Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing
Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing
Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing
Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing
Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing
Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing
Specifications
Brand Name :
Senny
Model Number :
SRS1669-DR4CH
Certification :
CE SGS
Place of Origin :
China
MOQ :
1PC
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
10PCS /Month
Delivery Time :
45days
Packaging Details :
Plywood package
Printing Color: :
4 Col Screen Printing+1 Col Hot Stamping
Station :
5 Stations
Printing Durability :
High Durability
Condition :
New
Warranty :
1 Year
After-Sales Service :
Video Or On-line
Payment terms :
T/T
Package Details :
Plywood Package
Description

Robotic Arm Servo Drive Auto Hot Stamping Machine With 4 Colors Screen Printing And Double-Clamp Fixation For High-Speed Printing

Catalog 04_compressed.pdf

Application

The machine is designed with a multi-purpose concept, focusing on screen printing and hot stamping operations. It is particularly suitable for round lotion bottles, cups and other products, enabling flexible partial or 360-degree full-range screen printing and hot stamping processing.

Technical Specifications

Model SRS829-D SRS1033-D SRS1249-D SRS1669-D SRS829-DR SRS1039-DR SRS1249-DR SRS1669-DR
Printing stations 2 3 4 6 2 3 4 6
Product diameter Irregular shapes 20-100mm cylindrical 20-100mm
Printing speed Up to 45pcs/min
Max. printing area L250mm X W160mm
Product height 250mm
Air presser 6-7 bar
Power 380V 50/60HZ


Features

Blanking device

Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing

The bottles are gripped into the fixture by a robotic arm so that the product stands on the conveyor belt. If the bottles cannot stand because they are too small, too tall or have an irregular shape at the bottom, bottle holders can be added to the conveyor belt.

Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing

Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing

Flaming treament device for PP/PE material

Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing

UV curling device
Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing

Customer's plant using our machine

Robotic Arm Servo Drive Auto Hot Stamping Machine 4 Color Screen Printing

About us

SENNY PRINTING EQUIPMENT CO.,LTD was established in the year 2004, it is specialized in designing and manufacturing precise automatic screen printing machines, stick labler machines, hot stamping machines and auxiliary equipments. Meanwhile, they can design any kinds of automatic printing machines according to customers' requirements.

SENNY has very good designers. The founder of SENNY was engaged in designing and developing screen printing machines early from the year 1994, and he got many achievements: he designed the first automatic screen printing machine; automatic screen printing machine for big iron pails; four colors sereen printing machine for big oil kettles; automatic screen printing machines controlled by module independently for bottles; automatic screen printing machine for pails from 10L 1o 20L(3colors and 7colors) and so on so forth.

In order to improve our products, SENNY adopts the advantages of the similar products in or abroad, and we also take customers' comments and suggestions into consideration. With the innovation and improvement for many years, the products produced by SENNY now are in a leading position in the domestic markets. And it also sales well all around the world.

With the mission“Excellence,Creation,Sincerity,Quality!”,SENNY insists on providing high--quality products and services, dedicating to exploring the new markets and seeking for mutual benefit and win-win state with our customers.
