Structural Design of the Industrial Touch Panel PC

Utilizing high-strength 6061 aluminum alloy and a one-piece stamping process, the frame and rear shell are seamlessly connected, reducing weight by 40% compared to traditional sheet metal structures while enhancing impact resistance and electromagnetic shielding capability (30dB attenuation).

The device is IP65 certified and features Mohs 6-level tempered glass on the surface. Combined with full lamination technology, it achieves a 0.1mm-level gap seal, effectively resisting challenges such as disinfectant splashing in operating rooms and metal dust intrusion in automotive production lines.

Industrial-Grade Performance of the Industrial Touch Panel PC

Equipped with a 13.3-inch industrial A-grade IPS hard screen, it supports 1920×1080 resolution and 450 nits of high brightness, with a static contrast ratio of 1500:1. This ensures clear visibility in high-light scenarios such as outdoor self-service terminals and shadowless surgical tables. The wide-temperature design supports stable operation from -30°C to 70°C (expandable to -40°C to 85°C) and has passed a 72-hour high-temperature and high-humidity cycle test, making it suitable for extreme environments like cold chain storage and outdoor equipment in equatorial regions.

Intelligent System and Deep Customization

The device features a self-developed 6-layer industrial PCB motherboard, supporting 100-240V wide-voltage input and tolerating voltage fluctuations of ±30%. Its EMC anti-interference capability meets industrial Level 4 standards.

Pre-installed with Android 12, it offers open APK secondary development interfaces and supports boot screen customization, application auto-start, and data encryption functions. Modular expansion slots are available for integration in various scenarios:

Medical Scenarios: Sterilizable housing, capacitive stylus

Logistics Scenarios: RFID high-frequency reader, 4G communication module

Industrial Scenarios: PROFINET bus interface, anti-vibration bracket
