CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation
Specifications
Brand Name :
SDLIFT Or OEM
Model Number :
SJG6-3
Certification :
CE ISO SGS
Place of Origin :
China
MOQ :
1 UNIT
Price :
USD5980- USD12800 / UNIT
Payment Terms :
T/T
Supply Ability :
1200 units per year
Delivery Time :
30 days
Packaging Details :
Iron case or plywood case package
Travel Height :
3000m
Lifting Height :
3000mm
Lift Style :
scissor portable garage car elevator
Oem :
Yes
Drive Mode :
hydraulic
Colour :
grey, blue or as your request
Safety Device :
Explosion-Proof Lock Valve
Lift System :
Hydraulic motor pump system
Load Capacity :
3000kg / 3000kg
Customization :
Available
Description

Double Deck Scissors Car Lift for Home Garage Parking

Application:

DOUBLE DECK SCISSOR CAR LIFTS with passion in full harmony with the most modern architectural and

urban environmental requirements. Double deck scissor lift is an ideal car lift solution for fast and easy access

underground garage of your villa. Installed to replace an access ramp on private property, the double deck

scissor car lifts are specially engineered for day to day residential application as a solution for maximizing

available space, storing automobiles, and providing security for exclusive and/or seasonal vehicles. It’s also

perfect for commercial parking operations looking to maximize their overall vehicle capacity. Optional color can

be easily in harmony with surrounding environment.

BENEFITS
One lift for two-car parking, maximize your utilization rate of your garage;
Quick and easy to pick up the car from the underground garage;
Far-end control and multi-control points at the different floors could be realized;
Great load capacity, safe and reliable.
CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation

Parameters:

1) Load capacity: 3000kgs (lower platform)
3000kgs (upper platform)
2) Platform size: 5.2m x 2.6m (lower platform)
5.2m x 2.6m (upper platform)
3) Lift height: 3m
4) Height between platforms: 3m
5) Power: 380v/50hz/3ph/5.5kw
6) Control system: 1 control box, 1 control panel, 2 remotes
7) Control buttons: up, down, stop, emergency
8) Safety device: explosion-proof lock valve
9) Standard: CE, ISO9001

Configuration:

1) Platform Material:120mm*60mm rectangular tube +6mm checkered iron

2) Scissor material: 200mm*100mm*10mm high strength Manganese Steel.

3) Hydraulic system: 380V/5.5Kw

4) High Precision Hydraulic Cylinder: 100*4sets

5) Piston Rod: 70*4 hard chromium plating surface.

6) High-pressure oil pump

7) Hydraulic oil: summer 46#, winter 32#

8) Controller: 1 control box below, 1 control panel above platform

Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety guard rails to guarantee safety of the car above platform.
3) The limit switch system helps the double parking car lift to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the double deck car lift are passed 1.2 times loading test before leaving factory.

CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy OperationCE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation

CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy OperationCE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation

The models we supplied for clients:

MODEL

LOAD CAPACITY

PLATFORM SIZE

LIFT HEIGHT

PIT DEPTH

POWER

SJG2.5-3

2.5T

5.2m x 2.6m

3m

600mm

220V, 240V, 380V or 400V

SJG2.5-3.5

2.5T

5.2m x 2.6m

3.5m

700mm

220V, 240V, 380V or 400V

SJG2.5-5

2.5T

5.6m x 3m

5m

750mm

220V, 240V, 380V or 400V

SJG3-2.5

3T

5m x 2.3m

2.5m

700mm

220V, 240V, 380V or 400V

SJG3-3

3T

5.2m x 2.6m

3m

750mm

220V, 240V, 380V or 400V

SJG3-3.5

3T

5.6m x 2.7m

3.5m

800mm

220V, 240V, 380V or 400V

SJG8-2.5

8T

6.5m x 4.5m

2.5m

750mm

220V, 240V, 380V or 400V

SJG12-3

12T

5.5m x 2.8m

3m

850mm

220V, 240V, 380V or 400V

SJG15-4.5

15T

8m x 2.2m

4.5m

950mm

220V, 240V, 380V or 400V

The double deck car lift can be customized as your detailed size.

The Certificates:

CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation

CE Certified Double Deck Scissors Car Lift for Home Garage Parking with Easy Operation

Our service:

1) We can design the portable car hoist as per your requirement.
2) The portable car hoist will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) Engineers are available to your country if necessary.
