Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
Specifications
Brand Name :
Kelong
Model Number :
KL02
Certification :
ISO9001 / IRIS
Place of Origin :
China
Payment Terms :
L/C, T/T, Paypal
Supply Ability :
100,000 pcs /months
Delivery Time :
7-15 work days
Packaging Details :
Opp bag
Style :
Hydraulic Rod Seals
Material :
NBR / FABRIC NBR / POM
Temperature (max) °C :
-30/+100
Pressure (max) bar :
400
Sliding Speed (max)- m/s :
0.5
Application :
Iron and steel industry / Marine hydraulics / Presses / Heavy duty cylinders / Mining industry
Description

Operating In Heavy Duty Conditions Single Acting Rod Sealing Set Rod Packing Multi Lip Structure


KL02 rod packing is a single acting rod sealing set which consists of one header ring, three pieces fabric elastomer rings, two pieces elastomer rings and one fabric elastomer back ring.

Advantages

• Operating in heavy duty conditions
• Functions even with poor surfaces by the multi lip structure
• Adjustable housing height due to the reason of being used in open grooves
• Quick installation and removal
• Long service life
• Very good sealing performance at both low and high pressures

Area of Application

• Iron and steel industry
• Marine hydraulics
• Presses
• Heavy duty cylinders
• Mining industry
Kelong Hydraulic Rod Seals NBR / FABRIC NBR / POM Material With Multi Lip Structure
d (f8) D (H9) L (+0.2/-0) H Cross Section E C MATERIAL
KL02-008 8 18 18.5 18.5 5 2.5 3 FB
KL02-010 10 20 18.5 18.5 5 2.5 3 FB
KL02-012 12 22 18.5 18.5 5 2.5 3 FB
KL02-013 13.5 25 16.5 16.5 5.75 - 3 FB
KL02-014 14 24 18.5 18.5 5 2.5 3 FB
KL02-015 15 25 18.5 18.5 5 2.5 3 FB
KL02-015/1 15 32 25 25 8.5 - 3 FB
KL02-016 16 26 18.5 18.5 5 2.5 3 FB
KL02-018 18 28 18.5 18.5 5 2.5 3 FB
KL02-018/1 18 32 23.5 23.5 7 - 3 FB
KL02-020 20 30 18.5 18.5 5 2.5 3 FB
KL02-020/1 20 32 22.5 22.5 6 3 5 FB
KL02-022 22 32 18.5 18.5 5 2.5 3 FB
KL02-022/1 22 34 22.5 22.5 6 3 5 FB
KL02-025 25 37 22.5 22.5 6 3 5 FB
KL02-025/1 25 40 22.5 22.5 7.5 3 5 FB
KL02-028 28 40 22.5 22.5 6 3 5 FB
KL02-028/1 28 43 22.5 22.5 7.5 3 5 FB
KL02-030 30 42 22.5 22.5 6 3 5 FB
KL02-030/1 30 45 22.5 22.5 7.5 3 5 FB
KL02-030/2 30 50 37 37 10 - 5 FB
KL02-032 32 44 22.5 22.5 6 3 5 FB
KL02-032/1 32 47 22.5 22.5 7.5 3 5 FB
KL02-032/2 32 45 22.5 22.5 6.5 3 5 FB
KL02-035 35 47 22.5 22.5 6 3 5 FB
KL02-035/1 35 50 22.5 22.5 7.5 3 5 FB
KL02-036 36 48 22.5 22.5 6 3 5 FB
KL02-036/1 36 51 22.5 22.5 7.5 3 5 FB
KL02-040 40 52 22.5 22.5 6 3 5 FB
KL02-040/1 40 55 22.5 22.5 7.5 3 5 FB
KL02-040/2 40 55 25 25 7.5 - 5 FB
KL02-040/3 40 56 22.5 22.5 8 3 5 FB
KL02-042 42 54 22.5 22.5 6 3 5 FB
KL02-042/1 42 57 22.5 22.5 7.5 3 5 FB
KL02-045 45 60 22.5 22.5 7.5 3 5 FB
KL02-045/1 45 65 22.5 22.5 10 4 5 FB
KL02-045/2 45 55 22 22 5 - 5 FB
KL02-045/3 45 62 26 26 8.5 - 5 FB
KL02-047 47 65 33 33 9 - 5 FB
KL02-048 48 63 22.5 22.5 7.5 3 5 FB
KL02-050 50 65 22.5 22.5 7.5 3 5 FB
KL02-050/1 50 70 30 30 10 4 5 FB
KL02-055 55 70 22.5 22.5 7.5 3 5 FB
KL02-055/1 55 75 30 30 10 4 5 FB
KL02-055/2 55 67 24 24 6 3 5 FB
KL02-056 56 71 22.5 22.5 7.5 3 5 FB
KL02-056/1 56 76 37 37 10 5 5 FB
KL02-056/2 56 72 46 46 8 6 5 FB
KL02-060 60 75 22.5 22.5 7.5 3 5 FB
KL02-060/1 60 80 37 37 10 5 5 FB
KL02-060/3 60 85 37 37 12.5 5 7.5 FB
KL02-063 63 78 22.5 22.5 7.5 3 5 FB
KL02-063/1 63 83 37 37 10 5 5 FB
KL02-063/2 63.5 78 40 40 7.25 - 5 FB
KL02-065 65 80 22.5 22.5 7.5 3 5 FB
KL02-065/1 65 85 40 40 10 5 5 FB
KL02-070 70 85 22.5 22.5 7.5 3 5 FB
KL02-070/1 70 90 40 40 10 5 5 FB
KL02-075 75 90 22.5 22.5 7.5 3 5 FB
KL02-075/1 75 95 40 40 10 5 5 FB
KL02-075/2 75 87 25 25 6 3 5 FB
KL02-075/3 75 100 34 34 12.5 4 7.5 FB
KL02-078 78 100 35 35 11 - 7.5 FB
KL02-080 80 95 22.5 22.5 7.5 3 5 FB
KL02-080/1 80 100 40 40 10 5 5 FB
KL02-085 85 100 22.5 22.5 7.5 3 5 FB
