OEM & ODM Supported Customization based on your drawings or ideas
LOGO Printing Supported According to your provided drawing or design
Minimum Order Quantity (MOQ) 1,000 PCS 100-500 PCS acceptable for initial orders
White/Green Customized 7 Segment LED Display for Electric Scooter
Key Features
  • High Luminous Efficiency: Operates at forward voltage with high-intensity output, ensuring brilliant and efficient performance
  • Low Power Consumption: Energy-saving operation with extremely low operating current
  • Uniform Illumination: Seamless visual consistency with evenly distributed brightness across all segments
  • Standard Sizing: Designed to fit seamlessly into your systems with industrial standard dimensions
  • High Reliability in Bright Light: Exceptional visibility and reliable performance in bright ambient conditions
  • Stable Performance: Consistent and unwavering reliability for long-lasting operational excellence
  • Long Lifespan: Crafted for durability with extended operational life, minimizing replacement needs
  • Environmental Compliance: Meets RoHS and REACH standards for environmentally responsible performance
Technical Parameters
Yellow Green (Code: J/JU)
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8 - 2.4 V
Reverse Voltage Vr Ir=10uA 5 - - V
Luminous Intensity Iv If=10mA 30 - 40 mcd
Spectrum Width Of Half Value △λ If=10mA - 20 - nm
Wavelength Dλ If=10mA 569 - 574 nm
Amber/Yellow (Code: Y)
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8 - 2.5 V
Reverse Voltage Vr Ir=10uA 5 - - V
Luminous Intensity Iv If=10mA 60 - 80 mcd
Spectrum Width Of Half Value △λ If=10mA - 20 - nm
Wavelength Dλ If=10mA 585 - 595 nm
Orange (Code: F)
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8 - 2.4 V
Reverse Voltage Vr Ir=10uA 5 - - V
Luminous Intensity Iv If=10mA 60 - 80 mcd
Spectrum Width Of Half Value △λ If=10mA - 20 - nm
Wavelength Dλ If=10mA 600 - 605 nm
Absolute Maximum Ratings (Ta=25ºC)
Parameter Symbol Ratings Unit
Forward Current (per dice) Ipm 20 mA
Reverse Voltage (per dice) Vr 5 V
Power Dissipation (per dice) Pm 80 mW
Operating Temperature Range Topr -40~+85 ºC
Storage Temperature Range Tstg -40~+85 ºC
Solder Temperature (≤3 seconds) Th 260 ºC
Company Profile

Shenzhen Guangzhibao Technology Co., Ltd. (BRAND: LIGHT-BO), established in 2006, symbolizes excellence in OEM and ODM services. As an ISO 9001:2015 certified leader, our legacy of over 15 years is marked by quality and innovation.

LIGHTBO propels clients to new heights with high-quality, cost-effective custom solutions, reducing expenses and fortifying competitive advantages globally.

Applications
White/Green Customized 7 Segment LED Display for Electric Scooter

Our innovative products find applications in home appliances, temperature and humidity indicators, refrigerator controllers, thermostats, and heating and cooling systems, showcasing our commitment to performance.

White/Green Customized 7 Segment LED Display for Electric Scooter White/Green Customized 7 Segment LED Display for Electric Scooter
Frequently Asked Questions
Q1: Are you trading company or manufacturer?
We are original manufacturer with more than 20 years experience in optoelectronic LED displays.
Q2: What is your main products?
Our main products include 7 Segment LED display, SMD LED Display, Dot matrix LED Display, Arrow LED display, Custom Design LED Display, LED light bar, Through hole led, SMD LEDs, LED Backlights, and more.
Q3: What is your MOQ?
Our MOQ is 1000 pcs. We can also accept sample orders and small orders with quantity less than our MOQ.
Q4: Before placing order, Can I get some samples for test?
Yes. We can provide 5-10 free samples for your testing, but the freight cost will be borne by the customer.
Q5: How long is your delivery time?
Delivery time: About 10-20 days; According to order quantity and raw materials. If you have urgent order and we have raw materials in stock, we can adjust our production plan to make it ready within 7-10 days.
Q6: What is your terms of payment?
We accept bank transfer, T/T, Western Union and Paypal with small amount. Details of payment methods can be negotiable.
