Specifications
Place of Origin :
Sichuan, China
Brand Name :
BONENS
Model Number :
RIG
Specification :
250watt
Description :
50 ohm RF resistor, RF resistor
Resistance :
1 to 500 ohm
Resistance Tolerance :
±5%
material :
BeO and Cu
type :
Rf resistor
Characteristics :
high power
certificate :
ISO9001-2008,TUV,ROHS
Lead wire :
single Lead wire or double Lead wire
Type :
Flange RF power resistor
Supplier Type :
Retailer
Technology :
Thick Film
Package Type :
Throught Hole
MOQ :
100
Certification :
ISO9001-2008
Rated Power :
20W-30W
Description
Product Description
1000W 800W 500W 250W 100W 60W 30W 20W flange resistor 50 ohm 100 ohm RF resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
30W 20W ISO9001 2008 Certified Flange RF Power Resistor and Thermal Resistor
technical parameter
Electrical Characteristics:
Range of nominal resistance
1 ~500Ω
Resistance tolerance
±5%
Frequency range
0~2GHz
Standing wave ratio
1.2~1.3
Insulation resistance
≥ 1GΩ
Withstand voltage
500V/1 mm (Substrate thickness)
Environment Characteristics:
Rated power
1~1000W (70°C)
Temperature range
-55°C~+165°C
TCR
±300×10-6/°C
Temperature shock (-55°C/+125°C, 3 times)
ΔR≤±5%R
Moisture proof (GJB306A-96-Method106)
ΔR≤±5%R
Vibration (10-500HZ, 0.75mm, 6h)
ΔR≤±3%R, No mechanical damage
Test at low temperature (-55°C, 24h)
ΔR≤±5%R
Load life (96)
ΔR≤±5%
Collision
ΔR≤±3%R
Physical Characteristics:
Terminal strength(10N,5S)
No loose and fall off
Solderability(240℃,3s)
Tin layer covering area of 95%
