Specifications
Brand Name :
ZXTLCD
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T,MoneyGram,Western Union
Supply Ability :
2000 pcs per month
Delivery Time :
15 working days
Packaging Details :
wooden case, carton, flight cases are optional
Model Number :
ZXTLCD-IFP105CTP
Screen Size :
105 inch
Brightness :
400cd/m²
Resolution :
5120*2160 , 5K
View Angle :
178°/178° (H/V)
Color :
16.7M
Response time :
8 ms
Fresh Frequency :
120 Hz
Surface Glass (Optional) :
Fingerprint-resistant, protective glass with anti-glare surface
Touch Technology :
PCAP touch screen
Touch Points :
10points
Audio system :
Built-in 15 W X 2 Speakers
Language :
3000 : 1
Built-in wifi :
150Mbps 802.11n wifi integate
OS :
Android 12.0
CPU :
Octa-core Cortex-A73,2.8GHz
GPU :
ARM Mali-G52 MC6
RAM :
8G
SSD :
128G
Power Supply :
AC 100~240V, 50hz-60hz
OPS Slot :
Available
Max power consumption :
≤350W【OPS not included】
Standby :
≤0.5W
Protype :
Floor standing /wall mounted(Optional)
Description

105 inch 5K Interactive Display large screen interactive teaching capacitive touch whiteboard

The 105 inch 5K Interactive Display breaks through the traditional 16:9 screen ratio limitation, featuring a 21:9 ultrawide screen with 5K ultra-high-definition picture quality, bringing a wider visual immersion and more freedom of image expression. Its large display area supports multi-window parallel display, easily realizing multi-task split-screen collaboration, and significantly improving information processing efficiency across teams and multiple scenarios.

105 inch 5K Interactive Display large screen interactive teaching capacitive touch whiteboard

A Powerful Tool for Digital Training and Education

Corporate Training : The 105-inch touch teaching all-in-one machine is an ideal tool for corporate training. Employees can engage in interactive training, quickly adapt to their roles, and improve overall training effectiveness, indirectly contributing to future work outcomes.

Business Meetings : During meetings, this all-in-one machine can be used to display reports, statistical data, and facilitate discussions, eliminating the need for additional meeting facilities and improving meeting efficiency.

Teaching and Training : Teachers can use the conference all-in-one machine for remote teaching, quickly present key course content to students, and encourage student interaction with the screen, helping to deepen their understanding of the course material.

Product Demonstrations : Products can be displayed intuitively on the large screen, and users can touch the screen to explore product features in detail, enhancing all employees' understanding of the products.

105 inch 5K Interactive Display large screen interactive teaching capacitive touch whiteboard

105 inch 5K Interactive Display large screen interactive teaching capacitive touch whiteboard

Functional Advantages of the 105-Inch Touch Teaching All-in-One Machine

Large Screen: The 105-inch large screen provides clearer images and a larger viewing area, suitable for various meetings, training sessions, and teaching activities.

Touchscreen Technology: Through touchscreen technology, users can interact, annotate charts and documents, and foster deeper understanding.

Multimedia Support: Supports multiple media formats, including video, audio, and images, making content more engaging.

Remote Collaboration: Equipped with remote collaboration features, enabling employees to share and collaborate on files from different locations.

105 inch 5K Interactive Display large screen interactive teaching capacitive touch whiteboard

Ease of Use: Simple to operate, requiring no additional training to utilize its powerful functions.

Efficiency: Significantly improves the efficiency of corporate training and meetings, making it easier for employees to understand and absorb information.

Flexibility: Suitable for various scenarios, saving time and costs. It can also build smart spaces through the expansion interfaces of the conference teaching all-in-one machine, creating personalized applications that integrate with other smart devices.

Collaboration: Remote collaboration features promote teamwork, regardless of where employees are located.

105 inch 5K Interactive Display large screen interactive teaching capacitive touch whiteboard

The Specification of 105 inch 21:9 with PCAP touch Android All In One PC
LCD Panel Parameters Screen Size 105 inch
Screen Brand BOE
LCD Panel Model BOE-UVA05CLB-N10
Backlight LED
Resolution 5120*2160
Brightness(typ)/(min) 400(Max)
Contrast ratio(typ)/(min) 1200 : 1
Response Time (typ)/(min) 8ms (Typ.)
Dot Pitch(Unit:um) 211.5(H) × 634.5(V)
Field Frequency 120Hz
Viewing angle H 178°,V 178°
LCD Panel Life (typ)/(min) 50000h
Color Saturation (x% NTSC) 68%
Display area 2449.9(H) × 1033.6(V)
Display color 16.7M
Touchscreen Panel Parameters Touch style Projected Capacitive Touch screen Technology, supports 10 points
Cover Glass Optically bonded 4mm glass for low parallax
Physical toughened Morse magnitude 7 explosion-proof
The glass transmittance >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88%
Response speed < 6ms
Accuracy of touch More than 90% of the touch area ±2mm
Touch ways Fingers, touch pen
Output format The coordinate output
Clicks time Unlimited
The smallest touch size 5mm
Light resistance Yes available
OSD Language Chinese/Traditional Chinese/ English/Japanese/French/Russian/German/Portuguese/Spanish
Buit-in Android PCB Board Configuration CPU Main chip Cortex-A73
Working frequency 2.8GHz
Number of cores Octa-core
GPU ARM Mali-G52 MC6
RAM 8GB
ROM 128GB
wifi hotspot 2.4G+5G
OS Android12.0
Media Format Video format MPEG-2/4
AVS
H.264, H.265
TS
Realmedia
Audio format MPEG1/2 layer I/II
AAC‐Lc,WMA
Photo format BMP/JPG
PNG
The Specification of 105 inch 21:9 with PCAP touch Android All In One PC
Side interface Earphone output 1
RS232 1
USB3.0*2 2
HDMI(5K) input 1
Touch-USB - B type Output 1
YPBPR IN 1
TYPE-C IN 1
Rear Down Ports HDMI(5K) output 1
VGA input 1
HDMI input 1
PC AUDIO IN 1
AV IN 1
AV Output 1
MIC IN 1
COAX output 1
DP IN 1
RJ45 IN 1
Audio Speaker power 2×10W(8Ω) THD+N<10%@1KHz
Frequency response 100Hz~15K Hz @±3dB(1KHz, -12dB reference signal)
Speaker type Box speakers, stereo
Radiation direction forward
Enclosure Net weight 120kg
Gross Weight 155kg
Product Size(W x D x H) 2548.3mm*91.4mm*1134.3mm
Carton Package size(W x D x H) 2700×280×1360mm
Shell material Die stamping back panel + hardware back cover + aluminum alloy brushed front frame
Shell color Full Black
Vesa Hole 1600mm*700mm
Power Input voltage 100-240V 50/60Hz
Maximum power 350W
Standby power 0.5W
Power switch Rocker type double-pole switch
Features Operating temperature 0-40
Storage temperature below 20℃~60
Operating humidity 10%-90% No condensation
Maximum usage time (hours/day) 18 hours
