Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
Specifications
Brand Name :
AGMT
Model Number :
SXP25S
Certification :
CE
Place of Origin :
Hefei, Anhui, China
MOQ :
One unit
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
100 units/month
Delivery Time :
15-20 working days
Packaging Details :
Film wrapped and packed in exported wooden case
Weighing Accuracy :
±0.2-0.5%
Packing speed :
180-300 bags / hour
Free air capacity :
0.1 M3 / Min
Discharge pressure :
0.7Mpa
Trademark :
EAGLE
Display type :
Touch screen/buttons
Machine material :
SUS / carbon steel
Description
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine
Self-Installed 3 Phase Plastic Particles Packing Scale for Provisions Industry
Working Principle
Materials flow through the feeding parts (connected hopper) into the belt feeder, then into the weighing hopper. The weighing hopper uses load cells for precise measurement. When manually placing a bag onto the packing machine's bag clamp device and touching the sensor, the bag is automatically clamped. The weighed materials discharge into the bag, which then releases onto the conveyor for transport to the sewing machine for thread stitching closure.
Technical Specifications
Product Name High Quality Packing Machine
Packing Material Wood
Application Materials Animal feed, granule fertilizer, urea, seed, rice, sugar, beans, corn, peanut, wheat, PP, PE, plastic particles, almond, nuts, silica sand, etc.
Display Resolution 5g, 10g
Weighing Range 10-50kg/bag or customized needs
Precision +/- (0.2-0.5)% FS
Packing Capacity 200-300 bags/hour or faster
Dimension (L*W*H mm) See detailed drawing, size customizable according to your site
Power Supply AC220V/380V, 50HZ, 1P/3P
Air Source 0.4-0.6 Mpa
Power 2.2KW
Working Temperature -10~40 ℃
Relative Humidity ≤90% RH (Non condensing)
Product Overview
This series of machines are designed for packing powders and flaked materials into open mouth bags. They feature low dust emission and high accuracy, making them suitable for materials including: Flour, Titanium, Alumina, Kaolin, Lime Carbonate, Bentonite, Dry mortar, and similar substances.
Primary Applications
Suitable for rationing package of powdery or particulate materials in the food, grain, feed, and chemical industries. Examples include bean pulp, linter pulp, mixtures, chemical powders, bran, and powdery grains.
Key Features
  • Bucket weighing method for accurate measurement
  • Multi-stage feeding mechanism for wide weighing range
  • Guaranteed speed and precision for maximum and minimum weighing
  • IP54 rated weighing control system (dustproof and waterproof)
  • Complete unit includes automatic weighing machine, conveyor, sewing machine, and automatic control box
  • Flexible device selection: various conveyors, sewing machines, and air pumps available
Machine Components
Controller: Touch screen operation panel with English/Chinese language switching for convenient operation.
Sealing Machine: Optional heat sealing or bag sewing machines. Heat sealing is suitable for PE/PET sack bags, while sewing machines work with woven and paper bags.
Packaging and Shipping
  • Standard export wooden packing and carton boxes
  • Multiple shipping options: express, air, train, or sea transport
  • Expert recommendations based on experience
  • Partnership with China's best shipping companies for competitive pricing and fast delivery
  • Complete tracking and feedback during transit
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
After-Sales Service
  • Comprehensive quality inspection throughout manufacturing process
  • Assistance with equipment foundation construction
  • On-site installation and debugging by dispatched engineers
  • Training for first-line operators
  • Regular client visits to resolve production issues
  • Life-long maintenance service
  • Technical exchange and support
Self Installed 3 Phase 50kg Wood Pellet Bagging Machine with Touch Screen Display
