ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Goldantell
MOQ :
2
Price :
$1,380-1,500
Model Number :
GAT-ESD305
Certification :
CE
Display size :
8 inches
Power supply :
220 / 110 V(AC)
Operating voltage :
input AC220V output DC12V
Pass speed :
30-40 persons/min
Interface :
RS485, TCP/IP
Material :
Stainless steel
Working temperature :
-15~+75 °C
Environmental temperature :
5°C~40°C
Humidity range :
0%~90%
Pedal size :
W 400 x L 420 x H 20 (mm)
Left shoe range :
0.01-1000MΩ
Right shoe range :
0.01-1000MΩ
Wrist-strap range :
0.1-35MΩ
Left shoe accuracy :
±5%
Right shoe accuracy :
±5%
Wrist-strap accuracy :
±5%
Description
Product Description
Built in computer internet interface rfid card reader optional 8inch screen esd wrist strap & footwear tester esd shoe tester

Technology Parameter Of GAT-ESD305 Tester System
Features: It can be used to save data online, with signal output, 8 inch display monitor, included related software, tester and voice prompts (additional), and employee card access control.
1. ESD equipment can be quickly tested, and three independent devices (Left Shoes, Right Shoes, Wrist Strap) be completely ESD tested at one time.
2. Just install SQL Server2000/2008 and run the access control management software system on any computer in your
company.
3. Through TCP/IP communication technology, you can connect 255 human body comprehensive testing equipment (255 sets of Flap Turnstile / Tripod Turnstiles or other types). To monitor employees' compliance with anti-static requirements in real time.
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
Specification
1
Instrument Dimensions
8 inch LCD monitor:
display all info of users, like photo, name, card ID,depart, entry time,etc.
2
Pedal size
W 400 x L 420 x H 20 (mm)
3
Operating voltage
input AC220V output DC12V
4
Working hours
unlimited
5
Environmental conditions
Humidity: 0%~90%, Temperature: 5C°~ 40°C
6
Automatically store records and ESD test data (except client mode), recording information up to 100,000 or more.
7
Test Range and Accuracy (Note: The ESD checker meets the standards of other countries. The upper
and lower limit values of the test range can be adjusted according to customer requirements.)
8
Left shoe setting 0.01-1000MΩ,Accuracy ±5%
Right shoe setting 0.01-1000MΩ,Accuracy ±5%
Wrist-strap setting 0.1-35MΩ,Accuracy ±5%
Features & Functions
ESD tester system has 4 modes to choose from:
① Simultaneously detect hands and feet. This mode is suitable for line operators;
② Only detect the feet, this mode is suitable for those who need to enter the workshop, but do not directly contact the product such as QC, warehouse manager, etc.;
③ Only detect the hand, this mode is suitable for assembly line or logistics;
④ Free test card, applicable to the boss/customer inspection workshop, passing directly via swiping card.
Pls note: The above modes do not need to be switched manually, all can be set in the software, reading card automatically recognizes the employee's authority, the company can set different test card permissions according to different test requirements.
Projects Example
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
1. Flap Turnstile Gate + ESD tester system GAT-ESD305 (include software and Card access control system)
* 8 inch LCD monitor screen: much more bigger than common ones in 4 inches.
* higher esd Test Range and Accuracy: 0.01-1000MΩ for shoes, 0.1-35MΩ for Wrist-strap.
2. Flap Turnstile Gate + ESD tester (no control software for this type)
* Apart from ESD tester, can also combine with Access control system like RFID card reader on Turnstile.
* no display screen
Related Products
Certifications
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
Company Profie
ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester
Our Shenzhen Goldantell Technologies Co.,Ltd is a leading exporter and supply chain service provider of intelligent turnstile and parking management products with more than 13 years’ experience.

Our main products include intelligent turnstiles,parking barrier, RFID card,sentry box, wheel clamp and other related security access control system and parking system. We have exported to more than 50 countries and built long term partnerships with clients.

Your satisfaction is our duty! It will be our great honor to serve you. We do hope we can offer you more help in medical field and build the long term business relationship with you.
