Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Bulletproof 750mm Metal Window Screen Mesh
Specifications
Brand Name :
QIJIE
Model Number :
QIJIE01
Place of Origin :
CHINA HEBEI
MOQ :
10pcs
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000m2
Delivery Time :
15-18days
Packaging Details :
paper carton and pallets
Screen netting material :
Stainless Steel
Type :
Door & Window Screens
Material :
Stainless Steel Wire
Application :
Anti insect,Sliding Windows,Protecting Mesh
Color :
white
Product name :
Security Window Scree,Stainless steel mosquito net for security window screen,High Quality Rat Proof Stainless Steel Window Screen,King kong network
Width :
750mm
Mesh :
etc
Length :
30m,1-30m
Mesh size :
11x11mesh,etc
Surface treatment :
Electrostatic Powder Spraying
Wire diameter :
0.8mm
Packing :
water proof plastic bags outside
Description

Bulletproof 750mm Metal Window Screen Mesh

Window screen is also known as wire screen, insect screen or fly screen. It is used to keep leaves, debris, insects, birds and other animals from entering a building or a screened structure such as a porch, while permitting fresh air-flow. Therefore it is applied to filtration, windows for mosquitoes and flies, doors, etc.
Stainless steel insect mesh is the most durable of the materials available for insect mesh and has excellent resistance to corrosion. Stainless steel insect mesh keeps out flies, wasps, bees, mosquitoes and other insects, but not midges.

Window Screen Mesh Specification


Black SS Security Insect Screen
1. material:AISI316/304.
2. mesh:11 mesh.
3. wire dia : 0.8mm
4. meet Australia standard


Material
Mesh per inch
Wire Dia (mm)
Wire Dia (inch)
Open Area %

AISI 316 or 304
10 x 10
0.9
0.035"
41.7

AISI 316 or 304
10 x 10
1.2
0.028"
27.8

AISI 316 or 304
10 x 10
0.8
0.032"
46.9

AISI 316 or 304
10 x 10
1.15
0.045"
29.9

AISI 316 or 304
11 x 11
0.8
0.032"
42.5

AISI 316 or 304
11 x 11
0.7
0.027"
48.3

AISI 316 or 304
12 x 12
0.7
0.027"
44.8

AISI 316 or 304
12 x 12
0.58
0.023"
52.8

Special mesh can be made according to customers requirement


Chemical Composition:

Chemical composition of stainless steel wire:
Grade Chemical Composition(%)
C Si Mn P S Ni Cr Mo
304 =0.08 =1.00 =2.00 =0.045 =0.030 8.00~10.50 18.00~20.00 -
304H >0.08 =1.00 =2.00 =0.045 =0.030 8.00~10.50 18.00~20.00 -
304L =0.030 =1.00 =2.00 =0.045 =0.030 9.00~13.50 18.00~20.00 -
316 =0.045 =1.00 =2.00 =0.045 =0.030 10.00~14.00 10.00~18.00 2.00~3.00
316L =0.030 =1.00 =2.00 =0.045 =0.030 12.00~15.00 16.00~18.00 2.00~3.00
430 =0.12 =0.75 =1.00 =0.040 =0.030 =0.60 16.00~18.00 -
430A =0.06 =0.50 =0.50 =0.030 =0.50 =0.25 14.00~17.00 -


Features:
1. Against theft, bulletproof, super resistance to impact, insect and so on.
2. mooth surface, mesh standard, latitude and longitude curve is consistent, its remarkable characteristic is BanShi hard like iron, is against theft, bulletproof, home of choice for workplace safety protection.
3. Bulletproof Mesh Screen Features :
-- very high bounce impact force,the most feature and application.
-- as window screen ,it has good view inside room,but hazy for person outside room
-- easy to clean
-- power coated
