Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data
Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data
Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data
Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data
Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data
Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data
Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data
Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data
Specifications
Brand Name :
DAQIN
Model Number :
C188
Certification :
CE ,GSG, ISO, GS
Place of Origin :
China
MOQ :
1 Set
Price :
USD 774 per Set
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
800 sets per month
Delivery Time :
2-10 days
Packaging Details :
Wood package
Cutter Type :
Laser cutter
Transport Interface :
USB Cable
Usage :
cutting,marking
Applicable Material :
Leather, tpu, Plastic, Wood,pvc
Cooling Way :
Circulating water cooling
Item :
Water Cooling Weihong Control Automatic Laser Cutting Plotter
Keyword :
Water Cooling Weihong Control Automatic Laser Cutting Plotter
Radiator :
DC12V 0.20A
Laser-type :
C02 Sealed Glass Laser Tube
Cutting Accuracy :
High
Materialcompatibility :
PET, TPU, tempered glass, plastic films
Laser Power :
40W
Laser Type :
CO2
Control Machine :
APP and PC software
Air System :
Air pump
Cuttingspeed :
0-500 mm/s
Use :
Notebook, Mobile Phone, Camera,
Drawing :
Support
Cooling Mode :
Air Cooling
Machinetype :
Laser Cutting Machine
Format Supported :
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
Keywords :
Glass Screen Protector Making Machine
Description

Screen Protector Laser Cutting Machine Supporting Any Model And Shape With Easy Modification And Addition Of Template Data
DAQIN Automatic Screen Protector Cutting System is a system of automatically cutting screen protectors, which controlled by the professional design and management software that can transform abundant and latest cutting die into graphic data and can connect with the cutting machine to produce screen protectors of PET/PVC fast and accurately. It solves the problem of supply screen protectors of small batch. The curve of cutting is natural and without rough edge.

Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template dataScreen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data

Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template dataScreen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template dataScreen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template dataScreen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data

  • Abundant template data. Upgrading in time. Including the newest models of mobile phones and tablets.
  • Any model, any shape, any brand. DIY template data for local brand of mobile phones.
  • Free arrangement, automatic positioning, saving cutting material effectively.
  • Adding and modifying the template data.
  • Easy operation, powerful functions.

Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data

Market value of Water Cooling Weihong Control Automatic Laser Cutting Plotter

  • Suitable for the mobile phone stores, mobile phone beauty salons, gift wholesalers, custom DIY project.
  • Easy to operate, which can produce various models and materials of screen protectors. It changes the physical holding of stock of screen protectors into template data that stored in the computer.
  • It can produce according to the order at any time, no worry about the inventory. It’s a historical leap of the process of mobile phone screen protectors.
  • Can cut screen protectors for the mobile phones, digital cameras, tablets,and PSP etc.
  • Cutting materials available: Scratch-resistant film-glossy, Scratch-resistant film-matte, Anti finger print film, Mirror screen film, Private screen film, Anti-radiation film, Anti-oil film, Diamond screen film and 3D screen film etc.

Screen Protector Laser Cutting Machine supporting any model and shape with easy modification and addition of template data

Specification for Daqin Water Cooling Weihong Control Automatic Laser Cutting Plotter

Specification of Water Cooling Weihong Control Automatic Laser Cutting Plotter
Laser Type CO2( laser tube ) Laser Power 30W
Laser Power Supply 40W Air Pump (Built-in) DC12V
Water Pump (Built-in) DC24V Exhaust Fan (Built-in) DC12V 1.74A
Radiator DC12V 0.20A LED light DC12V
Cooling Way Circulating water cooling Smoke Exhaust Way Rear Exhanst
Driving Mode 0.9°Stepper Motor Transport Interface USB Cable
Cutting Precision ±0.01mm Cutting Speed 0-50mm/s
Maximum Cut Area 360x250mm Machine Dimension 710x570x235mm
Machine Weight 27kg Total Power 700W
Packing Size 87*72*35 CM ( 44kg ) Total Packing Weight 40 KG

FAQ
How about the Warranty and Training for Water Cooling Weihong Control Automatic Laser Cutting Plotter ?
* The warranty for the machine is 1 year.
* The machine has been tested by professionals and has 18 years of practical application.
It's with high stability and low fault rate.
* Detailed training video for the machine and software will be provided.
Professional after-sale service is available by remote assistance and video chatting.
The operation is easy to learn, everyone can be a master.
How about the delivery time and shipping way for Water Cooling Weihong Control Automatic Laser Cutting Plotter?
* Since the packing is with small volume and light weight,
usually the goods will be shipped by international express company, such as DHL, FEDX...
need about 2 days for preparing and packing the goods.
