Bright Annealed Sanitary Seamless Tube ASTM A270 TP316L 1.4404
Bright Annealed Sanitary Seamless Tube ASTM A270 TP316L 1.4404
Specifications
Brand Name :
Shangle
Model Number :
12.7
Certification :
PED,IS09001
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500TONS/30DAYS
Delivery Time :
30DAYS
Packaging Details :
Woven Packing
Material :
304 ,304L 310 321 316 316L
Standard :
AISI, ASTM, DIN, EN, GB
Shape :
SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80
Technique :
Cold Draw
Application :
Oil, Petroleum/Power
Package :
Woven Packing
Description

Bright Annealed Sanitary Seamless Tube ASTM A270 TP316L 1.4404

ASTM A270 specification is covering the grade of welded, seamless austenitic/ferrite and heavily cold worked welded SS sanitary tubing. Those are intended for use in the food industry, dairy industry and are also having special surface finishes.

A270 TP316L sanitary stainless pipe works well in elevated pressure applications and showcases enhanced strength allowing it to be very robust in harsh environments. The pipes are also tolerant to pitting by acids and crevice corrosion in the system.

ASTM A270 TP316L sanitary stainless pipe usually refers to the small pipe diameters, normally from 1/2” to 2 1/2”, thickness from 0.049 inch (1.24mm) to 0.15 inch (3.81mm). The maximum outer diameter of ASTM A270 TP316L tubing is 12 inch (316L.8 mm). ASTM A270 TP316L tubing using inch pound as the standard unit of measure. ASTM A270 TP316L Tube wall thickness tolerance shall not vary more than 12.5%.

Advantage of Austenitic:

Austenitic steel grades are very formable and weldable. These sanitary tubes are made of a highly corrosion-resistant, maintenance-free substance that provides hardness at low temperatures and maintains mechanical properties even when temperatures climb to high levels. Austenitic steel grades have 30-minute fire resistance in stainless steel systems without extra fire safety.

ASTM A270 TP316L Stainless Steel Tube Chemical Composition

Grade UNS C Mn P S Si Cr Ni Mo
ASTM A270 TP316L S31603 0.035 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.0-3.0

ASTM A270 TP316L Mechanical Properties

Material Heat Temperure Tensile Strength Yield Strength Elongation %, Min
Treatment Min. Ksi (MPa), Min. Ksi (MPa), Min.
º F(º C)
Asme A270 TP316L Solution 1900 (1040) 70(485) 25(170) 35

TP316L Equivalent

Grade WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
TP316L 1.4404 / 1.4435 S31603 SUS 316L 316LS11 / 316LS13 03Ch17N14M3 / 03Ch17N14M2 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3

Physical properties of ASTM A270 TP316L stainless steel in the annealed condition


Grade		 Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (μm/m/°C) Thermal Conductivity (W/m.K) Specific Heat 0-100°C (J/kg.K) Electrical Resistivity (nΩ.m)
0-100°C 0-315°C 0-538°C at 100°C at 500°C
ASTM A270 TP316L 8000 193 17.2 17.8 18.4 16.2 21.5 500 720

Applications:

  • Chemical and petrochemical
  • Power generation
  • Renewable energy
  • Pulp and Paper
  • Process piping
  • Pharmaceutical
  • Food and beverage
  • Oil and gas
  • Mining
  • Water/waste
  • Marine Industry
  • Fertilizers

Size InspectionBright Annealed Sanitary Seamless Tube ASTM A270 TP316L 1.4404
