Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
Specifications
Brand Name :
Changyuan
Model Number :
P2
Certification :
ISO9001/14001/45001
Place of Origin :
Shandong,China
MOQ :
500㎡
Price :
14-38$/㎡
Payment Terms :
T/T
Supply Ability :
10000m/day
Delivery Time :
5-20days
Packaging Details :
Film covered panels in pallets,EPS in the bottom,belt with or without,paper/steel protect the corner.
Core material :
PUR/PIR
Description

Sandwich panel polyurethane pu panel wall polyurethane foam sandwich panels pu foam sandwich panel

Products description

Name Polyurethane sandwich panel
Face metal PPGI,Al-Zn,Al-Mg-Mn,Al alloy,SS
Back metal PPGI,SS,Al-Zn
Core PUR/PIR
Thickness of the metal 0.4-0.8mm
Thickness of the core 50/75/100/120/150/200mm
Kinds roofing/wall sandwich panels
Surface Flat,wave,corrugated
Width 930/1000/1130mm
Length customized less than the container

Production line


Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm

Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm


Features

Thermal conductivity:≤0.020w/m·k

Water absorption rate:≤0.5

Closed porosity:≥97%

Compressive strength:≥220MPa

Flexural bearing capacity:≥2450

Oxygen index:≥28

Fireproof:B

Stability of the size:≤2%

Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm

Application

The high grade buildings,offices,the smart mushroom container,cold storage waredhouse,famous company warehouse,workshop,office buildings,cleaning room like labs,food warehouse,medical industry and so on.

Payments:

30% T/T in advance,balance before delivery after production.

Delivery time after payments reached 5-20days.

Pay attention:

1.The PUR/PIR products need time to stable after production,summer about 24hours,winter about 48hours.Then can be deliveried.

2.The face/back metal both film faced,after installation,tear off the film to avoid the water or rain into the sandwich panel,easy to rusting and corrosiion.

3.When moving the sandwich panels,dont drag the panels from one side,the panel must be pressed on average,the surface in a flat line best.

4.Before installation,the panels must be put in flat,dry ground.

Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm

Polyurethane Sandwich Panel with Thermal Conductivity ≤0.020W/m*K, Fireproof B Rating, and Customizable Thickness 50-200mm
