Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-LD550SL
Certification :
CE/Rohs/FCC
Place of Origin :
ShenZhen, China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
200pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight cases are optional
Screen Size :
55 inch
Waterproof grade :
IP65
Resolution :
1920 X 1080 / 3840 X 2160
Brightness :
2000nits
Panel type :
TFT-LCD with WLED backlight
Touchscreen Type :
Capacitive
Ventilation Cooling system :
Built-in Fan or Air Conditioner
Cabinet material :
1.5mm zinc coated steel, waterproof and anti-dust design
Protection Glass :
with 6mm Tempered explosion-proof Glass
Input Voltage :
AC 100~240V, 50hz-60hz
Appearance Color :
White/Black/Customization
Network support :
Wifi /3G/4G/Ethernet Optional
Timer :
Set up on/off time on day/week/month
Switch power supply :
Industrial Power supply
Description

55-inch high-definition, high-brightness network remote cloud publishing large vertical screen outdoor lcd digital signage


The 55-inch outdoor lcd digital signage, with its high-definition waterproof network screen design, brings a brand-new experience to your advertising information display. Not only does it offer a bright and vibrant outdoor display, but it also allows for easy remote posting, making your advertising more free and flexible.


55-inch high-definition, high-brightness network remote cloud publishing large vertical screen outdoor lcd digital signage


55-inch outdoor lcd digital signage: Bright and vibrant outdoor display, easy remote posting, advertise anytime!


High-definition waterproof network screen, stunning and vibrant display: The device adopts a 55-inch outdoor lcd digital signage, ensuring that advertising content is displayed brightly and vibrantly in outdoor environments. Whether day or night, rain or shine, your advertising information can be clearly displayed.


55-inch high-definition, high-brightness network remote cloud publishing large vertical screen outdoor lcd digital signage


Remote cloud posting, more flexible advertising: The device supports remote cloud posting, so you don't need to be on-site to operate it. You can update your advertising content anytime, anywhere simply through the network. This gives your advertising more freedom and allows you to display the latest information in a timely manner.


All-in-one design, simple and beautiful: The device adopts an all-in-one design, with a simple and beautiful overall appearance. It not only displays advertising information but also adds a touch of brightness to the outdoor environment.


55-inch high-definition, high-brightness network remote cloud publishing large vertical screen outdoor lcd digital signage

55-inch high-definition, high-brightness network remote cloud publishing large vertical screen outdoor lcd digital signage


Wholesale with Ease, Meeting Diverse Needs: As a manufacturer, we offer wholesale services. You can choose different styles and specifications of 55-inch vertical outdoor advertising machines to meet diverse advertising needs.


55-inch high-definition, high-brightness network remote cloud publishing large vertical screen outdoor lcd digital signage

55-inch high-definition, high-brightness network remote cloud publishing large vertical screen outdoor lcd digital signage


The 55-inch outdoor lcd digital signage brings greater convenience and freedom to your advertising. Whether in commercial plazas, street corners, or public places, it can attract attention and convey promotional information. At the same time, the all-in-one design is simple and beautiful, making your advertising more attractive. Whether for large-scale events or daily displays, it will become your powerful assistant, helping you take your advertising results to the next level!


55 inch Android outdoor all-in-one machine (air conditioning model) specification sheet (English version)
Specications
The containment structure The material and feature of shell IP66 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design.
Glass feature with 6mm Tempered explosion-proof Glass above the screen panel
LCD Panel Screen Size 55 inch
Display area 1214mm(H) X 684mm(V)
Aspect Ratio 9:16
LCD Type TFT-LCD
Max Resolution 1920X 1080
Display color 16.7M
Brightness 2000cd/~2500 cd/
Contrast Ratio 4000:1
Viewing angle(up/down/left/right) 178°/178°/178°/178°
Response Time 6ms
Field Frequency 60Hz
Storage temperature & Humidity below20 ~ +60, ≤ 90%RH
Touch Overlay for Interactivity Touch style Projected Capacitive Touch screen
Touch points 10 points
Ambient light sensor auto dimming, with light sensor, automatically adjust the brightness.
Drawer-type Android Media Player box Configuration Processor Chip RK3399, six core
RAM 4GB
Flash Memory Card 32GB
Wifi and 4G Yes
Version Android 9.0
Media Format Video format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio format MP3, WMA
Photo format BMP, JPEG, PNG, GIF etx
Onboard interface Network port RJ45, 10M/100M Adaptive Ethernet
HDMI 1
USB 2
Camera Built-in 5 Megapixel Camera with 1920X1080 Resolution
Speakers Dual side speakers for Audio
ECU Switch power supply Industrial Power supply
Waterproof speaker High quality waterproof 10W speaker
Thunder Preventer The tree-level lightning protection
Leakage protective device Defend Electricity Leakage
Timer Set up on/off time on day/week/month
Outdoor OMC system(optional) inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor).
Problem and staus monitoring software included.
Touble shooting by software included.
Use softwae Remote Check key working performance by Group
Unnormal work alarm generation
Built-in Air conditioner for Ventilation Intelligent Straight ventilation Cooling system Intelligent cooling system, unique design of air duct and main board, automatic adjust internal temperature
Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically
Environment Working temperature 0 ~ 50
Working humidity 5% ~ 95%
Working Voltage AC 100 ~240v , 50Hz
Max Power Consumption 280W
Product size / Net weight To be determined
Outer Package size and Gross weight


If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
