High-Speed Bottle Screen Printer High-Speed Printing With 3-Color UV Printing​

Machine Application:

1. Wide Shape & Product Coverage
It handles not only common round (e.g., cylindrical plastic bottles) and oval (e.g., elliptical perfume bottles) items, but also shaped products—such as curved cosmetic essence bottles, ribbed metal lids, or customized small-appliance plastic casings. Even products with subtle surface contours maintain uniform ink coverage.

2. Broad Material Adaptability
It works seamlessly with mainstream packaging materials:
Plastics: PET (beverage bottles), PP (food containers), HDPE (chemical barrels) — UV inks adhere firmly without peeling.
Glass: Soda-lime glass (sauce jars) and high-borosilicate glass (skincare bottles) — printed patterns resist scratches.
Metals: Aluminum (aerosol cans), tinplate (food cans) — cured inks offer wear and corrosion resistance.

3. Key 3-Color UV Printing Advantages
Precise overprinting (≤0.1mm accuracy) for vivid brand logos or product info.
Instant UV curing (no long drying time) to avoid smudges, suiting high-speed lines.
Durable ink layer (resists friction, solvents, temperature changes) for long-term use.
It meets needs of food & beverage, cosmetics, daily chemical and industrial packaging—for both mass-produced and small-batch customized products.

Printing sample

Main Functions:

Wireless tablet control function;

Remote service management function;

Speed-adjustable conveyor separation feeding function;

Bottle standing robot feeding function;

Digitally controlled servo motor drive for 3-color 360-degree printing;

UV curing function;

Standing robot bottle discharge function;

Conveyor discharge function with adjustable speed.

Ten workstations:

1. Visual positioning and electrostatic dusting of the bottom of the feed bottle;

2. Flame treatment

3. Visual positioning of the bottle

4. First color screen printing

5. LED-UV curing

6. Second color screen print

7. LED-UV curing

8. Third color screen printing (or hot stamping)

9. UV curing

10. Discharge.

Screen printing device UV curing device

Technical Specifications:

What is the difference between a linear screen printing machine and a CNC rotary screen printing machine?

1. Straight line screen printing machine is faster than CNC rotary screen printing machine, but the printing accuracy is lower.

2. Straight line presses are modular combinations, the more colors the larger the footprint, while CNC rotary is a rotating structure that will save space.

3. CNC printers are easier to use with remote management and service feature.

4. For CNC machine, all printing functions will be done in the same set of fixture, which will avoid the product being scratched.

5. All adjustments such as printing head, screen frame etc. can be fixed by wireless tablet PC, but linear machine must be adjusted manually.
