0.17mm Aluminum Window Screen Aluminium Insect Mesh 1.5 X 25m Rolls
0.17mm Aluminum Window Screen Aluminium Insect Mesh 1.5 X 25m Rolls
0.17mm Aluminum Window Screen Aluminium Insect Mesh 1.5 X 25m Rolls
0.17mm Aluminum Window Screen Aluminium Insect Mesh 1.5 X 25m Rolls
Specifications
Brand Name :
X MESH
Model Number :
X MESH-Aluminium Window Screen-015
Certification :
ISO9001:2015
Place of Origin :
Hebei P.R. China.
MOQ :
10pcs
Price :
USD2.35-3.58/m2
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000m2/week
Delivery Time :
5-7days
Packaging Details :
Wrapped with plastic film and wooden case packing
Product name :
Aluminium Window Screen
Material :
Aluminium Alloy Wire
Wire Diameter :
0.17mm
Mesh/inch :
20 x 20 mesh
Width :
1.5m
Length :
25m
Application :
For Windows
Color :
Silver
Feature :
Good ventilation
Packing :
Carton or Wooden Pallet Packing
Description

Aluminum alloy insect fly and mosquito window screen mesh with 1.5 x 25m rolls

Aluminium Window Screen Introduction:

Aluminum window screen is woven from aluminum wire or aluminum-magnesium alloy wire with square opening mesh. Aluminum insect screen is also called magnalium wire screen. Its natural color is silver white. And our aluminum window screen can be coated with epoxy coating to green, silver gray, yellow and blue, or with charcoal coated in black color.

Aluminium Window Screen Specification:

Mesh

Wire Diameter (mm)

Width

Length

12meshx12mesh

0.28

0.6m to 1.5m

100'

14meshx14mesh

0.25

0.6m to 1.5m

100'

14meshx14mesh

0.23

0.6m to 1.5m

100'

14meshx14mesh

0.22

0.6m to 1.5m

100'

14meshx14mesh

0.21

0.6m to 1.5m

100'

16meshx14mesh

0.25

0.6m to 1.5m

100'

16meshx14mesh

0.23

0.6m to 1.5m

100'

16meshx14mesh

0.22

0.6m to 1.5m

100'

16meshx14mesh

0.21

0.6m to 1.5m

100'

16meshx16mesh

0.25

0.6m to 1.5m

100'

16meshx16mesh

0.23

0.6m to 1.5m

100'

16meshx16mesh

0.22

0.6m to 1.5m

100'

16meshx16mesh

0.21

0.6m to 1.5m

100'

18meshx16mesh

0.25

0.6m to 1.5m

100'

18meshx16mesh

0.23

0.6m to 1.5m

100'

18meshx16mesh

0.22

0.6m to 1.5m

100'

18meshx16mesh

0.21

0.6m to 1.5m

100'

18meshx18mesh

0.25

0.6m to 1.5m

100'

18meshx18mesh

0.23

0.6m to 1.5m

100'

18meshx18mesh

0.22

0.6m to 1.5m

100'

Variety

Mesh/inch

Wire gauge

Roll size

Material


Aluminum Wire Window Screening

10x10

BWG31
BWG32
BWG33
BWG34

3"x100"
4"x100"
1x25M
1.2x25M
1.5x25M

Al-mg.alloy
or
Enamelled Aluminium
Window Screening

14x14

18x18

14x18

18x18

22x22

24x24

Mesh

Gauge(mm)

Size

Color

14×14

0.21,0.23,0.25


Width:2’to 6’
Length:50’to 300’


White/black/custom color

16×16

0.21,0.23,0.25

18×16

0.19,0.21,0.23,0.25

20×20

0.17,0.19,0.21

Aluminium Window Screen Feature:

  • 1. High quality, long life.
    2. Fireproof and flame retardant.
    3. Invisible screen wirh good ventilation.
    4. Anti mosquito, anti rat, anti insect bite, also anti dust and esay to clean.
    5. The mesh is fine and flat, and the holes are evenly distributed.

Aluminium Window Screen Application:

widely used in the windows, doors and corridors of the constructions, houses and hotels against mosquitoes and flies or other flying worms. Benefit from the anti-corrosion and rust feature, galvanized window screen can be used in the environments where is corrosive and dusty.

Aluminium Window Screen Packing:

1.Put into wooden carton
They are packaged by paper board and then put into wooden carton

2. Suitable carton
After packaging, waiting for delivery

3. Pick them up into container
Pick the wooden cases into container,then deliver them to all over the world.
