Specifications
Brand Name :
SANROCK POWER
Model Number :
SPDG20KW
Certification :
CE;ISO
Place of Origin :
Zhejiang, China
MOQ :
1 set
Price :
Chat with supplier now for more details.
Payment Terms :
MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100000set/month
Delivery Time :
18-30work days Shipping fee and delivery date to be negotiated.
Packaging Details :
Nude package for machines, Wooden box package for spare parts, Or customer demand.
Product Nam :
open type generator set / genset open type
Frequency :
50HZ/60HZ
Voltage :
48V, 110V, 220V, 230V, 240V, 380V, 400V, 415V, 480V
Cylinder :
3/4/6/12-According to power
Cylinder number :
3,4,6,8,12cylinders
Phase Number and connection :
3-phase 4-wire system
Cooling system :
Water cooling
Dimension of set (mm) :
1485*700*1000mm~7300*2440*2800mm
Net weight of set (kg) :
specified
Rated Power (kw/1500rpm) :
5-2250kva
Speed :
1500/1800RPM
Type :
Trailer Type, Silent Type, Container Type, Super Silent Type, Open Frame, Portable Type, Mobile Type, Canopy Type
Rated Power :
20KW,30KW,40KW,50KW,80KW,100KW,200KW,300KW,800KW,1000KW,1200KW,1500KW,1800KW,2200KW
Application :
Factory,Building,Farm,Bank etc
Usage :
Common Units, Standby Unit
Stroke :
Four Stroke
Logistics :
Whole machine transportation or disassembly transportation; Sea or railway transportation
Description

20kW Open Frame Diesel Generator for Telecommunications Infrastructure Maintenance
This heavy-duty 20kW open frame diesel generator is engineered to meet the critical demands of telecommunications infrastructure maintenance and repair. It provides a robust and reliable source of prime or standby power to restore and maintain network operations during grid outages, in remote locations, or during emergency deployments.

Key Features for Telecom Applications:
Mission-Critical Reliability: Ensures continuous power for cell towers, base stations, and transmission equipment, minimizing network downtime.
Rapid Deployment: The robust frame and optional mobility kits (wheels and tow bar) allow for quick transportation and setup by service crews.
Stable Power Output: Provides clean and stable electricity vital for sensitive electronic communication gear, protecting against power surges.
Extended Operation: Large fuel tank capacity and superior diesel fuel efficiency enable long-term operation for prolonged repair missions.
Durability: Built with a corrosion-resistant frame to withstand harsh weather conditions commonly encountered at remote site locations.
Ideal for telecom service teams, this generator is a vital asset for ensuring network resilience, enabling swift recovery from power failures, and supporting infrastructure upgrades.

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator


Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator


Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Applicable Industries
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant,
Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company.

Product descriptions from the supplier
100KVA 150KVA 200KVA 300KVA 400KVA 500KVA 700KVA Diesel Genset
"Contact us for specific product details or customized requirements"

Product Description

Technical parameters of diesel generator set
Generator set model:SPDG20KW
Steady state voltage adjustment rate (%):≤± 1
Generator power:20kW/25kVA
Voltage fluctuation rate (%):≤ ± 0.5
Power factor:COSΦ = 0.8 (lagging)
Transient voltage adjustment rate (%):＋20 ～－15
Output voltage:400V/230V
Voltage stabilization time (s):≤1
Generator set current:36A
Steady state frequency adjustment rate (%):≤ ± 1
Rated frequency:50Hz
Frequency fluctuation rate (%):≤ ± 0.5
Rated speed:1500rpm
Transient frequency adjustment rate (%):+ 10 ~ -7
Fuel grade:(standard) 0 # light diesel (normal temperature)
Frequency stabilization time (S):≤3
Diesel generator size:1620*620*1380(L*W*H mm
Diesel generator fuel consumption (100% load):224g/kW·h
Diesel generator weight:600kg
Diesel generator volume(LP7m):95dB(A)
Technical parameters of diesel engine
Cooling method: Closed water-cooling
Oil supply method: direct injection
Engine cylinder number: 4 / L Type
Speed regulation method: Mechanical
Bore stroke: 102*120mm
Intake method: Natural inhalation
Compression ratio: 16.5:1
Overload capacity: 110%
Start method:DC 24V Electric start
Diesel engines Speed: 1500rpm
Technical parameters of generator
Protection level:IP22
Wiring mode:Three-phase four-wire, Y-connection
Generator power: 20kW/25kVA
Adjustment method: AVR (Automatic Voltage Regulator)
Rated voltage: 400V / 230V
Output frequency: 50Hz
Insulation class: H class
Output factor: COSΦ = 0.8 (lag)
Product Name Diesel generator
Engine customized
Alternator customized
Protection genset shotdown when high water temperature,low oil pressure,shortcuit
Rated Power

20KW,30KW,40KW,50KW,80KW,100KW,200KW,300KW,800KW,1000KW,1200KW,1500KW,

1800KW,2200KW
Cylinder number
3,4,6,8,12cylinders
Cooling System Type
Water Cooling System
Applicable Industries
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company
Rated Voltage
48V, 110V, 220V, 230V, 240V, 380V, 400V, 415V, 480V
Speed
1500/1800
Frequency
50/60HZ
Diesel Engine
UK, USA, German, Japanese brand engines,4 stroke,water cooled
Alternator model
Stamford/Mecc alte brushless self-excited,IP23,Class H.
Power factor
0.8lagging
Noise level dB(a)
65-95/1m
Excitation
self-excitation
Phase Number and connection
3-phase 4-wire system
Dimension of set (mm)
1485*700*1000mm~7300*2440*2800mm

Customizable Options: SANROCK POWER Machinery Co., Ltd., offers various customization options for their products, including different genset power and frequency settings. This flexibility allows users to select the most appropriate equipment for their specific requirements, ensuring optimal performance and energy efficiency.

SANROCK POWER Machinery is committed to offering competitive prices without compromising on quality. Their products come with a 3-year warranty period, which provides customers with the assurance and peace of mind necessary to confidently purchase and utilize their generators.

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator


Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator


Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

Open Type Diesel Generator Telecommunications Infrastructure Diesel Engine Generator Set Small Diesel Generator

FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;


2.what can you buy from us?
Screw Air Compressor,Reefer Container Generator,Diesel Generator,Light Tower,Sewage Pump,Centrifugal Pump,Fire Pump System,Mobile Pump Truck


3. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese,Spanish
