Specifications
Brand Name :
LIGHT-BO
Model Number :
LB20471LWH3B-D
Certification :
ISO9001&RoHS
Place of Origin :
Shenzhen, China
MOQ :
1000
Price :
Negotiate
Payment Terms :
T/T,Western Union,
Supply Ability :
20000 PCS/Day
Delivery Time :
10-15 days
Packaging Details :
EPE+CARTON
Digit Height :
12mm (0.47 inch)
Outer Dimensions (L×W×H) :
20.9 × 13.9 × 5.9mm
Luminous Intensity :
120-140 mcd
Packing :
EPE+Carton
Origin :
Shenzhen
Brandname :
LIGHT-BO
Description

Ultra Bright White 12mm (0.47-Inch) 2-Digit 7-Segment Common Cathode LED Display for Water Heater Temperature Control

Product Overview
Introducing the Ultra Bright White 12mm 2-Digit 7-Segment Common Cathode LED Display—a water heater-optimized numeric solution engineered for temperature controllers, home appliances, and compact digital indicators. Designed to prioritize clarity, heat resistance, and space efficiency, this 2-digit display excels at showing water heater temperatures (e.g., “45°C” for warm, “75°C” for hot) and other short-value metrics (e.g., “08” for appliance timer, “22” for room temp).
Its 12mm (0.47-inch) digit height ensures readability from 0.5–1.5 meters (typical distance for water heater control panels), while the 20.9×13.9×5.9mm form factor fits seamlessly into slim water heater enclosures—no bulky redesigns required. The yellow segments on a black surface create sharp contrast with ultra bright white light (120-140mcd), cutting through bathroom/utility room glare (e.g., overhead lights, steam fog) without eye strain.
With common cathode polarity, fast heat dissipation, and RoHS compliance, this display delivers reliable performance for 24/7 operation in water heaters (where heat and humidity are common) and other home appliances.


Product Image


Key Features (Water Heater Temperature Control-Optimized)
1. Superior Visibility for Water Heater Temps
Ultra Bright White Illumination (120-140mcd): Among the brightest in its class, it cuts through bathroom steam, utility room glare, or dim lighting—ensuring users can quickly check water temp (e.g., “50°C”) without squinting, even when the heater is mounted high on a wall.
Yellow Segments on Black Surface: The yellow segment base enhances contrast with the black background, eliminating “fuzzy” edges on digits (e.g., distinguishing “6” from “8”)—critical for avoiding scalds (e.g., mistaking “75°C” for “45°C”).
Wide Viewing Angle: Uniform light distribution ensures readability from off-center positions (e.g., glancing at the heater while filling a tub)—ideal for busy bathrooms or utility spaces.
2. Heat Resistance & Stable Performance
Fast Heat-Dissipation: Specialized design prevents heat buildup, even when the water heater runs at high temps (e.g., 80°C+) or is mounted near heating elements. Avoids brightness dimming or segment failure due to overheating.
Stable Operation in Humid/Hot Environments: Withstands temperature fluctuations (-10°C to 60°C, typical for bathrooms/utility rooms) and high humidity (steam from showers)—maintains consistent brightness, no flickering during temp updates.
Long Lifespan (50,000+ Hours): High-quality white LEDs and heat-resistant materials match the 8–10 year service life of most water heaters—eliminates frequent display replacements, reducing maintenance hassle for users.
3. Energy Efficiency & Easy Integration
Low Power Consumption (5-10mA/LED): Extremely low current draw minimizes energy use for water heaters (which run daily) and extends battery life for portable temperature indicators (e.g., handheld water temp meters).
Optimized Forward Voltage (2.8-3.2V/LED): Compatible with standard 5V/12V power supplies used in water heater controllers—no need for custom voltage converters, simplifying circuit design for manufacturers.
Common Cathode Polarity: Works with standard driver ICs (e.g., TM1637, HT1621) widely used in temperature controllers—integrates seamlessly with water heater firmware (e.g., temp sampling, heat-on/off triggers) without extra wiring.
Easy Assembly: Designed for PCB direct-mounting, compatible with automated production lines—speeds up water heater manufacturing and ensures consistent display alignment in control panels.
4. Versatility & Compliance
RoHS Compliant: Free from lead, mercury, and harmful substances—safe for home use (especially around water) and export to global markets (EU, North America, Asia), meeting water heater safety standards.
Multi-Scenario Use: Beyond water heaters, ideal for other 2-digit needs: small ovens (temp “200°C” → displays “20”), room thermostats (temp “25°C”), or coffee makers (brew temp “95°C”).

