OD 25-300mm Resistance Seam Welding Equipment
OD 25-300mm Resistance Seam Welding Equipment
Specifications
Brand Name :
RUILIAN
Model Number :
RFA-J25
Place of Origin :
Hanzhong Shanxi China
MOQ :
1 devices
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
1+ devices+a month
Delivery Time :
5-8 work days
Packaging Details :
Packing in wooden cases
Welding diameter :
Ø25~Ø300mm
Device name :
Air duct arc seam welding machine of Resistance arc welding Seam Welding Equipment
Weld thickness :
Stainless steel sheet：0.2~0.5mm/Low carbon sheet steel:0.2~0.5mm/Galvanized sheet steel:0.2~0.5mm
Welding speed :
1~3m/min
Welding copper wire diameter :
Ø1.38 mm
Cooling water :
0.4Mpa 8.5L/min
compressed air :
0.8Mpa 600L/min ≤25°C
Welding power :
30KVA
Description

Seam Welding Equipment Air duct arc seam welding machine of Resistance arc welding

Welding diameter Ø25~Ø300mm
Weld thickness Low carbon sheet steel:0.2~0.5mm
　 Galvanized sheet steel:0.2~0.5mm
　 Stainless steel sheet:0.2~0.5mm
Welding speed 1~3m/min
Overlap 6mm
Welding copper wire diameter Ø1.38 mm
Cooling water flow rate 0.4Mpa 8.5L/min

compressed air

 0.8Mpa 600L/min ≤25°C
Welding power 30KVA
Net weight 1T

Seam Welding Equipment Air duct arc seam welding machine of Resistance arc welding

  • Air duct arc seam welding machine
  • Resistance arc welding
  • Arc welding
  • Air duct weiding
  • Sheet metal welding
  • Duct welder
  • Vanitation pipe

Product of Seam Welding Equipment Air duct arc seam welding machine of Resistance arc welding

Air duct arc seam welding machine of Resistance arc welding

The RFA-J25 basic ring seam resistance welding machine is suitable for welding applications of circular air ducts and household appliances. RFA-J25 basic welding ring seam resistance machine is a special resistance welding machine with high practical value, which is suitable for application scenarios such as blunting the round tube. The air duct and appliance industry requires welding scenarios in which thin-arm round tubes are connected and resistance welding is a perfect solution.
