Oil Gas Delivery Seamless ASTM Carbon Steel Pipe For Low Temperature Service
Oil Gas Delivery Seamless ASTM Carbon Steel Pipe For Low Temperature Service
Oil Gas Delivery Seamless ASTM Carbon Steel Pipe For Low Temperature Service
Oil Gas Delivery Seamless ASTM Carbon Steel Pipe For Low Temperature Service
Specifications
Brand Name :
NEW FORCE
Model Number :
ASTM A333
Certification :
MTC
Place of Origin :
China
MOQ :
10 tons or negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200000 tons per month
Delivery Time :
2~10 weeks
Packaging Details :
Bundle
Standard :
ASTM A333
Material :
Gr. 1, Gr. 3, Gr. 4, Gr. 6, Gr. 7, Gr. 8, Gr. 9, Gr.10
Service :
Low-Temperature Service
Length :
Random or Fixed
Structure :
Seamless
Steel :
Carbon Steel Pipe
Description

Oil Gas Delivery Seamless ASTM Carbon Steel Pipe For Low Temperature Service

1. Referenced Documents:

ASTM A 370 Test Methods and Definitions for Mechanical testing of Steel Products

ASTM A999/A 999M Specification for General requirements for Alloy and Stainless Steel Pipe

ASTM A 671 Specification for General requirements for Alloy and Stainless Steel Pipe

ASTM E 23 Test Methods for Notched bar Impact testing of Metallic Materials

2. Standards:
ASTM A333: Standard Specification for Seamless and Welded Steel Pipe for Low-Temperature Service

3. Available Size Range

OD Thickness
mm inch mm SCH
88.9~1422 3''~ 56'' 2.11~140 ≥SCH10
*If the steel grades and size you are looking for are not listed above, please contact us for further information.

4. Application:
Oil, Gas and water delivery;

Refinery, Boiler and Mechanical equipment manufacture;

structure construction; drilling, ship building and etc.

5. Ordering Information

Quantity (feet, centimeters, or number of lengths),

Name of material (seamless pipe),

Grade (Gr.1, Gr.3, Gr.4, Gr.6, Gr.7, Gr.8, Gr.9, and Gr.10),

Size (NPS or outside diameter and schedule number of average wall thickness),

Lengths (specific or random),

End finish

Optional requirements

Test report required

6. Chemical Requirements

Chemical Requirements
Element Composition, %
Grade 1 Grade 3 Grade 4 Grade 6 Grade 7 Grade 8 Grade 9 Grade 10
Carbon (C) max 0.3 0.19 0.12 0.3 0.19 0.13 0.2 0.2
Manganese (Mn) 0.40-1.06 0.31-0.64 0.50-1.05 0.29-1.06 0.90 max 0.90 max 0.40-1.06 1.15-1.50
Phosphorus (P) max 0.025 0.025 0.025 0.025 0.025 0.025 0.025 0.035
Sulfur (S) max 0.025 0.025 0.025 0.025 0.025 0.025 0.025 0.015
Silicon (Si) … 0.18-0.37 0.08-0.37 0.10 min 0.13-0.32 0.13-0.32 … 0.10-0.35
Nickel (Ni) … 0.47-0.98 0.47-0.98 … 2.03-2.57 8.40-9.60 1.60-2.24 0.25 max
Chromium (Cr) … 0.44-1.01 0.44-1.01 … … … … 0.15 max
Copper (Cu) … 0.40-0.75 0.40-0.75 … … … 0.75-1.25 0.15 max
Aluminum (Al) … 0.04-0.30 0.04-0.30 … … … … 0.06 max
Vanadium (V) max … … … … … … … 0.12
Columbium (Cb)max … … … … … … … 0.05
Molybdenum (Mo) max … … … … … … … 0.05
Cobalt (Co) … … … … … … … …

7. Manufacturing Process

Raw Material Inspection → Cold Centering → Heating → Piercing & Rolling → SIzing → Heat Treatment → Testing → Finishing → NDE → Visual & Dimension Inspection → Marking → Storing & Shipping

8. Mechanical Properties

Tensile Strength, min: Gr. 1 Gr. 3 Gr. 4 Gr. 6 Gr. 7 Gr. 8 Gr. 9 Gr. 10
ksi 55 65 60 60 65 100 63 80
Mpa 380 450 415 415 450 690 435 550
Yield Strength, min: 　 　 　 　 　 　 　 　
ksi 30 35 35 35 35 75 46 65
MPa 205 240 240 240 240 515 315 450

Oil Gas Delivery Seamless ASTM Carbon Steel Pipe For Low Temperature Service
