Specifications
Brand Name :
KELONG
Model Number :
Rubber V-seal VS Rotary Shaft Seal Ring
Place of Origin :
CHINA
MOQ :
100
Payment Terms :
L/C, T/T
Supply Ability :
100,000 pcs /months
Delivery Time :
15
Packaging Details :
Customizable packaging
Name :
Hydraulic Cylinder Ring
Material :
PTFE NBR
Pressure (max) bar :
300
Temperature (max) °C :
-30/+105
Sliding Speed (max)- m/s :
5
Description

Hydraulic Cylinder FKM Rubber V-Ring Water Seal NBR Rubber V-Seal VS Rotary Shaft Seal Ring

Hydraulic Cylinder FKM Rotary Seal Ring / Rubber NBR Sealing Ring

Type S V-rings with bevel back serves as a pressure-less, axial rod seal which is clamped on a shaft. The flexible sealing lip seals a counterface at a right angle to the shaft, preventing dirt, dust and splash to enter the construction. Available in sizes from .180″ (4.5mm) shaft to 8.270″ (210mm). Commonly used in agricultural and automotive applications.

Hydraulic Cylinder FKM Rotary Seal Ring / Rubber NBR Sealing Ring
VS Style Size Chart
Seal Dimensions Housing Dimensions
A B C D E F G
Part Number Shaft Diameter I.D. O.D Height I.D. O.D Width
VS 005 4.50-5.50 4.00 8.00 5.20 A+1.00 A+6.00 4.50±0.40
VS 006 5.50 ·6.50 5.00 9.00 5.20 A+1.00 A+6.00 4.50±0.40
VS 007 6.50-8.00 6.00 10.00 5.20 A+1.00 A+6.00 4.50±0.40
VS 008 8.00-9.50 7.00 11.00 5.20 A+1.00 A+6.00 4.50±0.40
VS 010 9.50-11.50 9.00 15.00 7.70 A+2.00 A+9.00 6.70±0.60
VS 012 11.50-13.50 10.50 16.50 7.70 A+ 2.00 A+9.00 6.70±0.60
VS 014 13.50-15.50 12.50 18.50 7.70 A+2.00 A+9.00 6.70±0.60
VS 016 15.50-17.50 14.00 20.00 7.70 A+2.00 A+9.00 6.70±0.60
VS 018 17.50-19.00 16.00 22.00 7.70 A+2.00 A+9.00 6.70± 0.60
VS 020 19.00-21.00 18.00 26.00 10.50 A+2.00 A+ 12.00 9.00±0.80
VS 022 21.00-24.00 20.00 28.00 10.50 A+2.00 A+ 12.00 9.00±0.80
VS 025 24.00-27.00 22.00 30.00 10.50 A+2.00 A+12.00 9.00±0.80
VS 028 27.00-29.00 25.00 33.00 10.50 A+3.00 A+12.00 9.00±0.80
VS 030 29.00-31.00 27.00 35.00 10.50 A+ 3.00 A+ 12.00 9.00± 0.80
VS 032 31.00-33.00 29.00 37.00 10.50 A+3.00 A+ 12.00 9.00±0.80
VS 035 33.00-36.00 31.00 39.00 10.50 A+ 3.00 A+ 12.00 9.00±0.80
VS 038 36.00-38.00 34.00 42.00 10.50 A + 3.00 A+ 12.00 9.00±0.80
VS 040 38.00-43.00 36.00 46.00 13.00 A+ 3.00 A+15.00 11.00±1.00
VS 045 43.00-48.00 40.00 50.00 13.00 A+3.00 A+15.00 11.00±1.00
VS 050 48.00-53.00 45.00 55.00 13.00 A+3.00 A+ 15.00 11.00±1.00
V5055 53.00-58.00 49.00 59.00 13.00 A+3.00 A+15.00 11.00±1.00
VS 060 58.00-63.00 54.00 64.00 13.00 A+ 3.00 A+ 15.00 11.00±1.00
VS 065 63.00-68.00 58.00 68.00 13.00 A+ 3.00 A+15.00 11.00±1.00
VS 070 68.00-73.00 63.00 75.00 15.50 A+4.00 A+ 18.00 13.50±1.20
VS 075 73.00-78.00 67.00 79.00 15.50 A+4.00 A+18.00 13.50±1.20
VS 080 78.00-83.00 72.00 84.00 15.50 A+4.00 A+18.00 13.50±1.20
VS 085 83.00-88.00 76.00 88.00 15.50 A+4.00 A+18.00 13.50±1.20
VS 090 88.00-93.00 81.00 93.00 15.50 A+4.00 A+18.00 13.50±1.20
VS 095 93.00-98.00 85.00 97.00 15.50 A+4.00 A+18.00 13.50±1.20
VS 100 98.00-105.00 90.00 102.00 15.50 A+4.00 A+18.00 13.50±1.20
VS 110 105.00 ·115.00 99.00 113.00 18.00 A+4.00 A+21.00 15.50±1.50
VS 120 115.00-125.00 108.00 122.00 18.00 A+4.00 A+21.00 15.50±1.50
VS 130 125.00-135.00 117.00 131.00 18.00 A+4.00 A+ 21.00 15.50±1.50
VS 140 135.00-145.00 126.00 140.00 18.00 A+4.00 A+ 21.00 15.50±1.50
VS 150 145.00-155.00 135.00 149.00 18.00 A+4.00 A+ 21.00 15.50±1.50
VS 160 155.00 ·165.00 144.00 160.00 20.50 A+5.00 A+24.00 18.00±1.80
VS 170 165.00-175.00 153.00 169.00 20.50 A+5.00 A+ 24.00 18.00±1.80
VS 180 175.00-185.00 162.00 178.00 20.50 A+5.00 A+24.00 18.00±1.80
VS 190 185.00-195.00 171.00 187.00 20.50 A+5.00 A+24.00 18.00±1.80
VS 199 195.00-210.00 180.00 196.00 20.50 A+ 5.00 A+24.00 18.00±1.80
