Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Specifications
name :
Interior RGB Dot Matrix Led Display
Description :
Long lifespan,Meet RoHS
Place of Origin :
Shenzhen,China
Brand Name :
LIGHTBO
Price :
Negotiable
Packaging Details :
EPE+CARTON
Delivery Time :
10-15Days
Payment Terms :
TT in advance& Western Union
Model Number :
LB03574BR1B
Certification :
RoHS&SGS&ISO
MOQ :
1000PCS
Supply Ability :
50000PCS/Day
Applications :
Can display numbers, letters, graphics images
Advantage :
Cost-competitive,Stable performance
Description
Ultra Red Dot Matrix LED Display 5x7 22 x 30 x 10 mm For Lift Position
High brightness Ultra Red Dot Matrix LED Display 5x7 22 x 30 x 10 mm For Lift Position
Quick Details
  • Square Dot matrix LED display
  • Dot size: 3.39mm × 3.9mm
  • Dimensions: 22 × 30 × 10 mm
  • Row Anode Column Cathode
  • Ultra Bright Red
  • Big viewing angle
  • Stable quality and performance
  • For elevator floor number indicators, lift position indicators
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Technical Specifications
Dot Diameter 5mm
Dimensions 34.1 × 45.5 × 12mm
Construction White diffused epoxy black face
Configuration Row cathode column anode
Emitting Color (Standard) Ultra bright red
Wavelength 620-625nm
Luminous Intensity 70-80mcd/LED
Forward Voltage 1.8-2.3V/LED
Recommended Forward Current 10-15mA
Available Colors Red, blue, yellow green, pure green, pure white, orange, yellow, and amber
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Product Description
Dot matrix LED displays are designed with advanced features for optimal performance:
  • High brightness produced by high luminous LED dice
  • Low current operation
  • Low power consumption
  • Stable quality and performance
  • Excellent dot uniformity
  • Wide viewing angle
  • Fast heat dissipation
  • Long lifespan
  • Easy mounting on PC boards and sockets
  • IC Compatible
  • Meet RoHS standards
  • Colors available: red, green, blue, white, amber, orange, bi-color, RGB
  • Character height available from 17.8mm (0.7") to 106.5mm (4.2")
Applications
  • Can display numbers, letters, graphics images
  • Message board
  • Moving signs
  • Lift / elevator floor number indicators, position indicators
  • Indoor and outdoor advertising screen
  • Interest rate screens
  • Time clock
  • Information display screen
  • Queue management systems
  • Traffic message
  • Video display board
  • Stadium video display
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Competitive Advantages
  • Can display various contents
  • Stable performance
  • Low cost
  • Low power consumption
  • Long lifespan
  • Easy assembly
  • High brightness
  • Wide viewing angle
  • Various sizes and colors available
  • No MOQ requirement
  • Prompt delivery
  • Stable quality
  • Cost-competitive pricing
  • Excellent service
  • OEM & ODM services available
Company Information
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Company Exhibition
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Certifications
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Shipping Methods
Ultra Bright Red 5x7 Dot Matrix LED Display 22x30x10mm Row Cathode Column Anode for Lift Floor Indicator
Frequently Asked Questions
Q1: Are you a trading company or manufacturer?
A: We are original manufacturers with more than 20 years of experience in optoelectronic LED displays.
Q2: What are your main products?
A: Our main products include 7 Segment LED display, SMD LED Display, Dot matrix LED Display, Arrow LED display, Custom Design LED Display, LED light bar, Through hole LED, SMD LEDs, LED Backlights, and more.
Q3: What is your MOQ?
A: Our MOQ is 1000 pcs. We can also accept sample orders and small orders with quantity less than our MOQ.
Q4: Before placing an order, can I get some samples for testing?
A: Yes. We can provide 5-10 free samples for your testing, but the freight cost will be borne by the customer.
Q5: How long is your delivery time?
A: Delivery time: About 10-20 days; according to order quantity and raw materials. If you have an urgent order and we have raw materials in stock, we can adjust our production plan to make it ready within 7-10 days.
Q6: What are your terms of payment?
A: We accept bank transfer, T/T, Western Union and PayPal for small amounts. Details of payment methods are negotiable.
Q7: Can you quote me FOB prices?
A: Yes. We can quote prices based on incoterms EXW, FOB, CIF, DDP.
Q8: How can I get your catalogue and price list?
A: Please let us know your email address or contact us from our website directly for our catalogue and price list.
Q9: Can I negotiate the prices?
A: Yes, we may consider discounts for bulk orders.
Q10: How much will the shipping charges be?
A: It depends on the size of your shipment and the method of shipping. We will provide the charge to you as requested.
Q11: Can you do custom design products?
A: Yes, OEM & ODM services are available. We can customize the sizes, LED color and functional icons according to your requirements.
Q12: If I send my design, can you make it exclusively for me and not show it to anyone else?
A: Yes, we will not show it or sell to others without your authorization.
Q13: What is the samples lead time for customized products?
A: Samples lead time will be about 20-25 working days after receiving mold cost and mold drawing approval from customers.
Q14: What are the shipping methods?
A: We usually ship goods by DHL, FEDEX, UPS, EMS, BY AIR, BY SEA, etc. You can also choose other methods that work best for you.
Q15: How do you ensure the quality of your products?
A: We are ISO 9001 QMS certified manufacturers with more than 20 years of experience. We conduct twice 100% testing for all our products before shipment.
