Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
Specifications
Brand Name :
Wisco
Model Number :
50WW350
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 MT
Price :
1000-3000 Usd / Mt
Payment Terms :
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
40 MT PER week
Delivery Time :
5-25 Days
Packaging Details :
Standard seaworthy export package
Standard :
GB
Grade :
50WW350
Certificate :
MTC, SGS
Mill :
Wisco
Process :
Cold rolled
Thickness :
0.5mm
Width :
730
Length :
in coil
Surface finish :
2B,
Description

50WW350 Cold Rolled Silicon Steel Coil non-oriented silicon steel sheets 0.5mm

The transformer works at rest.Large and medium-sized transformer cores are stacked with strips. Some distribution transformers, current and voltage transformers and pulse transformers are manufactured with wound cores, which can ensure the blanking and magnetization along the silicon steel plate rolling direction, so they are manufactured with cold-rolled oriented silicon steel
Dimensions of Products

Available thickness (mm) Availiable width range (mm) Inside Diameter (mm)
0.15,0.20 950-1000 508±10
0.30,0.35,0.50,0.70,0.75,0.80,0.85 1000~1250 508±10


Typical Mechanical Properties

Grade Yield strength Rp Tensile strength Rm Elongation Hardness HV5 Lamination factor %
(N/mm2) (N/mm2) (%)
L C L C L C
50WW350 390 410 510 530 25 27 185 98.5


Standard Magnetic Properties

Grade Norminal thickness Theoretical density Max. Core loss Min Induction Min. Number of bends Min. Lamination factor
P1550 50Hz 400Hz
mm kg/dm3 W/kg B5000 B2000 %
50WW350 0.5 7.65 3.1 1.62 6 97


Cold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mmCold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mmCold Rolled Silicon Steel Coil 50WW350 Nonoriented Sheets 0.5mm
