25-50kg/bag Automatic Weighing And Packing Machine for Fertilizer Feed with 5-10 BPM Speed
25-50kg/bag Automatic Weighing And Packing Machine for Fertilizer Feed with 5-10 BPM Speed
25-50kg/bag Automatic Weighing And Packing Machine for Fertilizer Feed with 5-10 BPM Speed
25-50kg/bag Automatic Weighing And Packing Machine for Fertilizer Feed with 5-10 BPM Speed
25-50kg/bag Automatic Weighing And Packing Machine for Fertilizer Feed with 5-10 BPM Speed
25-50kg/bag Automatic Weighing And Packing Machine for Fertilizer Feed with 5-10 BPM Speed
Specifications
Brand Name :
AGMT
Model Number :
SXPA50
Certification :
CE
Place of Origin :
Hefei, Anhui, China
MOQ :
1 unit
Price :
23360
Payment Terms :
L/C,T/T
Supply Ability :
50 units/month
Delivery Time :
40-50 working days
Packaging Details :
Fumigation-free export wooden box
Name :
Rice Packing Machine
Filling method :
Screw filler / gravity filler
Weighing range :
25-50kg/bag
Packing speed :
5-10 BPM
Application :
Fertilizer Feed
HS code :
8422400000
Air supply source :
0.6MPa, 0.5m3/min
Dimension(L*W*H) :
5700*2800*3500mm
ty :
rtyu
Description
25kg Rice Packing Machine for Fertilizer Feed in Chemical Industry
This automatic weighing and packing machine is designed for efficient packaging of fertilizers, feed, and chemical products in 25kg quantities. The system handles various bag types including pre-made pouches, prefabricated bags, zipper pouches, spouted pouches, and shaped pouches with capacity up to 50kg.
Complete Packaging Line Integration
The integrated system includes material measuring, filling, bag feeding & clamping, bag conveying & sewing, with optional extensions for bag push down, bag shaping conveying, robot palletizing, and pallet stock systems.
Technical Specifications
Parameter SXPA50 SXPA50P
Packaging Weight 10-50KG 10-50KG
Bag Size: L*W(mm) 630-1100/350-650 630-1100/350-650
Bag Material Woven bag (paint film); Kraft bag; Composite film plastic bag (film thickness ≥0.18mm)
Measuring Accuracy 0.2%FS 0.2%FS
Packaging Speed 6-15 bags/minute 2-5 bags/minute
Sealing Mode Woven bag: folding/seam; Kraft bag: heat sealing/seam; Composite film plastic bag: heat sealing
Engineering Requirements
Electricity: 220/380V, 50Hz
Power: 14kw
Air Supply Pressure: 0.5-0.7MPa
Air Consumption: 1.8Nm³/min
Temperature Range: -15℃ to 45℃
Machine Components
  • Empty bag storage
  • Empty bag taking unit
  • Bag management unit
  • Bag sending unit
  • Bag upper unit
  • Bag clipping and material filling unit
  • Bag holding unit
  • Bag mouth guiding unit
  • Heat sealing / bag sewing station
  • Stand-up bag conveyor
  • Electrical control section
Main Components & Brands
Component Brand
Vacuum pumpShanghai Zhongde
CylinderJapan SMC
Solenoid ValveJapan SMC
Other pneumatic componentsJapan SMC
Normal MotorCPG
Servo MotorDelta (Taiwan)
Heat sealing headDechao
PLCOmron
Touch ScreenWeinview
InverterDelta (Taiwan)
Switching power supplySchneider (France)
SwitchSchneider (France)
Air switchSchneider (France)
AC contactorSchneider (France)
Motor circuit breakerSchneider (France)
Thermal relaySchneider (France)
Limit switchSchneider (France)
PhotoelectricSICK
Load cell
Key Features
  • SIEM PLC and Weinview 10-inch color touch screen for simple operation and stability
  • AirTAC magnetic valve, oil-water separator and cylinder in pneumatic system
  • German FESTO magnetic valve, filter, and digital vacuum pressure switch in vacuum system
  • Magnet switch or optoelectronic switch detection units on all actuating mechanisms for safety and reliability
Working Process
  • Automatic bag seizing
  • Automatic bag opening
  • Automatic bag feeding & material auto filling
  • Bag automatic transferred by the conveyor
  • Auto bag sewing / heat sealing (folded)
  • Finished bag output
25-50kg/bag Automatic Weighing And Packing Machine for Fertilizer Feed with 5-10 BPM Speed
Packaging and Delivery
Packing: Wrapped with film first, then packaged with standard wooden cases
Delivery: Standard sea transportation with alternative methods available upon request
25-50kg/bag Automatic Weighing And Packing Machine for Fertilizer Feed with 5-10 BPM Speed
