Specifications
Type of backlight :
OLED self-luminous
Certification :
CE/Rohs/FCC
Screen Size :
55 inch
Viewing Angle :
178 °, 178 °
Onboard interface :
1 X RJ45, 2 X HDMI, 4 X USB2.0
Built-in wifi :
150Mbps 802.11n wifi integate
Packaging Details :
wooden case, carton, flight cases are optional
Input Voltage :
AC 100~240V, 50hz-60hz
Brand Name :
ZXTLCD
Audio system :
Built-in 10 W X 2 Speakers
Delivery Time :
3-5 working days
Model Number :
ZXTLCD-OLED055H002
MOQ :
1
Payment Terms :
L/C,T/T,MoneyGram,Western Union
Panel transparency :
43%
Price :
negotiable
Supply Ability :
2000 pcs per month
Contrast ratio :
8ms
Protype :
Desktop / Floor standing / Interactive(Optional)
Place of Origin :
Guangdong, China
Description

Double Sided 55-inch hanging vertical screen transparent oled screen High Brightness 2500nits for Shopping Mall


Premium Double-Sided Transparent OLED Display for Modern Retail Environments


The Double-Sided 55 Inch Hanging Transparent OLED Display is a cutting-edge commercial solution designed for shopping malls, luxury retail stores, airports, exhibition halls, and brand showrooms. Featuring a suspended vertical structure and dual-sided screen configuration, it delivers dynamic advertising content from both directions while maintaining a futuristic transparent visual effect.


As a professional OLED display manufacturer, we specialize in advanced transparent OLED display technology that combines high brightness, ultra-thin design, and immersive visual performance. This model is engineered for high-traffic commercial spaces where visibility and impact are essential.


Dual-Sided Transparent OLED Screen with High Brightness


2500 Nits High Brightness Performance


This transparent OLED screen is designed for environments with strong ambient lighting, ensuring clear and vibrant visibility even in open commercial spaces such as shopping malls and storefront atriums.

Key features include:


  • 55-inch dual-sided transparent OLED panel
  • High brightness up to 2500 nits (enhanced visibility)
  • 1920 × 1080 Full HD resolution
  • Self-emissive OLED technology (no backlight required)
  • Ultra-wide viewing angle (178°)
  • High contrast ratio with vivid color reproduction

The double-sided design allows simultaneous content playback in both directions, maximizing advertising exposure and customer engagement.


screen parameters

Panel size

55 inches.

Panel type

OLED

display area

1209.6 X 680.4mm

external dimensions

1221.5Mm × 699.35mm × 1.78mm (width × height × thickness)

transmittance

43%

viewing angle

178 °, 178 °

static contrast

100000:1 (Typ.) Transmission

Dynamic Contrast

200000:1 (Typ.) Transmission

patchwork

Unilateral 5.9mmm, bilateral 12mm, overall unilateral stitching 5.9/5 9/5.9/13 (left/right/top/bottom)

screen scale

16:9

brightness

200-600 (nits)

Best resolution

1920*1080

Screen life

≥ 30000 hours

power

≤ 190W

Display color

10-Bit, 1.07B (1B = 1 billion)

Speaker

8Ω/5W * 2

screen gross weight

Screen weight 2.4kg

Gross weight of the whole machine

to be determined

environment

Working temperature 1 ℃~ 45 ℃

working humidity

30%~80%

running time

18 hours x 7 days

Ambient height

(Altitude) 0~ 5000m

response time

8ms

working voltage

100V-240VAC, 50/60Hz

Fitting method

frame sticker

Fitting method (optional)

Full fit

Driver Board

input interface

HDMI IN

USB

USB 2.0

DP

DP IN

weight

0.4Kg

Control signal IN

RS232 serial port (RJ45)

