Steel Self Drilling Screws Zinc Plated XC DIN 7504 ANSI B18.6.4
Steel Self Drilling Screws Zinc Plated XC DIN 7504 ANSI B18.6.4
Steel Self Drilling Screws Zinc Plated XC DIN 7504 ANSI B18.6.4
Steel Self Drilling Screws Zinc Plated XC DIN 7504 ANSI B18.6.4
Specifications
Standard :
DIN 7504, ANSI B18.6.4
Size :
4.2mm - 6.3mm
Head Style :
HEX
Brand Name :
XC
Model Number :
4.8 5.8 6.3
Place of Origin :
China
MOQ :
500KG
Price :
0.1-1USD
Payment Terms :
L/C, T/T
Supply Ability :
10000TON
Delivery Time :
30-40days
Packaging Details :
in bulk
Surface Treatment :
Zinc Plated
Material :
Carbon Steel, Stainless Steel
Length :
13mm - 180mm
Description

Made in China Self Drilling Screws Hot Selling XC DIN 7504 ANSI B18.6.4

Key attributes

finish
Zinc, zinc plated
material
Steel
measurement system
INCH, Metric
Thread Type
standard thread
place of origin
Zhejiang, China
head style
HEX
brand name
XC
model number
DIN 7504K
Material
Carton Steel, Stainless Steel
Size
4.2mm--6.3mm
Length
13mm--180mm
Surface treatment
zinc plated
Package
1000pcs/box, box within 25kg carton or bulking in Carton; with pallet
Delivey time
within 30 days after receiving your advanced payment
Loading port
Shanghai port
MOQ

1 ton

Price term
FOB,CIF,CNF, EXW
key words
self drilling screw

Packaging and delivery

Selling Units
Single item
Single package size
30X20X50 cm
Single gross weight
9.000 KG

Product Description

Self Drilling Screw -

Self-Drilling Screw refers to a type of fastener featuring a drill bit-shaped tip that enables it to bore its own hole directly into substrates such as metal, wood, or hard plastics during installation, removing the requirement for pre-drilled pilot holes.
1Its design incorporates cutting edges that facilitate simultaneous drilling and threading, with variations including hex flange heads or countersunk heads for specific applications.
Typically manufactured from carbon steel or alloy materials, these screws often undergo surface treatments like zinc plating to enhance corrosion resistance.Common aliases include self-drilling screws, and they adhere to industry standards such as DIN 7504K for performance consistency.

Advantages

The DIN 7504K standard defines self-drilling screws featuring a hex flange head design, offering several key advantages for industrial and construction applications:

  • ‌Integrated Drilling Functionality‌: Eliminates the need for pilot holes by combining drilling and threading in one step, enabling rapid installation into materials like metal, wood, or hard plastics, thereby reducing labor time and costs 23.
  • ‌Superior Fastening Stability‌: The hex flange head provides exceptional clamping force and vibration resistance, ensuring a secure, tamper-proof connection in high-stress environments 12.
  • ‌Enhanced Durability and Corrosion Resistance‌: Manufactured from high-strength carbon steel or alloy materials (e.g., Grade 8.8) with surface treatments like zinc plating or Dacromet coating, delivering long-term protection against rust and environmental degradation 12.
  • ‌Broad Application Versatility‌: Optimized for diverse scenarios such as framing, roofing, and building construction, due to reliable performance across varying substrates and conditions 35.
  • ‌Standardized Performance and Reliability‌: Compliance with DIN 7504 ensures consistent dimensional accuracy and mechanical properties, guaranteeing high-quality outputs for industrial use
Additional Details
Finish:
Zinc, Plain
Material:
1022 304 316 410
Place of Origin: China
Brand Name:
XC FAST
Model Number:
8810
Certificate:
CE, ISO9001, TS16949
Process:
Cutting, Chamfered, Hot forging, Forming, Surface treatment
Surface Treatment:
PLAN, BLASTING, ZINC PLATED, HOT DIP GALVANISED, POWDER COATING
Applications

DIN 7504K – Technical Description & Applications

1. Definition & Standards

The DIN 7504K is a metric thread-rolling screw designed for self-tapping into pre-drilled holes in sheet metal, plastic, and light alloys. It features a pan head with a cross recess (Phillips drive) and is commonly used in fastening thin materials without requiring a pre-formed thread.

2. Key Features

  • Head Type: Pan head (low-profile, rounded top).

  • Drive Type: Cross recess (Phillips, typically PH or PZ).

  • Thread Type: Self-tapping thread (forms mating thread during installation).

  • Material: Steel (usually carbon steel or stainless steel A2/A4).

  • Surface Treatment: Zinc-plated, galvanized, or phosphated for corrosion resistance.

  • Standards Compliance: DIN 7504K (Germany), similar to ISO 7049 (international).

3. Mechanical Properties

Property Typical Value
Tensile Strength (MPa) 500–1000 (depending on grade)
Hardness (HV) 320–450 (case-hardened for thread durability)
Thread Pitch Coarse thread (e.g., M3, M4, M5)

4. Common Applications

  • Sheet Metal Assembly: Used in electrical enclosures, HVAC ducts, and automotive panels.

  • Plastic & Composite Materials: Fastens plastic housings, electronic casings, and lightweight structures.

  • Furniture & Appliances: Secures thin metal sheets in cabinets, racks, and home appliances.

  • Automotive Interiors: Used in dashboard assemblies, trim panels, and interior fittings.

  • Electronics & Consumer Goods: Fastens PCB mounts, battery covers, and small mechanical assemblies.

5. Advantages

✔ Self-Tapping – Eliminates the need for pre-threaded holes, reducing assembly time.
✔ Pan Head Design – Provides a low-profile, smooth finish for aesthetic applications.
✔ Phillips Drive – Allows for easy installation with standard screwdrivers or power tools.
✔ Versatile Material Compatibility – Works well with steel, aluminum, plastic, and thin sheet metal.

6. Installation Guidelines

  • Pre-drill a pilot hole (diameter slightly smaller than the screw’s minor diameter).

  • Avoid overtightening (risk of stripping threads in soft materials).

  • Use corrosion-resistant coatings (e.g., zinc or stainless steel) for outdoor/moisture-exposed applications.

7. Alternatives & Variants

  • DIN 7985K – Similar pan-head screw but with machine thread (not self-tapping).

  • ISO 7049 – International equivalent with slight dimensional differences.

  • DIN 7981 – Countersunk head self-tapping screw for flush mounting.

Frequently Asked Questions
What sizes do you offer?

Common sizes: 3#-6.3 * 130mm-180mm (other metric sizes available upon request).
