Specifications
Touchscreen type :
Projected Capacitive Touch screen
Onboard interface :
1 X RJ45, 2 X HDMI, 4 X USB2.0
Discrete Graphics card :
12GB GIGABYTE 4070
Input Voltage :
AC 100~240V, 50hz-60hz
MOQ :
1
Touch points :
10 points
Brand Name :
ZXTLCD
Price :
negotiable
Packaging Details :
wooden case, carton, flight cases are optional
Built-in wifi :
150Mbps 802.11n wifi integate
Payment Terms :
L/C,T/T,MoneyGram,Western Union
OS :
Android or Windows optional
Model Number :
ZXTLCD-OLED-T30-QP6A
Place of Origin :
Guangdong, China
Protype :
Desktop / Floor standing / Interactive(Optional)
Supply Ability :
2000 pcs per month
Type of backlight :
Transparent OLED
Screen Size :
30 inch
Certification :
CE/Rohs/FCC
Delivery Time :
3-5 working days
Description

30 Inch Ultra-Thin Transparent OLED Touch Screen Display for Smart Digital Signage and Interactive Commercial Use


Advanced Transparent OLED Display for Modern Business Applications


The 30 Inch Ultra-Thin Transparent OLED Touch Screen Display is a next-generation digital signage solution designed for retail stores, exhibitions, museums, corporate lobbies, and smart commercial environments. As a high-performance transparent OLED display, it combines self-emissive OLED technology with touch interaction, enabling digital content to appear as floating visuals while maintaining visibility of real-world objects behind the screen.


Unlike traditional LCD signage, this transparent OLED screen delivers superior contrast, deep blacks, and vivid colors without the need for a backlight, creating a futuristic and highly engaging visual experience for customers and visitors.



30-inch desktop splicing transparent device(ZXTLCD-T30-QP6A)
LCD Panel Parameters
Screen Size 30 inch
Panel type Transparent OLED
Resolution 1366*768
Brightness 200-600cd/ Automatic adjustment
Contrast Ratio 135000:1
Viewing angle(up/down/left/right) 178°/178
Onboard interface
Input Interface USB*1(Touch) + HDMI*1 +TYPE-C(powered by)
Output interface Camera + Microphone
Touch Method
Capacitive Touch screen Default 10 points Capacitive Touch
Power Specifications
Power supply DC 20V
Total System Power Consumption 40W
Machine Operating Parameters
running time 7*12h
Screen life 30000h
Operating temperature 0~40
Operating Humidity 20%~80%
structure
Material Tempered Glass+Metal
external dimensions 682*147*424 (mm)
Overall dimensions 800*260*560mm(Honeycomb box, subject to the actual product)
Installation Method Desktop base
Net weight / Gross weight 8.5KG/12.7KG(Honeycomb box)
Accessories
Power cord, HDMI port, USB port, remote control, certificate of conformity and warranty card, instruction manual
other
After-Sales Service 1-Year Warranty


Designed for Interactive Commercial Display Systems


Ultra-Thin Design for Seamless Integration


The ultra-thin structure of this display allows it to be easily integrated into desktop showcases, retail counters, exhibition cabinets, and custom brand installations. Its minimalist frameless appearance ensures that the focus remains on both the product and the digital content, enhancing the overall presentation quality in premium environments.


Capacitive Touch for Interactive Engagement


Equipped with responsive multi-point capacitive touch technology, the display enables users to interact directly with digital content. This makes it ideal for product browsing, interactive catalogs, brand storytelling, and customer self-service applications in retail and exhibition scenarios.


High-Performance OLED Technology from a Professional Manufacturer


As a professional OLED display manufacturer, the product is built with stable commercial-grade components to support long-term operation in demanding environments. The self-luminous OLED panel ensures fast response time, wide viewing angles, and consistent image quality.

The transparency feature allows physical objects placed behind the screen to remain visible, creating a layered presentation style that significantly enhances product visibility and marketing impact.


30 Inch Ultra-Thin Transparent OLED Touch Screen Display for Smart Digital Signage and Interactive Commercial Use


Applications of Transparent Digital Signage


This transparent digital signage solution is widely used in:

  • Luxury retail stores and flagship showrooms
  • Jewelry and cosmetics display counters
  • Museum and cultural exhibition spaces
  • Corporate reception and lobby displays
  • Trade show booths and exhibition stands
  • Smart retail interactive kiosks
  • Technology demonstration centers
  • Brand marketing and product launch events


Frequently Asked Questions


What is a transparent OLED display used for?


A transparent OLED display is used to combine digital content with physical objects, allowing both to be viewed simultaneously for immersive commercial presentations.


Does the display support touch interaction?


Yes, it supports multi-point capacitive touch for interactive applications such as product browsing and digital catalog navigation.


Is OLED better than LCD for transparent displays?


Yes. OLED is self-emissive, meaning it does not require a backlight, allowing higher contrast, better transparency control, and more realistic floating visual effects compared to LCD technology.


Can this display be customized?


Yes. As an experienced OLED display manufacturer, customization options include size, touch function, enclosure design, operating system, and branding integration.


30 Inch Ultra-Thin Transparent OLED Touch Screen Display for Smart Digital Signage and Interactive Commercial Use


Conclusion


The 30 Inch Ultra-Thin Transparent OLED Touch Screen Display delivers a powerful combination of transparency, interactivity, and ultra-thin design. It is an ideal solution for businesses looking to upgrade their transparent digital signage strategy and create modern, high-impact visual experiences that attract and engage customers.


30 Inch Ultra-Thin Transparent OLED Touch Screen Display for Smart Digital Signage and Interactive Commercial Use




30 Inch Ultra-Thin Transparent OLED Touch Screen Display for Smart Digital Signage and Interactive Commercial Use

30 Inch Ultra-Thin Transparent OLED Touch Screen Display for Smart Digital Signage and Interactive Commercial Use

30 Inch Ultra-Thin Transparent OLED Touch Screen Display for Smart Digital Signage and Interactive Commercial Use
