17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-RM170SW
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C,T/T,MoneyGram,Western Union
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight cases are optional
Screen Size :
17 inch
Operating Temperature :
0°C to 50°C
Power Supply :
AC 100~240V, 50hz-60hz
Panel type :
BOE Original A+ Grade IPS
Resolution :
1920 X 1080
Brightness :
350cd/m²
View Angle :
178°/178° (H/V)
Power Consumption :
80W
Cabinet material :
Metal case + Glass
Touch Screen :
10-point capacitive touch screen
NFC Reader/scanner/QR reader :
Support, built-in
80mm Thermal Printer :
Support, built-in
Passport Scanner :
Optional
POS terminal installation :
Resever space
Application :
Hospitality, hotel and catering
Protype :
Desktop / Floor standing /wall mounted(Optional)
Description

17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors


Rugged Display Monitors: "Customization on Demand" as the Core

The Rugged Display Monitors breaks the limitations of standardized equipment with "customization on demand" as its core principle, providing precisely tailored embedded solutions for smart warehouses, medical equipment, outdoor terminals, and other scenarios. It redefines the "invisible brain" of industrial equipment through flexibility and reliability.


17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors

Full-Size Coverage and Lightweight Design

Supports full-range size customization from 10.4 to 21.5 inches. The body adopts an aviation-grade aluminum-magnesium alloy frame, with rounded bezels and curved side panels reducing the overall thickness to 45mm—30% lighter than traditional models.


A fanless architecture combined with a 3D airflow guide ensures core temperature remains ≤50°C even in dusty ceramic kiln workshops through multi-layer dust filters, guaranteeing 7×24 silent operation.


17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors

Ten Military-Grade Tests and Scenario Empowerment

Each unit undergoes pre-delivery testing including:

Environmental Tests: -30°C freezing/85°C high-temperature baking, automotive-grade random vibration (5-500Hz)

Performance Tests: 72-hour full-load aging, 4KV electrostatic discharge, 1.5-meter drop

Interaction Tests: Million-touch clicks, glove/wet-hand mode verification

This enables adaptation to:

Medical Equipment: 12.1-inch narrow-bezel version seamlessly integrates into blood analyzers, resisting disinfectant splashes

Outdoor Terminals: 19-inch wide-temperature version (-40°C~75°C) for polar research station data collection

Smart Warehouses: 15.6-inch dust-proof version with integrated RFID, enduring high-dust environments in logistics sorting centers

17 inch Building Embedded All-in-one High-definition LCD Display Intelligent Advertising Rugged Display Monitors

Agile Development and Hardware-Software Synergy

Pre-installed with Linux/Windows IoT systems, supporting:


Protocol Compatibility: Plug-and-play Modbus/Profinet protocol libraries for seamless PLC and robot integration


Edge Computing: Open Python/C++ SDK for rapid deployment of AI quality inspection and energy consumption prediction algorithms


Deep Customization: Supports power-on auto-start, application whitelist locking, and private boot screen customization


For example, customized machines for nucleic acid testing booths can pre-install code verification and data encryption modules, completing system deployment in 1 hour.


LCD Panel Parameters Screen Size 17 Inch
Display Area 337.92 mm.(Height) X 270.3(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1280 X 1024
Display Color 16.7M , 72% NTSC
Brightness 250cd/m²
Contrast Ratio 1200 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 20ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Audio parameters Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Internal computer configuration
(Choose one of two)		 CPU i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics Card Integrated Graphics Card Intel® HD 4600 Integrated Graphics Card Intel® HD 530
RAM 4GB 8GB
Storage Memory Capacity 128GB 256GB
OS Win10 or win11 Optional Win10 or win11 Optional
Wi-Fi Built-in Speed 150Mbps 802.11n wifi Integrated Speed 150Mbps 802.11n wifi Integrated
Media Format Video Format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio Format MP3, WMA
Photo Format BMP, JPEG, PNG, GIF etc.
Onboard Interface Network port RJ45 X 1, 10M/100M Adjustable Ethernet
HDMI 1
USB 4
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 30 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0℃ ~ 50℃
Storage Temperature Below 10℃ ~ +60℃
Package Size Device Dimensions 385 X 317 X 51.7mm.
Net Weight 5.5 Kilogram
Package Size 44.3 X 38 X 10.5Centimeter
Gross Package Weight per Unit 6 Kilogram


if you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