Control signal OUT

RS232 serial port (RJ45)

function

With splicing function

protect

Anti-afterimage, anti-burn, repair function

Touch screen parameters: infrared optional

touch technology

Infrared touch technology

positioning accuracy

2.5Mm

Installation method

Built-in integrated

writing method

Finger ≥ 5mm

touch points

10 touch writing

Writing screen medium

5-8Mm tempered high-transparency glass, subject to the drawings

response speed

≤ 5ms

computer driven

drive-free

mode of communication

USB

service life

≥ 60 million times

Touch screen parameters: capacitance optional

touch technology

Capacitive touch technology

positioning accuracy

3Mm

Installation method

Built-in integrated

writing method

Finger ≥ 5mm

touch points

10 touch writing

Writing screen medium

5-8Mm tempered high transparency glass

response speed

≤ 5ms

computer driven

drive-free

mode of communication

USB

service life

≥ 60 million times

PC configuration (optional)

main board

Intel Core

CPU

4th generation/6th generation/7th generation/8th generation/10th generation - Core i3/i5/i7 (optional)

Memory

4G/8G/16G-DDR3 (optional)

Hard disk

SSD120G/240G/480-HDD500G/1T/2T (optional)

nuclear display

Intel HD Graphics 4000

Backplane I/O

1 × DC_IN power interface, 1 × HDMI interface, 1 × VGA interface, 2 × USB3.0 interface, 1 × LAN_RJ interface, 2 × USB2.0 interface, 1 × Mic (input), 1 × PHONE (output)

Operating System

Win 7/Win 10 operating system

Android configuration (optional)

Main board model

3568/3288/3588

Memory

2G/4G/8G optional

storage

16G/32G/64G/128G optional

interface

1 × USB2.0, 1 × USB3.0, 1 × DC_IN, 1 × HDMI_OUT, 1 × LAN_RJ, 1 × WIFI, 1 × 3.5 headphone socket, 1 × TFT socket

Packing and packing list

Package size

Honeycomb box: 85 * 9 * 135CM

Air box:/

Weight information

Bare metal weight: 58KG

Packing weight (bare metal + honeycomb box): 68KG

name

With PC/Android

Specifications

quantity

Remarks

transparent display

55 inch OLED transparent screen

1 piece

system

Customized according to actual needs (built-in)

1 set

remote control

Universal version (without battery)

1

Power cord

National standard 1.5 meters

Article 1

HDMI extension cable Note ②

optional

Article 1

Touch the USB extension cable Note ②

optional

Article 1

HDMI signal cable Note ②

optional

Article 1

Warranty card certificate

Chinese version

1 sheet

Note: HDMI extension cable, HDMI cable and touch USB extension cable are optional items. The final packing list is subject to the actual shipment of the customer. You can choose whether to configure the extension cable according to customer needs. Note that the selection will incur corresponding costs. Please confirm the price for shipment.


OEM & ODM Support from OLED Display Manufacturer


As an experienced OLED display manufacturer, we provide complete OEM and ODM customization services for global clients.


Customization options include:

  • Hanging structure design and dimensions
  • Brightness adjustment and display calibration
  • Android or Windows system integration
  • Content management system (CMS) support
  • Logo branding and cabinet design
  • Touch and interactive function upgrades

We support B2B partners, distributors, and system integrators with full technical and manufacturing support.


FAQ


What is a double-sided transparent OLED display?


It is a commercial display that shows content on both front and back sides using transparent OLED technology, allowing visibility through the screen while displaying digital content.


Is this transparent OLED display suitable for bright environments?


Yes. With up to 2500 nits high brightness, it is designed for well-lit environments such as shopping malls, airports, and storefronts.


Can the display be customized?


Yes. As an OLED display manufacturer, we offer OEM/ODM services including size, structure, system configuration, and branding customization.


What is the advantage of transparent digital signage?


Transparent digital signage allows dynamic advertising content to be displayed while maintaining visibility of the background, creating a futuristic and engaging visual experience.


Double Sided 55-inch hanging vertical screen transparent oled screen High Brightness 2500nits for Shopping Mall


The 55 Inch Double-Sided Hanging Transparent OLED Display is a powerful transparent OLED display solution designed for modern commercial advertising. With its high brightness, dual-sided visibility, and innovative suspended structure, it delivers unmatched performance in transparent digital signage applications. Ideal for retail, transportation hubs, and exhibition environments, it helps brands maximize visibility and customer engagement while maintaining a premium visual experience.
