Carbon Steel Seamless Pipe ASTM A333 Gr 6 Tube For Structure Construction
Carbon Steel Seamless Pipe ASTM A333 Gr 6 Tube For Structure Construction
Carbon Steel Seamless Pipe ASTM A333 Gr 6 Tube For Structure Construction
Carbon Steel Seamless Pipe ASTM A333 Gr 6 Tube For Structure Construction
Specifications
Brand Name :
NEW FORCE
Model Number :
ASTM A333
Certification :
MTC
Place of Origin :
China
MOQ :
10 tons or negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200000 tons per month
Delivery Time :
2~10 weeks
Packaging Details :
Bundle
Standard :
ASTM A333
Material :
Gr. 6
Application :
Structure Construction
Length :
Random or Fixed
Structure :
Seamless
Steel :
Carbon Steel Pipe
Usage :
Refinery
Description

Carbon Steel ASTM Seamless Pipe A333 Grade 6 Tube For Structure Construction

ASTM A333 Grade 6 is the part of standard covers wall seamless and welded carbon and alloy steel pipe intended for use at low temperatures. ASTM A333 Grade 6 alloy pipe shall be made by the seamless or welding process with the addition of no filler metal in the welding operation.

1. Standards:
ASTM A333: Standard Specification for Seamless and Welded Steel Pipe for Low-Temperature Service

2. Applications of ASTM A333 Grade 6 Seamless Pipes:

  1. Refineries
  2. Power Plants
  3. Boilers
  4. Ship Building
  5. Heat Exchangers
  6. Condensers
  7. Paper & Pulp
  8. Marine Applications
  9. Nuclear Power
  10. Fossil Fuel Power Plants

3. Ordering Information

Quantity (feet, centimeters, or number of lengths),

Name of material (seamless pipe),

Grade (Gr.6),

Size (NPS or outside diameter and schedule number of average wall thickness),

Lengths (specific or random),

End finish

Optional requirements

Test report required

4. Chemical Requirements

Chemical Composition % Gr. 6
Carbon (C) max Manganese (Mn) Phosphorus (P) max Sulfur (S) max Silicon (Si) Nickel (Ni) Chromium (Cr) Copper (Cu) Aluminum (Al) Vanadium (V) max
0.3 0.29-1.06 0.025 0.025 0.10 min … … … … …

5. Manufacturing Process

Raw Material Inspection → Cold Centering → Heating → Piercing & Rolling → SIzing → Heat Treatment → Testing → Finishing → NDE → Visual & Dimension Inspection → Marking → Storing & Shipping

6. Mechanical Properties

Tensile Strength, min: 60ksi/415MPa

Yield Strength, min: 35ksi/240MPa

7. Available Size Range

OD

Thickness

mm

inch

mm

SCH

88.9~1422

3''~ 56''

2.11~140

≥SCH10

*If the steel grades and size you are looking for are not listed above, please contact us for further information.