Technical Specifications

Category Parameter Specification (Water Heater-Optimized)
Basic Design Display Type 2-Digit 7-Segment LED Display (supports decimal points for precision temps)

Polarity Common Cathode

Digit Height 12mm (0.47 inch)

Outer Dimensions (L×W×H) 20.9 × 13.9 × 5.9mm

Segment/Surface Finish Yellow segments on Black Surface
Optical Performance Emitting Color Ultra Bright White

Luminous Intensity 120-140 mcd

Color Coordinate (X/Y) 0.29-0.31 (neutral white, no color bias)

Viewing Angle Wide (≥120° horizontal, ≥110° vertical)
Electrical Parameters Forward Voltage (VF) 2.8-3.2V per LED

Forward Current 5-10mA per LED

Power Consumption Low (energy-efficient for daily use)
Quality & Compliance Core Advantages Fast heat-dissipation, stable performance, wide viewing angle, easy assembly

Compliance RoHS Compliant


Applications
This display is purpose-built for water heaters and compact temp-controlled devices, including:
Water Heater Temperature Control: Electric/gas water heaters (showing “40°C”–“80°C”), tankless water heaters (real-time temp “55°C”), or under-sink water heaters (temp “60°C”).
Home Appliances: Small ovens (temp “180°C” → displays “18”), coffee makers (brew temp “95°C”), or electric kettles (heat level “03” → 80°C).
Temperature Controllers: Room thermostats (temp “22°C”), greenhouse mini-controllers (temp “25°C”), or aquarium heaters (temp “28°C”).
Instrument Panels: Portable temp meters (water temp “37°C”), battery chargers (charge “90%”), or fitness equipment (workout time “15”).


Why Choose This Display for Water Heaters?
Safe Temp Reading: Ultra bright light + high contrast prevent misreading hot temps—critical for avoiding scalds in bathrooms.
Heat & Humidity Resistance: Fast heat-dissipation and moisture tolerance handle water heater-specific harsh conditions, no premature failure.
Space-Saving Fit: Compact dimensions fit slim water heater enclosures—no need to enlarge existing designs.
Energy Efficiency: Low current use cuts water heater energy bills, aligning with eco-friendly home trends.
Easy Manufacturing: Common cathode polarity + standard size fit existing water heater PCBs—saves manufacturers redesign time.


Order & Logistics Information
Minimum Order Quantity (MOQ): 300 pieces for standard models; 500 pieces for customized variants (e.g., adjusted brightness).
Packing: Anti-static EPE + carton (each display is individually wrapped to protect segments and pins during shipping).
Delivery Time: 5–7 days for standard orders; 10–12 days for custom configurations.
Transport: Express (FedEx/DHL for urgent samples), Air (medium-volume shipments), Ocean (bulk production runs for water heater manufacturers).


Product Parameters

Absolute Maximum Ratings(Ta=25ºC)

Parameter Symbol Ratings Unit
Forward Current(per dice) Ipm 20 mA
Reverse Voltage(per dice) Vr 5 V
Power Dissipation(per dice) Pm 80 mW
Operating Temperature Range Topr -40~+85 ºC
Storage Temperature Range Tstg -40~+85 ºC
Solder Temperature(≤3 seconds) Th 260

ºC

Code:Yellow Green- J

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8
2.4 V
Reverse Voltage Vr Ir=10uA 5

V
Luminous Intensty Iv If=10mA 30
40 mcd
Spectrum With Of Half Value △λ If=10mA
20
nm
Wavelength Dλ If=10mA 569
574 nm


Code:Amber/Yellow -Y

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8
2.5 V
Reverse Voltage Vr Ir=10uA 5

V
Luminous Intensty Iv If=10mA 60
80 mcd
Spectrum With Of Half Value △λ If=10mA
20
nm
Wavelength Dλ If=10mA 585
595 nm


Code:Orange -F

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8
2.4 V
Reverse Voltage Vr Ir=10uA 5

V
Luminous Intensty Iv If=10mA 60
80 mcd
Spectrum With Of Half Value △λ If=10mA
20
nm
Wavelength Dλ If=10mA 600
605 nm


Code:Super Bright Red -R

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8
2.2 V
Reverse Voltage Vr Ir=10uA 5

V
Luminous Intensty Iv If=10mA 50
60 mcd
Spectrum With Of Half Value △λ If=10mA
20
nm
Wavelength Dλ If=10mA 630
635 nm


Code:Ultra Bright Red -UR

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8
2.2 V
Reverse Voltage Vr Ir=10uA 5

V
Luminous Intensty Iv If=10mA 80
100 mcd
Spectrum With Of Half Value △λ If=10mA
20
nm
Wavelength Dλ If=10mA 625
635 nm


Code:Pure Green -G

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 2.6
3.2 V
Reverse Voltage Vr Ir=10uA 5

V
Luminous Intensty Iv If=10mA 120
180 mcd
Spectrum With Of Half Value △λ If=10mA
20
nm
Wavelength Dλ If=10mA 515
525 nm


Code:Ultra Bright Blue -BH

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 2.8
3.2 V
Reverse Voltage Vr Ir=10uA 5

V
Luminous Intensty Iv If=10mA 120
140 mcd
Spectrum With Of Half Value △λ If=10mA
20
nm
Wavelength Dλ If=10mA 460
465 nm


Code:Ultra Bright White -WH

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 2.8
3.2 V
Reverse Voltage Vr Ir=10uA 5

V
Luminous Intensty Iv If=10mA 120
140 mcd
LED color Temperature K If=10mA 5500 20 6800 K
Chromaticity Coordinates
 X/Y If=10mA 0.29,0.32
0.30,0.33 nm
