Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft
Specifications
Another name :
Johnson Wedge Wire Wedge Wire Screen Pipe
Material :
SS304
Surface treatment :
Electrolytic polishing
Diameter :
203mm or 219mm
SLot :
1.5mm (0.06")
v wire :
3x4.6mm
support wire :
3.8
Legnth :
3.048m (10ft)
Flow type :
from outside to inside (FOTI)
Usage :
Water well filter
Technology :
sprial welded
Products Tags :
8" wedge wire screen pipe, 10ft wedge wire screen tube, .060"johnson wedge wire screen
Brand Name :
Anping County Xinlu Wire Mesh Products Co.,Ltd
Model Number :
XL - Wedge Wire Screen Pipe - 045
Certification :
CO
Place of Origin :
Anping County, Hebei Province, China
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100pcs/20days
Delivery Time :
3-5days
Packaging Details :
wood case, pallet,container
Description

8“ X 10ft Continous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes Slot 0.060

wedge wire screens, v shaped wire welded stainless steel water well screens, low carbon galvanized water well screen, Johnson screen tube, johnson screen pipe, johnson well screen, johnson wire screen, johnson filter screen, johnson v wire screens,v wire slot tube, wire wrapped screen pipe, oil well screens, dewatering well screen, perfect roundness screen tube, profile wire screen pipe, reverse rolled screen tube, spiral screen tube, screen cylinders, rod based continous slot screens, sand conrol well screen, wire wound screen pipe, stainless steel filter elements, wedge wire roll screen, stainless steel strainer pipe

Product Quick Details:

Wedge Wire Screen Tube

1. Diameter: 8"-8/5/8"(203mm or 219mm)

2. Flow gap: 1.5mm

3. Profile Wire: 3x4.6mm (#118)

4. Support wire: 3.8mm

5. End joints: welded ring

6. length: 10ft = 3.048m

7. Weight: 50kg/pcs

8. Qty: 1x40ft container

9. FOB Tianjin 219-280$/pcs

Advantages Wedge Wire Screen Pipe include:

1. The wedge tapered opening becomes progressively wider increasing dewatering efficiency

2. Even gap, Non plugging,to make sure the smooth circulation

3. Smooth surface without burrs, brightly

4. Tensile Weight: 21.9Ton

5. Collapse Strength: 34bar

6. Easy to clean,long service life,safe and reliable,low comprehensive cost

Package: Stainless Steel Wedge Wire Screen Tube

Plastic bubble bag packaging
Transparent plastic bag inside, woven bag outside
Wooden box
Pallet

Johnson Wire Water Well Screen Pipe Wire Specification


SIZE

(INCH)

O.D

(MM)

SLOT

(MM)

LENGTH

(M)

COLLAPSE

STRENGTH

(BAR)

TENSILE

WEIGHT

(TON)

WRAP WIRE

(WIDTH*HEIGHT)

(MM)

RODS

(MM)
3-1/2 88.9 1.0 3 >22 10.2 2.3x3.5 3.8MM/22
4-1/2 114.3 1.0 3 >28 11.5 2.3x3.5 3.8MM/22
6-5/8 168.3 0.75 5.8 >40 12.8 2.3x3.5 3.8MM/32
6-5/8 168.3 1.0 5.8 >33 12.8 2.3x3.5 3.8MM/32
6-5/8 168.3 0.63 5.8 >83 45 3.2x6.0 6.0MM/32
8-5/8 219.1 1.0 5.8 >34 21.9 2.3x3.5 3.8MM/48
8-5/8 219.1 1.0 5.8 >50 38.2 3.0x5.0 4.0MM/48
8-5/8 219.1 1.0 5.8 >60 46 3.2x6.0 5.0MM/48
10-3/4 273.1 0.75 5.8 >50 32.9 2.3x3.5 4.9MM/55
10-3/4 273.1 1.0 5.8 >60 39.5 3.0x5.0 4.9MM/55
10-3/4 273.1 1.0 5.8 >100 48 3.2x6.0 5.0MM/55
12-3/4 323.9 1.0 5.8 >120 37.2 3.0x5.0 4.0MM/50
14 355.6 1.0 3 >80 37.8 3.0x5.0 4.0MM/59

　PROFILE WIRE
　WIDTH(mm) 1.00 1.50 1.50 2.00 2.30 2.50 3.00 3.05
　HEIGHT(mm) 2.00 2.00 2.50 3.80 3.50 4.00 4.60 6.35

　SUPPORT ROD ROUND
　WIDTH(mm) 1.80 2.00 2.50 3.00 3.00 Ø2.5--Ø6mm
　HEIGHT(mm) 2.50 3.00 4.00 4.60 6.00 ----

Johnson Wedge Wire Screen Pipe Application

water well

Juice

Beer
water supply systems
Refining & petrochemical
Filter equipment
Drum Filter
Sand control

Groundwater

Pump Filter

Motor Filter

Dewatering

Pharmaceutical

Groundwater
Architecture & Construction
Food & Beverage Screens
Mineral & Aggregate Processing
OEM Screen Components
Pulp & Paper Screens
Refining & Petrochemical
Waste Water Treatment
Water Well & Oil well
Salt industry

FAQ

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.

Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.

Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.

Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ftContinuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ftContinuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft

Xinlu Wedge Wire Screens Package

Continuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ftContinuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ftContinuous Slot Stainnless Steel 304 Johnson Wedge Wire Screen Tubes 8“ X 10ft

Product Tags: 8" wedge wire screen pipe, 10ft wedge wire screen tube, Slot 60 johnson wedge wire screen
