Specifications
Place of Origin :
Henan, China
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC, motor
Brand Name :
HONEST
warranty :
1 Year
material / metal processed :
Stainless Steel, Brass / Copper, Alloy, Carbon Steel, Aluminum
power (kw) :
60
weight (kg) :
15000
key selling points :
Multifunctional
Operating Mode :
Automatic
Name :
Scrap Steel Tailings Crushing Separation Equipment
Keyword :
Hammer crusher
Usage :
Waste metal recycling
Color :
Client's Requirements
Final product :
2-10cm
Raw material :
waste metal
Model :
SZS-600/800/1000/1200/1500/2000
Type :
Double shaft
Blade :
Cr12Mov
Speed :
10-12rpm
Description
Waste Steel Tailings Scraps Metal Recycling and Sorting Line
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Technical Parameters
Equipment Name
Power
2000 Double Shaft Shredder (Soft Start + H13 Blade)
132kW+132kW=264kW
630 Hammer Crusher (Water Cooling, Vibration Pad)
630kW
Vibrating Screen
2.2kW
Rotary Screen (Dust Removing)
22kW
Vibrating Screen
2.2kW
Drum Magnetic Separator 100%
3kW
Rotary Screen
22kW
Eddy Current Separator
5kWx3=15kW
Pulse Dust Collector (Spark Arrester & Cyclone)
30kW
Total Power: 1072kW
Footprint: 80m x24m x6m


APPLICATION

This recycling line is suitable for processing a wide variety of scrap metal materials: Scrap Vehicles & Appliances Car bodies, tinplate, household appliances, bicycles, truck parts, cans, and steel structures (≤6mm thick).
Scrap Steel & lron
Scrap steel tailings,mixed scrap iron/steel, shavings, old drums, color steel tiles, thin metal sheets, and construction scraps.
Copper Scrap Brass, red copper, copper sheets/shavings, and copper-containing components like cables, motorstransformers,and panels 87%.
Aluminum Scrap Aluminum sheets, wires, ingots, alloy doors/windows, and aluminum-containing machinery Stainless Steel Scrap Offcuts, sheets, utensils, and decorative or structural stainless steel waste.

Non-Ferrous & Precious Metals Lead, zinc, tin, molybdenum, solder, rare and precious metals, and other valuable raw materials.
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment


Final Materials

Through processes such as crushing and separation, these materials can be effectively sorted into iron.copper, aluminum, and non-metallic components, significantly improving recycling efficiency and resource utilization. Below are some examples of the output materials.
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Process Description

1. Material Feeding: The raw materials are loaded onto a chain-type conveyor, which transports them steadily into the shredder.
2. Primary Shredding: The shredder breaks the materials into large pieces, making them suitable for further processing.
3. Secondary Crushing: The shredded materials are then transferred via conveyor to a
hammer crusher.where they are crushed into smaller. uniform particles.
4. Dust Collection: A dust collection system operates simultaneously to capture dust generated during the crushing process, ensuring a clean and environmentally friendly operation.
5. Magnetic Separation: The crushed material passes through a magnetic separator, which removes ferrous metals (iron) from the material stream.
6. Rotary screen: The remaining non-ferrous and plastic mixture is conveyed into a rotary screen, which separates the material into three different size categories, each discharged
from a separate outlet.
7. Eddy Current Separation: Each of the three size-based outputs is fed into a dedicated
eddy current separator, which effectively separates non-ferrous metals (like aluminum and copper) from plastic.
Product Technology
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Detailed Structures
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Product Fature
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Customer Site
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Customer Feedback
Automatic Aluminum Window Frame Crusher Scrap Steel Tailings Crushing Separation Equipment
Company Show
Our Company has advanced technology, professional R&D team and perfect sales service system. Besides, we possess several patents and domestically-leading technologies. Our advanced equipment have been currently exported to USA, Spain, Turkey, Italy, Vietnam,Hungary, Australia, Korea, Malaysia, Singapore, India, Philippines, Ireland, Saudi Arabia, Dubai etc.
