Specifications
Brand Name :
LIGHT-BO
Model Number :
LB2638IWG1B
Certification :
ISO9001&RoHS
Place of Origin :
Shenzhen, China
MOQ :
1000
Price :
Negotiate
Payment Terms :
T/T,Western Union,
Supply Ability :
20000 PCS/Day
Delivery Time :
10-15 days
Packaging Details :
EPE+CARTON
Polarity :
Common Anode
LED Color :
White/Pure Green
Forward Voltage :
2.8-3.2V/LED
Forward Current :
5-10mA/LED
Packing :
EPE+Carton
Brandname :
LIGHT-BO
Description
High Brightness White / Pure Green Dual Line 7 Segment LED Display
Common Anode for Temperature Indicator
This dual-line 7-segment LED display offers high-brightness white and pure green illumination, specifically designed for temperature indicators, instrument panels, and dual-parameter readout applications. With a compact outline and stable performance, it provides clear, high-contrast display while maintaining ultra-low power consumption.
Product Features
  • High-luminous intensity output for excellent visibility even in strong ambient light
  • High electro-optical efficiency with low power consumption
  • Extremely low working current for long-term stable operation
  • Uniform luminous distribution across all segments for sharp, consistent display
  • Dual-line structure supports simultaneous dual-parameter readouts
  • Wide color selection supports customized indication schemes
  • Easy PCB mounting and assembly
  • Fully compatible with standard driver ICs
  • Reliable performance and long service life
Technical Specifications
Display Type Dual Line 7-Segment LED Display
Outer Dimensions 26 × 38 × 5 mm
Digit Height 0.67 inch (17 mm)
Polarity Common Anode
Standard Emitting Colors High brightness white, pure green
Optional Colors Red, yellow-green, amber; multiple colors available
Applications
Temperature indicators & controllers, dual-parameter measuring instruments, industrial control panels, household appliances digital displays, thermostats, humidity meters, and test equipment.
Absolute Maximum Ratings (Ta=25°C)
Parameter Symbol Ratings Unit
Forward Current (per dice) Ipm 20 mA
Reverse Voltage (per dice) Vr 5 V
Power Dissipation (per dice) Pm 80 mW
Operating Temperature Range Topr -40~+85 °C
Storage Temperature Range Tstg -40~+85 °C
Solder Temperature (≤3 seconds) Th 260 °C
Electrical & Optical Characteristics by Color Code
Yellow Green - J
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8 2.4 V
Reverse Voltage Vr Ir=10uA 5 V
Luminous Intensity Iv If=10mA 30 40 mcd
Wavelength Dλ If=10mA 569 574 nm
Amber/Yellow - Y
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8 2.5 V
Luminous Intensity Iv If=10mA 60 80 mcd
Wavelength Dλ If=10mA 585 595 nm
Orange - F
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8 2.4 V
Luminous Intensity Iv If=10mA 60 80 mcd
Wavelength Dλ If=10mA 600 605 nm
Super Bright Red - R
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8 2.2 V
Luminous Intensity Iv If=10mA 50 60 mcd
Wavelength Dλ If=10mA 630 635 nm
Ultra Bright Red - UR
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 1.8 2.2 V
Luminous Intensity Iv If=10mA 80 100 mcd
Wavelength Dλ If=10mA 625 635 nm
Pure Green - G
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 2.6 3.2 V
Luminous Intensity Iv If=10mA 120 180 mcd
Wavelength Dλ If=10mA 515 525 nm
Ultra Bright Blue - BH
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 2.8 3.2 V
Luminous Intensity Iv If=10mA 120 140 mcd
Wavelength Dλ If=10mA 460 465 nm
Ultra Bright White - WH
Parameter Symbol Condition Min Typ Max Unit
Forward Voltage Vf If=10mA 2.8 3.2 V
Luminous Intensity Iv If=10mA 120 140 mcd
LED Color Temperature K If=10mA 5500 20 6800 K
Manufacturer Information
SHENZHEN GUANGZHIBAO TECHNOLOGY CO., LTD. (BRAND: LIGHT-BO)
Established in 2006, we are an ISO 9001:2015 Quality Management Systems certified company that integrates R&D, manufacturing and sales of optoelectronics LED displays. With more than 15 years OEM and ODM experience.
LIGHTBO has been committed to provide high quality and low cost customized solutions to help customers reduce cost and enhance competitiveness.
Products Applications
High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator
7 Segment LED Display, Customized LED Display, Numeric LED Display, Dot matrix LED Display, widely used for home appliances, temperature indicators, humidity indicators, refrigerator controller, thermostats indicator, heating and cooling control and so on.
Certifications
High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator
Office and Factory Overview
High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator
Company Exhibitions
High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator
Shipping Services
High Brightness White /Pure Green Dual Line 7 Segment LED Display Common Anode for Temperature Indicator
Frequently Asked Questions
Q1: Are you trading company or manufacturer?
A: We are original manufacturer with more than 20 years experience in optoelectronic LED displays.
Q2: What is your main products?
A: Our main products include 7 Segment LED display, SMD LED Display, Dot matrix LED Display, Arrow LED display, Custom Design LED Display, LED light bar, Through hole led, SMD LEDs, LED Backlights, and so on.
Q3: What is your MOQ?
A: Our MOQ is 1000 pcs. We can also accept sample orders and small orders with quantity less than our MOQ.
Q4: Before placing order, Can I get some samples for test?
A: Yes. We can provide 5-10 free samples for your testing, but the freight cost will be borne by the customer.
Q5: How long is your delivery time?
A: Delivery time: About 10-20 days; According to order quantity and raw materials. If you have urgent order and we have raw materials in stock, we can adjust our production plan to make it ready within 7-10 days.
Q6: What is your terms of payment?
A: We accept bank transfer, T/T, Western Union and Paypal with small amount. Details of payment methods can be negotiable.
Q7: Can you quote me FOB prices?
A: Yes. We can quote you prices based on incoterms EXW, FOB, CIF, DDP.
Q8: How can I get your catalogue and price list?
A: Yes. Please let us know your email address or contact us from website directly for our catalogue and price list.
Q9: Can I negotiate the prices?
A: Yes, we may consider discounts for bulk orders.
Q10: How much will the shipping charges be?
A: It depends on the size of your shipment and the method of shipping. We will offer the charge to you as you requested.
Q11: Can you do custom design products?
A: Yes, OEM & ODM service are available. We can customize the sizes, LED color and functional icons according to your requirements.
Q12: If I send my design, can you make it for myself only, and will not show it to any one else?
A: Yes, we will not show it or sell to others without your authorization.
Q13: What will be the samples lead time for customized products?
A: Samples lead time will be about 20-25 working days after receiving mold cost and mold drawing approval from customers.
Q14: What is the shipping methods?
A: We usually ship the goods by DHL, FEDEX, UPS, EMS, BY AIR, BY SEA etc, also you can choose the other way that best for you.
Q15: How do you ensure the quality of your products?
A: We are ISO 9001 QMS certified manufacturers with more than 20 years experience. We conduct twice 100% percent test for all of our products before shipment.
