Specifications
Brand Name :
R&K
Model Number :
R&K-Stainless Steel Screen Mesh
Certification :
FDA / SGS / ISO:9001
Place of Origin :
Hebei, China(Mainland)
MOQ :
1meter
Price :
USD 5$-30$ per meter
Supply Ability :
10000 meters per month
Delivery Time :
7-15 days according to your quantity
Packaging Details :
Wrapped with moister-barrier paper, then in wooden cases.Or your requirements.
Weave Style :
Plain Woven
Elasticity :
No
Monofilament :
Yes
Mesh Count :
18 Mesh-420 Mesh
Width :
as your request
Application :
Chemical Industry / Solar Battery
Description

304 L Stainless Steel Screen Printing Durable Low Elongation Mesh

Product Introduction

Stainless Steel Screen Printing Mesh has

1 High tension. Its tension is more higher than common polyester mesh,and this proptery is very stable.

2 Super Precision. Uniform wire diameter and aperture with extermely low difference.

3 Low Elongation. Very small elongation of wire mesh at high tension.

4 High Flexibility. The wire mesh will not lose elasticity at extreme tension.

Product Specification

Mesh / Inch

Wire Dia.

(μm)

Aperture

(μm)

Thickness

(μm)

Theoretical Ink

(cm³/㎡)
40 160 475 300-320 179.1
60 120 303 230-245 123.2
80 120 198 234-245 92.9
100 100 154 195-205 77.2
120 80 132 155-165 65.8
200 40 87 82-82 43.0
200 50 77 98-103 42.0
250 40 62 82-86 34.0
300 30 55 66-68 28.0
400 23 41 50-54 19.0
500 18 33 36-40 15.3

Product Features

1.Super precisions

2.Extremely low elongation rate

3.High corrosion resistance

4.High tension

5.Non-electrostatic

6.Good heat-melting

7.Many years of research and production experience

8.High quality and export over 50 ountries.

9.High capacity and fast delivery.
